- Page 1 SANTO 75438 KG User manual Fridge-Freezer Manual de instruções Combinado Gebrauchsanweisung Kühl-Gefrierkombination Downloaded from Fridge-Manual.com Manuals...
- Page 2 Dear Customer Thank you for choosing one of our high-quality products. With this appliance you will experience the perfect combination of functional design and cutting edge technology. Convince yourself that our appliances are engineered to deliver the best performance and control - indeed we are setting the highest standards of excellence.
-
Page 3: Table Of Contents
Contents Safety ..........4 Disposal . -
Page 4: Safety
Safety The safety aspects of our appliance comply with accepted technical standards and the German Appliance Safety Law. Nevertheless, we consider it our obligation to make you aware of the following safety information: Intended use • The appliance is intended for use in the home. It is suitable for the cooling, freezing and storing of frozen food, as well as for making ice. -
Page 5: Disposal
concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. Daily Operation • Containers with flammable gases or liquids can leak at low temperatures. There is a risk of an explosion! Do not store any containers with flammable materials such as, for example, spray cans, fire extinguisher refill cartridges etc in the refrigerator/freezer. -
Page 6: Disposal Of Old Appliances
The carton parts are made from recycled paper and should be disposed of at a waste-paper recycling collection location. Disposal of old Appliances For environmental reasons, refrigeration appliances must be disposed of properly. This applies to your old appliance, and - at the end of its service life - for your new appliance as well. -
Page 7: Your Appliance Needs Air
The climate classification can be found on the serial plate, which is located at the left on the inside of the appliance. The following table shows which ambient temperature is correct for each climate classification: each climate classification: If installation next to a source of heat is unavoidable, the following minimum clearances must be maintained at the sides of the appliance: Climate classification for an ambient temperature of... -
Page 8: Rehingeing The Door
Door Reversibility The door reversibility is not possible. Electrical connection Before initial start-up, refer to the appliance rating plate to ascertain if supply voltage and current values correspond with those of the mains at the installation location. e.g.: 220 ... 240 V 50 Hz or 220 ... -
Page 9: Control Panel
Control panel MODE RESET A Fridge section indicator B Temperature indicator for fridge section C Buttons for setting temperature for fridge section D Thermometer indicator for fridge section (with COOLMATIC) E MODE button for setting the operating mode F Text display G RESET button H Freezer section indicator I Temperature indicator for freezer section... - Page 10 DESIRED temperature means: The temperature that has been selected for inside the fridge or the freezer compartment. The DESIRED temperature is indicated by flashing numbers. ACTUAL temperature means: The temperature display indicates the current temperature inside the fridge or the freezer compartment. The ACTUAL temperature is indicated with illuminated numbers.
- Page 11 – FROSTMATIC and COOLMATIC: Cooling for freezer section runs for 52 hours in continuous operation, fridge temperature value 2 °C for 6 hours. – HOLIDAY: Fridge temperature value approx 14 °C. – : Normal operation according to the required temperatures set. 1.
- Page 12 Prior to Initial Start-Up Before connecting the appliance to the mains and putting it into ope-ration for the first time, leave the appliance to stand for 30 minutes if was transported upright. After transport on its side, the appliance must be left to stand for 2 hours before putting it into operation.
- Page 13 Temperature Adjustment With the individual temperature setting buttons the desired temperatures in the refrigerator and in the freezer compartment can be adjusted independently of one another. 1. Press either the „+“ (WARMER) or „-“ (COLDER) button for the refriger- ator or freezer compartment . The temperature display switches over and the DESIRED temperature currently set flashes on the temperature display.
- Page 14 Operating modes Using the MODE button different operating modes can be selected. The operating modes are automatically switched off after a corresponding period, but can also be manualled ended each time. To do this, press the MODE button repeatedly until there are no longer any words appearing in the display.
- Page 15 The operating mode FROSTMATIC is automatically switched off depending on how the appliance is filled at the latest after approx. 52 hours. The FROSTMATIC indicator will go out. COOLMATIC The COOLMATIC operating mode is suitable for quickly cooling larger quantities of refrigerated foods in the fridge section, e. g. drinks, salads for a party or wedding.
- Page 16 After emptying and cleaning the appliance, proceed as follows: 1. To switch on the holiday setting, press the MODE button repeatedly until HOLIDAY is flashing in the display. After approx. 4 seconds the operating mode HOLIDAY is activated, HOLIDAY lights up. Important! Do not store any goods in the refrigerator when the holiday mode is in operation.
-
Page 17: Temperature Warning
Temperature warning For the freezer section: An alarm sounds and the TEMPERATURE indicator and red back light flash, as soon as the temperature in the freezer section rises above -11 °C. In addition the temperature display for the freezer section flashes. If the temperature in the freezer section falls back below -11 °C, the alarm automatically switches itself off. -
Page 18: Interior Accessories
Interior Accessories Storage Shelves The glass shelf above the fruit and vegetable compartment should always remain in position, to ensure fruit and vegetables stay fresh longer. The remaining storage shelves can be adjusted to various heights: Pull the storage shelf forward until it can be tipped up or down and D338 removed. -
Page 19: Moisture Regulator
Moisture regulator There is an adjustable air grille in front of the shelf above the fruit and vegetable compartments. The opening in the ventilation slots can be adjusted with the slider. Right slider: Ventilation slots opened. With the ventilation slots open, more air circulation results in a lower air moisture content in the fruit and vegetable compartments. -
Page 20: Air Recycling
Air recycling The refrigerator compartment is equipped with a special D.A.C. (Dynamic Air Cooling) fan which can be turned on with the switch B (seefig.). The green light, when on, means that the fan is working. It is suggested that the device be used when the ambient temperature exceeds 25°C .
