Linksys WPG54G Quick Installation

®
A Division of Cisco Systems, Inc.
Package Contents
• Wireless-G Presentation Player
• Setup CD-ROM
• User Guide on CD-ROM
• Remote Control with built-in laser pointer (two
AAA batteries included)
• Adapter Stands
• Power Supply
• Quick Installation
• Registration Card
2.4
GHz
Wireless-G
802.11g
Presentation Player
Wireless Quick Installation
Model No.
Model No. WPG54G
1
Connecting the Presentation Player
A
Connect the VGA cable from
your monitor or projector to the
Presentation Player's Monitor/
Projector port.
B
Make sure the Presentation
Player is turned off. Plug the
supplied power adapter into
the jack on the Presentation
Player's back panel. Then plug
the other end into a power out-
let (surge protection recom- A
mended). Turn on the
Presentation Player.
C
To have a wired connection,
connect one end of the Cate-
gory 5 Ethernet network cable
to your PC's Ethernet adapter.
Connect the other end to the
Ethernet port on the back of
the Presentation Player.
B
D
For a wireless connection, fix
the direction of the antenna.
Place the antenna perpendic-
ular to the ground.
E
Place the Player near the mon-
itor or projector facing the pre-
senters so that the infra red in
the remote control will be in
C
line of sight to the Player.
Proceed to Step 2.
2
Installing the Control Utility
The Presentation Player can play from
any PC in your wired or wireless net-
work. Install the Control Utility in each
PC that will use the Presentation
Player.
A
Insert the Setup CD-ROM into
your CD-ROM drive. The Setup
Wizard should start automati-
cally, and the Welcome screen
should appear. If it does not,
click the Start button, and
select Run. Then enter
d:\setup.exe in the Open field (if
"D" is the letter of your CD-ROM
drive).
B
Click the Setup tab.
B
C
After reading the License Agree-
ment, click Yes.
C
D
The Choose Destination Loca-
tion screen will appear. If you
want to change the location
where the Control Utility will be
installed, click Browse, and
select another location. Click
the Next button to continue.
D
E
The wizard will now be ready to
begin copying the program
files.
E
F
After the files have been suc-
cessfully copied, click the Exit
button.
The Control Utility is successfully
installed. Proceed to Step 3 to use
the Control Utility.
F
