Installation/Care/Use Manual
Hydroboost Bottle Filling Station and Cooler
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREATING AN ELEC-
TROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE WATER.
THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN FITTINGS
PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE FOUNTAIN
FROM THE BUILDING PLUMBING SYSTEM. WE SUGGEST THAT THE BOTTLE FILLING STATION AND WATER
COOLER BE PROTECTED BY A GROUND FAULT CIRCUIT INTERRUPTER (GFCI).
INSTALLER
HTHB-HVRGRN Bottle Fillers are among the easiest to install on the market today.
To insure you install these models easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK
YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND
OTHER APPLICABLE CODES. After installation, leave these instructions with the
Fountain for future reference.
HVRGRN8WS*1B HVRGRN8BLWS*1B
HTHB-HVRGRN Factory Prep
Page 1
IMPORTANT
THIS IS AN INDOOR APPLICATION ONLY.
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSON.
TOOLS REQUIRED
BUT NOT PROVIDED:
SAFETY GLASSES
GLOVES
ELECTRIC DRILL
3/4" WRENCH OR CRECENT WRENCH
5/16" NUT DRIVER
UTILITY KNIFE
TAPE MEASURE
PENCIL
CENTER PUNCH
1/2" SOCKET & RATCHET WRENCH
5/32" ALLEN WRENCH
98767C (Rev. A - 6/11)
Advertisement
Related Manuals for Halsey Taylor GreenSpec HTHB-HVRGRN
Summary of Contents for Halsey Taylor GreenSpec HTHB-HVRGRN
- Page 1 HVRGRN8WS*1B HVRGRN8BLWS*1B Installation/Care/Use Manual HTHB-HVRGRN Factory Prep Hydroboost Bottle Filling Station and Cooler IMPORTANT THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON. TOOLS REQUIRED BUT NOT PROVIDED: SAFETY GLASSES GLOVES ELECTRIC DRILL 3/4”...
- Page 2 HVRGRN8WS*1B HVRGRN8BLWS*1B Single Rough-In Fig. 1 98767C (Rev. A - 6/11) Page 2...
- Page 3 HVRGRN8WS*1B HVRGRN8BLWS*1B Two -Level Rough-In Fig. 2 Page 3 98767C (Rev. A - 6/11)
- Page 4 HVRGRN8WS*1B HVRGRN8BLWS*1B 7/16” BOLT HOLES FOR MOUNTING FASTENING UNIT TO WALL TOP COVER SCREWS UNIT CENTER LINE Fig. 3 Fig. 4 BOTTLE FILLER INSTALLATION Remove two (2) mounting screws with 5/32” allen wrench holding top cover to Bottle Filler (See FIG. 4). Remove top cover. Note do not discard mounting screws, they will be needed to reinstall top cover..
- Page 5 HVRGRN8WS*1B HVRGRN8BLWS*1B BF6-BF7-BF8 PROGRAMS SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE RESETTING BOTTLE COUNT 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted. The chiller until the display changes then release.
- Page 6 HVRGRN8WS*1B HVRGRN8BLWS*1B BF9 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE SETTING UNIT TYPE 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted. The chiller until the display changes then release.
-
Page 7: Replacement Part Kits
HVRGRN8WS*1B HVRGRN8BLWS*1B ® WATERSENTRY PLUS FILTER PARTS LIST LISTA DE PIEZAS DEL FILTRO LISTE DES PIÈCES DU FILTRE (See Fig. 7) (Vea Fig. 7) (Voir Fig. 7) ITEM NO. PART NO. DESCRIPTION DESCRIPCIÓN DESCRIPTION Ensamblado de la Cabeza del Filtro Ens.
