PA151
Two-Way Speaker System
Architects' and Engineers' Specifications
The two-way loudspeaker system shall be self-contained
and consist of the following components: (1) a 15-inch, low-
frequency driver; (2) a high-frequency section consisting of a
constant-directivity horn and compression driver; (3) a two-
way crossover network; (4) a vented enclosure.
The low-frequency transducer shall be a cone type loud-
speaker having a cone diameter of at least 15 inches
(380mm). It shall have a voice coil of at least 3 inches
(76mm) in diameter. It shall present a nominal load imped-
ance of 8Ω. Sensitivity shall be at least 99dB when measured
at 1m with an input of 1 Watt and have a power rating of at
least 250 Watts (AES), 1000 Watts peak.
The high-frequency section shall have a compression
driver with a diaphragm of at least 1.75 inches (44mm) in
diameter. It shall present a constant-impedance load of 8Ω.
It shall be connected to a constant-directivity horn having a
throat diameter of at least 1 inch (25mm) and a nominal cov-
erage pattern of 90° horizontal by 70° vertical. Sensitivity
shall be at least 107dB when measured at 1m with an input
of 1 Watt and have a power rating of at least 35 Watts (AES),
140 Watts peak.
The system shall be crossed over by an internal, high-
level, passive network having a response of 12dB/octave.
The nominal crossover frequency shall be 1.7kHz. The low-
pass section of the network shall have minimum inductance
in series with the low-frequency driver. The high-pass section
of the network shall be equalized to optimize the perform-
ance of the constant-directivity horn. A dynamic high-fre-
quency protection circuit based on a low-value, low-mass fila-
ment resistor shall limit the current available to the compres-
sion driver. A connection option shall be provided to discon-
nect the crossover network, but not the high-frequency pro-
tection circuit, from the drivers to allow bi-amp operation.
Connections to the loudspeaker shall be Speakon
connectors.
The enclosure shall be a vented design with an internal
volume of at least 2.57 cu. ft. and a vent tuning of 50Hz. It
shall be constructed using 0.75 inch (19mm), void-free birch
plywood and finished with black, scratch-resistant paint. It
shall be trapezoidal shaped with 15° angled sides. A full
size, detachable, perforated steel grille, finished in black
scratch-resistant paint shall be provided. At least 10 rein-
forced threaded metal sockets (M10) for attaching mounting
www.mackieindustrial.com
16220 Wood-Red Rd. NE, Woodinville, WA 98072 USA
888.337.7404, fax 425.487.4337, industrial@mackie.com
UK
+44.1268.571.212, fax +44.1268.570.809, info@rcf-uk.com
+39.0522.354.111, fax +39.0522.926.208, industrial@rcf.it
ITALY
FRANCE
+33.3.8546.9160, fax +33.3.8546.9161, rcf.commercial@wanadoo.fr
GERMANY
+49.2572.96042.0, fax +49.2572.96042.10, industrial@mackie.de
(continued Architects' & Engineers' Specs)
hardware, three eye bolts and two hand-carry locations shall
also be provided. The overall dimensions of the enclosure
shall not exceed 27.44 x 17.9 x 16.93 inches (697mm x
455mm x 430mm).
The performance of the two-way loudspeaker system shall
be as follows: long-term power handling, at least 300 Watts
RMS; peak power handling, at least 1200 Watts; frequency
response, 80Hz–18kHz at –3dB; maximum SPL, 130dB (ane-
choic–1m); sensitivity, 97dB SPL (1W/1m anechoic); –6dB
coverage, measured average 2kHz–16kHz, 90° horizontal by
70° vertical. The two-way loudspeaker system shall be a
model PA151 manufactured by Mackie Industrial.
®
