- Page 1 NEC Value Series User’s Manual 78131791 7/29/98, 9:24 AM...
- Page 2 CAN/CSA 22.2 No. 950. 78131791 FCC Information 1.Use the attached specified shielded cables with the JC-1745UMA-1 color monitor so as not to interfere with radio and television reception. (1) Shielded power supply cable. (2) Shielded captive type signal cable.
-
Page 3: Table Of Contents
Geometry Controls MultiSync is a registered trademark of NEC Technologies, Inc. in the U.S. and of NEC Home Electronics, Ltd. in Canada, UK, Germany, France, Spain, Italy, Austria, Benelux, Switzerland, Denmark, Finland, Norway and Saudi Arabia. OptiClear and ErgoDesign are registered trademarks of NEC Technologies, Inc. in the U.S. XV a registered trademark of NEC Corporation Copyright ©... -
Page 4: Packaging
3. Captive signal cable 4. User’s manual 5. Registration card: Please fill out and return this card as soon as possible. Remember to save the original box and packing materials to transport or ship this monitor. 78131791 ® +™ 7/29/98, 9:24 AM... -
Page 5: Quick Start
Quick Start Is the monitor Is the computer a a MultiSync ® Macintosh ™ computer? monitor? Call NEC at (800) 820-1230 to receive your MultiSync XV Macintosh cable adapter. Attach the Mac adapter to the monitor connector on the Macintosh. - Page 6 To attach the MultiSync XV monitor to your system, follow these instructions: 1. Turn off the power to your computer and MultiSync monitor. 2. If necessary, install the display card. For more information, refer to the display card manual. 3. For the PC: Connect the MultiSync XV cable to the display card’s connector on the computer.
-
Page 7: Quick Start
3. Check the pin assignment and signal timing charts of the display card and make sure the monitor accepts these pin assignments and signal timings. 4. Connect the signal cable supplied with your display card to the monitor. 5. Connect one end of the power cable to the MultiSync XV the other end to the power outlet. -
Page 8: Introduction
Introduction Congratulations on your purchase of NEC’s MultiSync monitor, which includes Microsoft ® ’s Plug and Play compatibility. Other features that enhance the MultiSync XV performance are NEC’s ErgoDesign ® features and the OSM (On-Screen Manager) controls. Screen Technology The MultiSync XV monitor also features NEC’s exclusive... -
Page 9: Ergodesign ® Features
Field ™ technology designed to reduce magnetic and alternating electric field emissions and static electricity. NEC MultiSync monitors follow the strictest magnetic field, alternating electric field and electro-static recommendations of the Swedish Board for Technical Accreditation, or SWEDAC (previously known as... -
Page 10: Osm™ (On-Screen Manager) Controls
Horizontal and vertical FullScan capability can increase the ™ display size of a variety of video modes to the edges of the monitor bezel. The FullScan capability allows you to use the entire screen area in most resolutions, significantly expanding image size. -
Page 11: Controls
Controls Control Panel EXIT CONTROL control buttons on the front of the monitor function as ™ follows: Main Menu Sub-Menu Exits the OSM controls. Exits to the OSM controls EXIT main menu. CONTROL Moves the highlighted Moves the highlighted area... -
Page 12: Osm Controls Menu
Controls ™ Controls Menu Main Menu OSM controls main menu of icons gives you an overview of the selection of controls available. When OSM controls are activated, icons are displayed at the top of the menu. If an arrow button is displayed, ( ), it indicates further choices are available. -
Page 13: Geometry Controls
OSM Turn Off: The OSM controls menu will stay on as long as it is in use. In the OSM Turn Off sub-menu, you can select how long the monitor waits after the last touch of a button to shut off the OSM controls menu. The preset choices are 10, 20, 30, 60, 120 seconds. -
Page 14: Information
When the tips appear, follow the advice of the tips and press EXIT to clear. For additional information on setting up a healthy work environment, see pages 16-20. Display Mode: Indicates the current mode and frequency setting of the monitor. 78131791 7/29/98, 9:24 AM... -
Page 15: Specifications
Invar Shadow Mask, multi-layered, anti-static screen coating and OptiClear ® screen surface Depends on display card used Automatically Automatically Some systems may not support all modes listed. NEC cites recommended resolution at 75 Hz for optimal display performance. 7/29/98, 9:24 AM... -
Page 16: Specifications
Specifications Monitor Specifications Active Display Area (Factory Setting) Active Display Area (Full Scan) Power Supply Current Rating Dimensions Weight Operating Temperature: Environmental Humidity: Considerations Feet: Storage Temperature: Humidity: Feet: 78131791 MultiSync ® ™ Monitor 306 x 230 mm 12.0 x 9.1 inches 316 x 237 mm 12.4 x 9.3 inches... -
Page 17: Recommended Use
For optimum performance, please note the following when setting up and using the MultiSync ® • If possible, position the monitor so that it is facing east to minimize the effects of the earth's magnetic field. • Allow adequate ventilation around the monitor so that heat can properly dissipate. -
Page 18: Setting Up A Healthy Work Environment
For a complete, detailed explanation on setting up a healthy work environment, call NEC at (800) 820-1230, NEC FastFacts™ information at (800) 366-0476... - Page 19 Check the following when you position the monitor: • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly down- ward when viewing the middle of the screen.
