ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can cause injury.
Side Handle (Fig. E)
WARNING: To reduce the risk of personal injury,
ALWAYS operate the tool with the side handle properly
installed. Failure to do so may result in the side handle
slipping during tool operation and subsequent loss of
control. Hold tool with both hands to maximize control.
WARNING: Before using the tool, check that the side
handle is tightened securely.
The side handle
4
threads into either side of the motor
housing and allows right or left hand use.
Installing the Side Handle (Fig. E)
WARNING: The side handle should always be used to
maintain control of the tool at all times.
1. Choose right or left hand use and insert the side
handle
4
into the side handle hole located on either side
of the motor housing
2. Lock the side handle
the side handle
4
rotating it clockwise so that the side
handle
4
will not rotate.
3. To switch the location of the side handle
side handle counterclockwise until it is free from the
motor housing. Move the side handle to the opposite
position and reinstall as described above.
Installing and Removing the Auger Bit or
Other Tool Specific Accessory (Fig. F, G)
WARNING: Always lock off trigger switch
and disconnect tool from power source when
changing acces sories.
WARNING: Always ensure the auger bit is secure
before starting the tool. A loose auger bit may eject
from tool causing possible personal injury.
WARNING: Check to be sure the accessory is straight
before installing onto the tool. A bent accessory can
create a hazardous imbalance or can move in a way to
create a hazardous condition.
To insert an auger bit
6
or other accessory, follow
these steps.
1. Turn tool off and remove battery pack.
2. Unlock the pin snap
the auger bit
6
.
3. With one hand secure the tool. With the other hand
grasp the auger bit
6
onto the drive shaft
13
4. Rotate the auger bit to align the holes
auger bit sleeve
9
and drive shaft
5. Insert the lock pin
7
drive shaft
13
holes
6. Lock the lock pin
7
in position with the pin snap
5
.
4
in place by securely tightening
4
rotate the
8
and remove the lock pin
and install the auger bit sleeve
as shown in Fig. Z.
14
on the
13
.
through the auger bit sleeve
14
.
7. To remove the auger bit, repeat steps 1 and 2 above.
Secure the tool with one hand. With the other hand
grasp the auger bit
drive shaft
OPERATION
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can cause injury.
Installing and Removing the Battery Pack
(Fig. H)
WARNING: Ensure the tool/appliance is in the off
position before inserting the battery pack.
nOTE: For best results, make sure your battery pack is
fully charged.
1. To install the battery pack
the battery pack with the rails inside the tool's handle
and slide it into the handle until the battery pack is firmly
seated in the tool and ensure that it does not disengage.
2. To remove the battery pack from the tool, press the
release button
the tool handle. Insert it into the charger as described in
the charger section of this manual.
Proper Hand Position (Fig. I)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main
handle
3
, with the other hand on the side handle
control the twisting action of the tool.
Trigger Switch/Reversing Button (Fig. A, J)
1. The tool is switched ON and OFF by squeezing and
releasing the trigger switch
2. A forward/reverse control button
direction of the auger bit
off button.
3. To select forward rotation, release the trigger switch and
depress the forward/reverse control button to the left.
4. To select reverse, depress the forward/ reverse control
button the opposite direction.
nOTE: The center position of the control button locks the
7
from
tool in the off position. When changing the position of the
control button, be sure the trigger is released.
9
9
and
8
.
6
and pull the auger bit from the
13
.
1
into the tool handle, align
and firmly pull the battery pack out of
11
1
.
2
6
and also serves as a lock
English
