Black & Decker MX400B Quick Start Manual

5- SPE ED HAND MIXER
BATIDORA DE MANO DE 5 VELOCIDADES
u se an d c are manual
manua l de uso y cui dado
M X400B
PARTS AND FEATURES
1
3
4
1. Storage case (Part # 12224) 5. Speed wheel
2. Whisk (Part # 35045) 6. Easy eject feature
3. Dough hooks 7. Mixer body
(Part # 35042-C Left)
8. Heel and bowl rest
(Part # 35043-C Right)
9. Turbo boost button
4. Beaters
(Part # 102170033 Left)
(Part # 102170032 Right)
Product may vary slightly from what is illustrated.
WHAT SPEED TO USE
1 (Low) 2 (Low/Med) 3 (Medium)
Stir Combine Mix
Combining dry and Preparing puddings; Creaming butter and
wet ingredients. mixing dough or thin sugar; mixing cake
Adding to mixtures: batter. batters and frostings.
nuts, dried fruits,
chocolate chips.
HOW TO CLEAN
Wipe mixer body with damp cloth and dry thoroughly with a dry cloth. Hand wash attachments in warm,
soapy water or in the dishwasher.
STORAGE
Store all attachments and power cord in the storage case. Insert bottom of mixer into case and snap
together for storage.
Customer Care Line: 1-800-465-6070
www.prodprotect.com/blackanddecker
Línea de Atención del Cliente: 1-800-465-6070
Para servicio al cliente en línea:
www.prodprotect.com/blackanddecker
6
5
Off
8
2
7
GETTING STARTED
• Remove all packing material, any
stickers, and the plastic band
around the power plug.
• Remove and save literature.
• Please go to
www.prodprotect.com/
blackanddecker
to register your warranty.
• Wash all removable parts.
4 (Med/High) 5 (High)
Blend Beat/Whip
Beating whole eggs Whipping cream and
or frozen desserts; egg whites; mashing
mixing light batter, potatoes.
such as for popovers.
For online customer service:
When using electrical appliances, basic safety precautions should always be followed, including the following:
• Read all instructions.
• To protect against risk of electrical shock do not immerse cord, plugs
or appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by or
near children.
• Unplug from outlet when not in use, before putting on or taking off
parts and before cleaning.
• Avoid contacting moving parts. Keep hands, hair and clothing- as well
as spatulas and other utensils- away from beaters during operation to
reduce the risk of injury to persons, and/or damage to the mixer.
• Do not operate appliance with a damaged cord or plug, or after the
appliance malfunctions or has been dropped or damaged in any
manner. Contact Consumer Support at the toll-free number listed in
the warranty section. This appliance has important markings on the
plug blade. The attachment plug or entire cordset (if plug is molded
onto cord) is not suitable for replacement. If damaged, the appliance
must be replaced.
POLARIZED PLUG (120V models only)
This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is intended to fit into a
polarized outlet only one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do
not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw to
prevent removal of the outer cover. To reduce the risk of fire or electric
shock, do not attempt to remove the outer cover. There are no user-
serviceable parts inside. Repair should be done only by authorized service
personnel.
HOW TO USE
6
1
Select correct attachment(s)
9
for mixing task:
•Beaters-general mixing
•Whisk-whipping, aerating
•Hooks-kneading dough
5
For least-mess mixing:
Before turning on, insert
attachment(s) into the center
of food at a 90 degree angle.
TURBO
(high speed burst)
Use at any speed
setting to get
maximum power for
tough mixing tasks.
Please Read and Save this Use and Care Book.
IMPORTANT SAFEGUARDS
• The use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter.
• Do not let cord contact hot surface, including the stove.
• Remove beaters from mixer before washing.
• This appliance is not intended for use by persons (including children)
with reduce physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• The maximum rated wattage for this product was obtained with
the dough hooks. Other recommended attachments may draw
significantly less power or current.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
ELECTRICAL CORD
a) A short power-supply cord is provided to reduce the risks resulting
from becoming entangled in or tripping over a longer cord.
b) Extension cords are available and may be used if care is exercised in
their use.
c) If an extension cord is used:
1) The marked electrical rating of the extension cord should be at least
as great as the electrical rating of the appliance; and
2) The cord should be arranged so that it will not drape over the
counter top or tabletop where it can be pulled on by children or
tripped over.
Note: If the power cord is damaged, please contact the warranty
department listed in these instructions.
Larger
Hole
Collar
2 3
NOTE: To insert beaters With mixer unplugged from
and dough hooks, insert the outlet, insert attachment(s).
attachment with a collar into
the larger hole.
7
6
NOTE: To avoid getting TIP: To scrape the bowl with
powder inside the unit, mix
a spatula, first turn mixer off
at speed 1 until dry and wet then place mixer on heel rest.
ingredients are combined.
Begin all mixing tasks on speed 1,
then increase as needed.
4
Once attachment(s) are firmly
inserted, plug the mixer into
outlet.
8
When finished, unplug mixer
and turn speed wheel to O.
Then press wheel downwards
to eject attachment(s).
21856-004
T22-5004130-B
