Makita 6260DWPE Parts List

Item Part Qty.
No. No. Use
d
1 125102-2 1 SPEED CHANGE LEVER ASS'Y
2 183793-5 1 HOUSING SET (INC. 14,15)
4 266130-9 9 TAPPING SCREW BIND PT 3X16
5 232182-2 1 LEAF SPRING
6 417283-9 1 F/R CHANGE LEVER
7 650556-9 1 SWITCH C3NA-1-M1
8 643909-9 1 BATTERY HOLDER
9 251468-5 1 - FLAT HEAD SCREW M6X22
11 125237-9 1 GEAR ASS'Y
12 629815-2 1 DC MOTOR
13 911003-8 2 PAN HEAD SCREW M3X6
14 819001-5 1 MAKITA LABEL
15 183793-5 1 HOUSING SET (INC. 2,14)
02-05
"
3/8 Cordless Driver Drill
(10MM)
9
10
14
Description
SINGLE VAR/REV
5
6
7
8
11
12
13
15
Item Part Qty.
No. No. Used
ACCESSORIES
10 763185-0
A01 414938-7
A02 DC1804
A03 784636-0
A04 824635-1
A05 193979-3
1
MODEL 6260DWPE
1
2
4
Description
1 KEYLESS DRILL CHUCK 10
2 BATTERY COVER
1 BATTERY CHARGER
1 +- BIT 2-65
1 PLASTIC TOOL CASE (Incl. 1 Ea.
1 Slide Latch Set 186347-7, Makita
1 Label 819143-5)
1 BATTERY PA09
Model 6260DWPE
