Linksys EF3512 Specifications

EtherFast ® 12-Port Gigabit Ethernet Switch
Model No.: EF3512
Benefits
Benefits
• Twelve 10/100/1000Mbps, half/full duplex,
switched ports
• Forwards and filters packets at non-blocking,
full wire speed
• All ports have auto speed negotiation and
MDI/MDI-X
• Supports address learning and aging, 802.3x
flow control and head-of-line blocking preven-
tion
Instant Wireless
EtherFast
Gigabit Ethernet Switch
Wire-speed switching and Linksys reliability
in an 12-port Gigabit switch
he EtherFast ® 12-Port Gigabit Ethernet Switch takes your
T
network to a whole new level of productivity—and does it
using your existing architecture. There's no need to aban-
don your present equipment or radically change your way of
doing things. This switch from Linksys allows you to do what you
already do—only faster!
Apply this switching power to your current Ethernet network, and
your data traffic efficiency will improve several times over.
Connect your Gigabit-equipped workstations to the Switch's
10/100/1000 ports for full-duplex, dedicated bandwidth of up to
1000Mbps!
With the EtherFast 12-Port Gigabit Ethernet Switch, you can con-
nect your existing 10/100 Ethernet network to your Gigabit net-
work backbone without any additional equipment. All ports are
auto-negotiating, and have auto MDI/MDI-X. Address learning
and aging is supported, as well as 802.3x flow control with head-
of-line blocking prevention to keep your high-speed clients from
bogging down in low-speed traffic.
The EtherFast 12-Port Gigabit Ethernet Switch from Linksys is the
all-in-one solution for your Gigabit and 10/100 networking needs.
Features
Features
• 12 10/100/1000Mbps auto MDI/MDI-X RJ-45 ports
• Full wire speed reception and transmission
• Integrated address look-up engine, support for up to 32K
MAC addresses
• Head of Line (HOL) blocking prevention
• All ports support Auto MDI/MDI-X
• Rack mounting hardware included for easily rack mounting
the switch
®
Series
®
12-Port
