- Page 1 Translated from German to English - www.onlinedoctranslator.com Clothes dryer WQG233D20 [de] Instructions for use and assembly...
-
Page 2: Table Of Contents
Further information can be found in the digital instructions for use. Table of Contents 1 Security ........4 9 Programs ......... 24 1.1 General information ....4 9.1 Automatic programs ....24 1.2 Intended 9.2 Time programs ......25 use ........4 10 Accessories ........ - Page 3 16 Eliminating malfunctions ....38 17 Transport, storage and Disposal ......... 42 17.1 Preparing the device for transport ........42 17.2 Disposing of old devices ....42 18 Customer service ......43 18.1 Product number (E no.) And production number (FD) ........
-
Page 4: Security
de safety 1 security Please note the following safety instructions. 1.1 General information ¡ Read this guide carefully. ¡ Keep the instructions and product information for later use or subsequent owner. ¡ Do not connect the device if it has been damaged in transit. 1.2 Intended use Use the device only: ¡... -
Page 5: Safe Installation
safety de 1.4 Secure installation When installing the device, follow the safety instructions. WARNING - Risk of Electric Shock! Improper installations are dangerous. ▶ Only connect and operate the device in accordance with the information on the nameplate. ▶ Only connect the device to an alternating current power supply via a properly installed, earthed socket. - Page 6 de safety WARNING - Risk of Fire! Using an extended power cord and unapproved adapter is dangerous. ▶ Do not use extension cables or multiple socket strips. ▶ If the power cord is too short, contact customer service. ▶ Use only adapters approved by the manufacturer. WARNING - Risk of Injury! The heavy weight of the device can lead to injuries when being lifted.
-
Page 7: Safe Use
safety de CAUTION - Risk of Injury! The device may vibrate or move during operation. ▶ Place the device on a clean, level and firm surface. ▶ Align the device with the device feet and a spirit level. There is a risk of tripping if the hoses and mains connection cables are improperly laid. - Page 8 de safety ▶ Do not use steam cleaners, high pressure cleaners, hoses or showers to clean the device. WARNING - Risk of damage to health! Children can lock themselves in the device and endanger their lives. ▶ Do not place the appliance behind a door that blocks or prevents the appliance door from opening.
- Page 9 safety de WARNING - Risk of Fire! The refrigerant R290 in this device is environmentally friendly but flammable and can ignite if it comes into contact with an open fire or ignition sources. ▶ Keep naked flames and sources of ignition away from the device. WARNING - Risk of Explosion! Residues in the fluff filter can ignite during drying.
-
Page 10: Safe Cleaning And Maintenance
de safety ▶ Do not place any objects on the appliance door. Reaching into the rotating drum can injure your hands. ▶ Wait for the drum to come to a complete standstill before intervening. 1.6 Safe cleaning and maintenance When you clean and maintain the device, follow the safety instructions. -
Page 11: Avoid Property Damage
Avoid property damage Foam or foam rubber may deform or Avoid property damage melt as it dries. Do not dry any laundry ▶ containing foam or foam P lease heed these instructions in order to rubber. Avoid damage to property and Unsuitable cleaning agents can equipment. -
Page 12: Energy Saving Mode
de Set up and connect Spin the laundry in the washing Set up and machine before drying. Connect a Damp laundry lengthens the Program duration and increases energy consumption. 4.1 Unpack the device Adhere to the maximum load of the CAUTION! programs. -
Page 13: Requirements For The Installation Site
Set up and connect ▶ Replace the corresponding accessories conditions Installation site before operating the device. On the floor Place the device → "Accessories ", page 27 in a clean, level stand on a solid Scope of delivery Description surface. Clothes dryer Turn the device off judge... -
Page 14: Aligning The Device
de Set up and connect 4.4 Align the device Orient the device correctly to reduce noise and vibration. To align the device, turn the ▶ device feet. Check the alignment with a spirit level. All device feet must be firmly on the floor. -
Page 15: Getting To Know Each Other
To get to know de 5 Getting to know each other 5.1 Device Here you will find an overview of the components of your device. Ever ch device type, details in the picture may differ, e. B. Color and n / A Shape. -
Page 16: Control Panel
de To get to know 5.2 Control panel You can use the control panel to set all the functions of your device and obtain information on the operating status. Programs → Page 24 Program selector → Page 28 Display → Page 17 Keys →... -
Page 17: Display
Display de 6 display The display shows the current setting values, selection options or information texts. Exemplary display display designation description 0:40 Estimated program duration or remaining Program duration / time of the program. Remaining time of the pro gram 1:25 The time program is set. - Page 18 de Display display designation description Start pause Start, cancel or pause ¡ lights up: The program is running and can canceled or paused. ¡ flashes: the program can start or to be continued. The dryness level is activated. Drying target ironing →...
