Multicom BMC-3G GPRS Module
with Solution 2000 & 3000
The Multicom BMC-3G module is designed to provide GPRS Base Station reporting.
It connects directly to the panel on the SDI-2 Bus.
There are 14 steps that an Installer will need to follow to set up the panel and the GPRS unit.
The following is from the Multicom BMC-3G Installation Guide.
Introduction
There are 14 steps in this Multicom BMC-3G
Installation Guide. Please ensure you complete
each step in order.
-
BMC 3G AlarmLINK
(Steps 1 -3) (Steps 4-6)
Connect Setup arm/disarm
the BMC-3G to give customers
communicator to control of the
your Bosch alarm Multicom via the
panel. AlarmLINK app.
2
Connect to the Bosch Panel
The BMC-3G connects directly to the Bosch
panel as shown in the following wiring diagram.
If the 12V auxiliary power output is unable to
supply the required 200mA, connect to a fixed
12V DC power supply (>200mA).
Note that TOTAL CURRENT DRAW
SDI-2 bus is 900mA MAX
Codepads and existing SDI-2 modules.
TechTools
(Steps 7-14)
Install TechTools
and program the
Multicom. Add
relays and techs.
Use TechTools to
add customers to
AlarmLINK and
your logo.
on the
including
Connect the Multicom BMC-3G
An overview of the basic hardware installation
steps. The full Multicom manual is available
---> bitly/mc3gman
1
Mount the Panel
The BMC-3G fits into any standard alarm
panel housing.
Mounting or
placement inside the
existing alarm panel
housing requires the
provided fly lead to
be attached and the
included antenna to
be mounted to the
top of the panel.
!
Note: If the BMC-3G is being installed in a poor
signal area, please consider using a high-gain
antenna available from your Multicom supplier.