- Page 20 Setting Up a Healthy Work Environment Checking Your Comfort: How Do You Measure Up? Use this checklist to see if you are setting up your work environ- ment to fit your physical needs. Checking Your Chair • Do you sit in an upright position with the backrest support- ing your lower back? •...
- Page 21 78131791 Checking Your Monitor • Did you adjust your monitor so that the top of the screen is at or slightly below eye level? • Do you periodically rest your eyes by blinking often or looking away from the screen? •...
-
Page 22: Setting Up A Healthy Work Environment
78131791 • Do you have regular eye checkups? • Do you contact your doctor if you feel any sustained discomfort? For more detailed information on workstation setup, call NEC at (800) 820-1230, NEC FastFacts ™ information at (800) 366-0476 and request document #900108 or write the American National Standard for Human Factors Engineering of Visual Display Terminal Workstations. -
Page 23: Troubleshooting/Support
• Signal cable should be completely attached to the computer. Image is scrolling or unstable • Check the pin assignments and signal timings of the monitor and your display • If the Mac adapter is used, check for proper connection or make sure the display card is Mac •... - Page 24 Troubleshooting/Support Problem Check These Items • Move electrical devices that may be causing electrical interference away from the monitor. Picture bounces or a waving pattern • See inside cover of this manual for FCC information. is present in the picture •...
-
Page 25: Fastfacts ™ Information
- Know the name of the display card you are using and have its manual nearby. 78131791 If it is more convenient to fax a question to NEC’s technical support, the fax number is (508) 635-4666. The BBS The NEC Remote Bulletin Board System (BBS) is a great way to keep in touch with NEC. -
Page 26: Warranty
Limited Warranty NEC Technologies, Inc. (hereinafter NECTECH) warrants this Product to be free from defects in material and workmanship and agrees to repair or replace any part of the enclosed unit which proves defective under these terms and conditions. How Long is the Warranty Parts and labor are warranted for three (3) years from the date of the first consumer purchase. - Page 27 While NEC TECHNOLOGIES, INC. Products are considered to be compatible with many systems, the specific functional implementation by the customers of the Product may vary.
-
Page 28: References
References ™ Advanced Digital Control System ANSI/HFS 16, 20 BBS (Remote Bulletin Board System) Brightness Control 10, 21 Contrast Control 10, 21 6, 13 Degauss Control 10, 21, 22 Dimensions Display Area Display Mode Dot Pitch (See Mask Pitch) 6, 13 DPMS Dynamic Beam Focus Electronic Channels... -
Page 29: Directory Of Telephone Numbers
1745201 MultiSync Monitor Technical Support Technical Support Fax 900203 NOTE: To request the “Setting Up a Healthy Work Environment” brochure, call NEC at (800) 820-1230, or NEC FastFacts information at (800) 366-0476 and request document #900108. 900204 153006 900108 7/29/98, 9:24 AM... - Page 30 Notes 78131791 7/29/98, 9:24 AM...
- Page 31 PROPRIETARY NOTICE AND LIABILITY DISCLAIMER The information disclosed in this document, including all designs and related materials, is the valuable property of NEC and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including all design, manu- facturing, reproduction, use, and sales rights thereto, except to the extent said rights are expressly granted to others.
- Page 32 Printed on Recycled Paper MultiSync is a registered trademark of NEC Technologies, Inc. 78131791 NEC Value Series NEC Technologies, Inc. 1250 North Arlington Heights Road Itasca, IL 60143-1248 7/29/98, 9:24 AM Part No. 78131791 Printed in U.S.A.
