- Page 1 /RDS-TFT2HE, /RDS-TFT2HE, /RDS-TFT3HE /RDS-TFT3HE & /RDS-TFT4 & /RDS-TFT4HE USER MANUAL Additional Manual for TEX-TFT series Manufactured by R.V.R ELETTRONICA Italy...
- Page 2 Editor 01/02/2022 First edition J. H. Berti /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE - User Manual Version 1.0 © Copyright 2022 R.V.R. Elettronica Via del Fonditore 2/2c - 40138 - Bologna (Italia) Phone: +39 051 6010506 Fax: +39 051 6011104 Email: info@rvr.it Web: www.rvr.it...
-
Page 3: Table Of Contents
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA Table of Contents Introduction Main Highlights RDS System Description Software 2. Technical Specifications 3. Physical Description Board Layout 4. Installation and Setting-up Preparation Connections 5. WINRDS+ Software Introduction WINRDS+ Application RDS Devices 6. Software Description WINRDS+ opening application Opening a saved document Saving document 6.4 PC ◄► RDS Data Transfer Setting of Serial ports of equipment... - Page 4 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA This page was intentionally left blank User Manual Rev. 1.0 - 01/02/22...
-
Page 5: Introduction
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 1. Introduction 1.1 Main Highlights • The RDS encoder is made with full digital technology capable to generating a very high quality of modulation and of spectral purity. • It supports all popular services including TMC, TDC, IH and EWS. •... - Page 6 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA The pourpose of the /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE option is to manage the principal services defined by the standard CENELEC EN 50067 as: PI, PS, PTY, TP, AF, TA, DI, M/S, PIN, RT, EON, TDC, IH, CT. As follows, we’ll mention a short description about the function of each of these services.
- Page 7 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA EON - ENHANCED OTHER NETWORKS: it’s used to transmit the PI,PS,AF,PTY to the PIN of other radios. TDC - TRANSPARENT DATA CHANNEL: it’s used for the data transmission and it could be free used, for example, to send messages on a brighltly sign. IH - IN HOUSE APPLICATION: it’s used to transmit data of exclusive use of the broadcaster and it can be utilized , for example, to send telemetry data, software, etc...
-
Page 8: Software
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 1.3 Software The WINRDS+ software in kit (in italian and english language), on a CD-Rom supplied, allows actually to set 16 different RDS messages, each of 64 words and a maximum of 25 alternative frequencies; every message automatically starts at the hour of the day specificately preselected from the user. Moreover, it allows to manage all the services, which are listed in the foregoing section. All the /RDS-TFT2HE, /RDS-TFT3HE &... -
Page 9: Technical Specifications
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 2. Technical Specifications /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE Parameters U.M. Value GENERAL Standards Cenelec 50067 Specification Frequency 57 +/- 0,3Hz (internal reference) Bandwidth +/- 2,4 (-50dB) RDS Output Level mVpp 2.200 Phase / Pilote Deg. Adjustable from 0 to 360 in 0.33 increments Connector IDC 10p Mas. -
Page 10: Physical Description
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 3. Physical Description 3.1 Board Layout [1] INPUT Connector for data exchange from the modulator panel board. [2] OUTPUT Connector for data exchange to the modulator panel board. [3] SERIAL Connector for data exchange to the RS232 connector on rear panel + RDS output + Pilot input. -
Page 11: Installation And Setting-Up
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 4. Installation and Setting-up 4.1 Preparation 4.1.1 Preliminary checks Provide for the following (applicable to operating tests and putting into service): √ Connection cable kit including: • Custom cable (included) to connect MPX/RDS and sync signals; • RS232 data cable (not included) for direct connection to PC in case of programming. - Page 12 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA RDS (RDS signal) always present in the back of the machine itself. If the connecting device is different, identify an equivalent. CUSTOM CABLE To SCA1/RDS To I C BUS or SERVICE/RDS To 19KHz PILOT OUT Note : For programming you need to connect it directly to a PC by using an RS232 cable or an USB-RS232 converter.
