Linksys WRT54G Product Data

Linksys WRT54G Product Data

Wireless-g broadband router
Hide thumbs Also See for WRT54G:
1
2
3

Advertisement

Quick Links

Download this manual See also: User Manual
The All-In-One Wireless-G
Networking Solution
Wireless-G
Broadband Router
WRT54G
Model No:
PRODUCT DATA
All-in-one Internet-sharing Router,
4-port Switch, and Wireless-G
(802.11g) Access Point
Shares a single Internet
connection and other resources
with Ethernet wired and Wireless-
G and -B devices
Push button setup feature makes
wireless configuration secure and
simple
High security: Wi-Fi Protected
Access™ 2 (WPA2), wireless MAC
address filtering, powerful SPI
firewall

Advertisement

loading

Related Manuals for Linksys WRT54G

Summary of Contents for Linksys WRT54G

  • Page 1 The All-In-One Wireless-G Networking Solution Wireless-G Broadband Router WRT54G Model No: PRODUCT DATA All-in-one Internet-sharing Router, 4-port Switch, and Wireless-G (802.11g) Access Point Shares a single Internet connection and other resources with Ethernet wired and Wireless- G and -B devices Push button setup feature makes wireless configuration secure and simple High security: Wi-Fi Protected Access™ 2 (WPA2), wireless MAC address filtering, powerful SPI firewall...
  • Page 2 802.11b (2.4GHz) Standards • Unsurpassed Wireless Security with Wi-Fi Protected Access™ 2 (WPA2) • Enhanced Internet Security Management Functions including Internet Access Policies with Time Schedules • All LAN Ports Support Auto- Crossover (MDI/MDI-X) - No Need for Crossover Cables • SecureEasySetup push button makes it easy to configure your wireless devices Wireless-G Broadband Router The Linksys Wireless-G Broadband Router is really three devices in one box. First, there’s the Wireless Access Point, which lets you connect both screaming fast Wireless- G (802.11g at 54Mbps) and Wireless-B (802.11b at 11Mbps) devices to the network. There’s also a built-in 4-port full-duplex 10/100 Switch to connect your wired-Ethernet devices together. Connect four PCs directly, or attach more hubs and switches to create as big a network as you need. Finally, the Router function ties it all together and lets your whole network share a high-speed cable or DSL Internet connection. Once your computers are connected to the Router and the Internet, they can communicate with each other too, sharing resources and files. All your computers can print on a shared printer connected anywhere in the house. And your computers can share all kinds of files—music, digital pictures, and documents. Keep all your digital music on one computer, and listen to it anywhere in the house. Organize all of your family’s digital pictures in one place, to simplify finding the ones you want, and easing backup to CD-R. Utilize extra free space on one computer when another’s hard drive starts to fill up. The new push button setup feature makes it easy to configure your wireless devices. Just push the button on the router and on your other SecureEasySetup-enabled wireless device to automatically create an encryption-secured wireless connection. Wi-Fi Protected Access™ 2 (WPA2) protects your data and privacy with up to 128-bit industrial-strength encryption. The Router can serve as a DHCP Server, has a powerful...

  • Page 3: Specifications

    A Division of Cisco Systems, Inc. 121 Theory Irvine, CA 92617 USA E-mail: sales@linksys.com support@linksys.com Web: www.linksys.com Linksys products are available in more than 50 countries, supported by 12 Linksys Regional Offices throughout the world. For a complete list of local Linksys Sales and Technical Support contacts, visit our worldwide website at www.linksys.com Wireless-G Broadband Router Specifications Model WRT54G Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11g, IEEE 802.11b Channels 11 Channels (US, Canada) 13 Channels (Europe, Japan) Ports/Buttons Internet: One 10/100 RJ-45 Port LAN: Four 10/100 RJ-45 Switched Ports One Power Port One Reset Button One SecureEasySetup Button Cabling Type CAT 5 LEDs Power, DMZ, WLAN, LAN (1, 2, 3, 4), Internet,...