- Page 19 Display de display designation description Program status Drying target ironing Dry target Program status Cupboard dry Anti-crease Program status Break Program status Program status End of program example 19th...
-
Page 20: Buttons
de Keys 7th Keys H Here you will find an overview of the buttons and their setting options. selection description button Start / reload ¡ start Start program, break or pause. ¡ abort, stop ¡ pause 3 sec. ¡ activate Activate or deactivate the child lock. - Page 21 Keys de selection description button cupboard dry ¡ cupboard dry ¡ With the selection ¡+1 cupboard dry ¡+2 Activate the dryness target ¡+3 fourth. The dry target sets how damp or dry the laundry is after the program mende is. →...
- Page 22 de Keys selection description button Gentle drying ¡ activate Gentle drying activate or deactivate. ¡ deactivate The temperature is reduced for sensitive textiles, e.g. B. for acrylic or elastane. The program duration lengthens. ¡ End of program ¡ The end of the program Completed in ¡...
-
Page 23: Changing The Dryness Level
Dry target de 8th Dry target F. A drying level is specified for each automatic program. The dry target specifies how dry or damp your laundry is at the end of the program. Dry target Laundry Drying result cupboard The laundry is dry. Multi-layer, thick fabrics cken plus she that dries badly. -
Page 24: Programs
Programs 9 Programs S. Y ou can use either an automatic program or a Dry time program. 9.1 Automatic programs Tips Automatic programs are programs in which moisture sensors measure the ¡ Select the dryness level residual moisture in the laundry while depending on the textiles or the it is drying. -
Page 25: Time Programs
Programs de max. program description charge (kg) Hygiene plus Dry hard-wearing, heat-resistant textiles made of cotton and linen. Notice: Particularly suitable for increased hygienic requirements. Drying quick-drying sportswear made Sportswear from functional fibers, microfibres and synthetics. Shirts / blouses Dry shirts and blouses made of cotton, linen, synthetic fibers or blended fabrics. - Page 26 de Programs max. Time program description charge (kg) Dry all types of textile except wool and Time program warm silk. Suitable for pre-dried or slightly damp laundry and for subsequent drying of multi-layered, thick laundry. 26th...
-
Page 27: Accessories
Items left in the laundry can damage in the digital instructions for use by the laundry and the drum. scanning the QR code in the table of contents or at www.bosch-home.com. Remove all objects from the laundry ▶ pockets before use. -
Page 28: Basic Operation
Ready in time is scanning the QR code in the table of displayed. contents or at www.bosch-home.com. a The display shows after program end: "End". 12.5 Adding laundry 12.1 Switch on the device... -
Page 29: Canceling The Program
Basic operation de on Start / reload to press. Remove the fluff from the door. 12.6 Abort the program on Start / reload to press. The cooling process starts automatically after about 30 seconds and cools the laundry while the drum is rotating. If you want to avoid or cancel the cool down process, open the door. - Page 30 de Basic operation Separate the two-part lint filter. Thoroughly clean the two fluff 8th. filters with warm running water and dry them. Open the two fluff filters. Close the two fluff filters and put them together. Remove the fluff. Insert the two-part lint filter. Close the door.
-
Page 31: Filter System Of The Base Unit
Basic operation de Clean the heat exchanger cover 12.10 Filter system of the base with a soft brush. unit During drying, the lint from the laundry is collected in the filter system of the floor unit. The filter system protects the device from lint. Clean the filter system of the base unit If the display shows a message... -
Page 32: Condensate Container
de Basic operation Slide the filter mat onto the Pull out the condensed water brackets. container horizontally. Make sure that the cleaned filter Empty the condensed water mat is not deformed, damaged or container. pushed onto the brackets the wrong way round. Notice: You can use the filter mat →... -
Page 33: Parental Control
Notice: You can find more information in the digital instructions for use by scanning the QR code in the table of contents or at www.bosch-home.com. 1 5 Cleaning and care To keep your device functional for a 3 parental controls long time, clean and care for it carefully. -
Page 34: Floor Unit
de Cleaning and care Pull out the heat exchanger cover by 15.2 Floor Unit the handle. The bottom unit is the lower, accessible area of the device where the heat exchanger is located. Open the bottom unit requirements ¡ The device has been switched off for 30 minutes cools. - Page 35 Cleaning and care de Slightly lift the middle tab of the Carefully clean the fins of the heat insert. exchanger with the brush attachment of a vacuum cleaner. Pull out the insert horizontally. Make sure to vacuum the slats from top to bottom and not to deform or damage them in the process.
-
Page 36: Humidity Sensor
de Cleaning and care Clean the opening with a soft, Install the heat exchanger cover on 8th. damp cloth. the handle. Slide in the insert horizontally until Close the lever on the heat the tab clicks into place. exchanger cover. Close the bottom unit Close the maintenance hatch. - Page 37 Cleaning and care de The appliance changes the duration of the automatic program if there is residual moisture in the laundry. Clean the moisture sensor After a while, residues of lime, detergents and care products can build up on the moisture sensor. Regularly clean the moisture sensor.
-
Page 38: Eliminating Malfunctions
Troubleshooting 6 Eliminate malfunctions K You can rectify minor faults in your device yourself. Take advantage of the Troubleshooting information before contacting customer service. In this way you avoid unnecessary costs. WARNING Risk of electric shock! Improper repairs are dangerous. Only trained specialists are allowed to carry out repairs on the device. - Page 39 Troubleshooting de Cause and troubleshooting disturbance Device paused, but Cooling process active. the drum turns No mistake - no action required. ▶ himself. Wrinkling. Load is too high. Note the maximum load of the ▶ → "Programs ", page 24 . Laundry has been in the drum for too long after drying.
- Page 40 de Troubleshooting Cause and troubleshooting disturbance Pumping noise. Condensation pump active. Not a fault - normal operating noise. ▶ Whirring sound. Compressor ventilation active. Not a fault - normal operating noise. ▶ Drying time is too The bottom unit filter is dirty. →...
- Page 41 Troubleshooting de Cause and troubleshooting disturbance Laundry is too damp. Unsuitable program set for the type of fabric. Set a time program for subsequent drying. ▶ → "Programs ", page 24 Power supply has failed. Check that the room lighting or other devices in ▶...
-
Page 42: Transport, Storage And Disposal
Transport, storage and disposal Disconnect the device's power plug 1 7 Transport, from the power supply. Storage and disposal a The device is ready for transport. F ind out how to use your device here 17.2 Dispose of the old device prepare for transport and storage. -
Page 43: Customer Service
Customer service 18.1 Product number (E no.) This device is according to the European And production number Directive 2012/19 / EU (FD) Via electrical and electronic equipment (waste The product number (E no.) And the electrical and electronic production number (FD) can be found on equipment - WEEE). -
Page 44: Consumption Values
Consumption values 9 consumption values D. t he program cotton eco The actual values may differ from the (indicated by an "arrow") is suitable stated values depending on the type for drying normally wet cotton of fabric, the composition of the laundry and is most efficient in terms laundry to be dried, residual moisture of energy consumption for drying... -
Page 45: Technical Data
Technical specifications de Per- program Bela- Sluice Ener- damp the- gram giever- catching manure (kg) damp need rotating length of time (h: min) (kWh / number (U / min) Cycle) 12.0 1400 1:14 0.52 Cotton + ironing dry chick 12.0 1000 2:12 1.08... - Page 46 de Technical specifications (E no.) On the nameplate. Alternatively, you can find the model identifier in the first line of the EU energy label.
- Page 48 Contact data of all countries are listed in the attached service directory. Robert Bosch Hausgeräte GmbH Carl-Wery-Strasse 34 81739 Munich GERMANY www.bosch-home.com * 9001629781 * 9001629781 (010831)