-
Page 13: Winrds+ Software Introduction
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 5. WINRDS+ Software Introduction 5.1 WINRDS+ Application WINRDS+ is an application based on documents, each document (file) represents a RDS system and contains all information relating to it. You can open multiple documents and communicate with several devices simultaneously, provided that each works towards a different serial, or you can have multiple devices on same serial port, provided that only one at a time is allowed to send. - Page 14 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA The users who need to see motion written on the car radio must use the window “PS Messages” that allows to have up to 8 sliding messages each long up to 128 characters or compound from 2 to 16 PS that rotating with personalized times. These messages, if enabled, are transmitted instead of PS within the PSN and do not depend on DNS enabled.
-
Page 15: Software Description
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6. Software Description 6.1 WINRDS+ opening application The usage of this application requires no installation process, it can be placed in any directory on your PC, even on the DESKTOP. To start the application: ► Double-click to opening with RDS EMPTY called RdsPlu1 and that the user must rename it if he wants to save. After launching the application in minimized window, it can be moved with the MOUSE all RDS documents (*. -
Page 16: Opening A Saved Document
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA The “UART communication Setting” section allows you to choose the PC serial port used to communicate with the devices and the speed communication from 1200 to 115200. The “Automatic” selection forces the program to groped all connections (1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200) seeking equipment connected. -
Page 17: Saving Document
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.3 Saving document To save the changes made to a document through the windows described below, you should use the drop-down menu “FILE►SAVE” / “FILE►SALVA”, or the “CTRL+S” combination, or the button on toolbar. 6.4 PC ◄► RDS Data Transfer The “LINK”... - Page 18 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA If the user sets a station (1-1023) or an equipment (1-63) address, or both, the messages will be created with the address and only the equipment that will recognize itself into address will accept the configuration and will answer. The addresses are used from subjected equipment in continuous data flow to recognize their own from those reserved for other devices.
- Page 19 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA You can also use the drop-down menu to select whether you want to transfer all selected data through custom or data blocks (for example update only the clock or only the hardware settings). Warning: when you read only a part of data from an equipment to edit themselves make sure you have the same selection when writing otherwise all selected parts before writing, but have not been read previously by the equipment, will have unpredictable values (or empty data with data from previous readings).
- Page 20 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA The “Read RDS” / “Leggi RDS” button is used to read all data on equipment and selected through “Custom” / “Personalizza” controls. The “Write RDS” / “Aggiorna RDS” button is used to write to the RAM of equipment all data present on document and selected through “Custom”...
-
Page 21: Setting Of Serial Ports Of Equipment
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA with the READ / WRITE buttons (see special features). When there is no connection with the equipment appears a special window that warns you of problem. The program tries several times before aborting the transfer in case of UDP protocol. -
Page 22: Special Functions - Serial Number
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.6 Special Functions - Serial Number The “Serial Number” button opens the connection to request the version but does not do any transfer. The operation result is visible in the appropriate window. This window contains two fields, the first is always filled with the descriptive version of device and the current firmware. The second field contains the serial number of single RDS card including version of hardware and software. -
Page 23: Special Functions - "Save Rds" - "Restore Rds
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.8 Special Functions - “Save RDS” - “Restore RDS” These two functions are active in certain cards only, use them on devices that do not have this function has no effect. All cards save data to buffered RAM, some cards allow you to use the button “Save RDS” t o photograph the RDS static data present on the buffered RAM in a dedicated flash bank memory. -
Page 24: Special Functions - Rds Clean
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.9 Special Functions - RDS cleaning The “Clear all RDS” / “Cancella tutto” button is used to delete all data and RDS configurations. This command has NO effect on the document, but it is executed by the equipment, and it is recommended when a SET-UP on the equipment is loaded for the first time so as to lose all present configurations before use “Write RDS” / “Aggiorna RDS”. After using this function, each device is bring back to original condition like at the exit of factory. -
Page 25: Special Functions - Windows Audio
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.11 Special Functions - Windows Audio The “Audio Windows” button adds in the active window a sheet for the management of audio functions. This function is not needed if the device is connected, because if it recognizes an equipment with audio functions during the connection adds automatically the correct sheet. -
Page 26: Special Functions - Windows Audio - Stereo
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.13 Special Functions - Windows Audio - Stereo The window audio changes depending on device connected, for the SDC2000 equipment is the following. The “Load Default Configuration” button allows you to upload all default settings and then change only the ones you want. The “Read/Write” for “Equipment”... - Page 27 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA The DI represents the characteristics of radio transmitted signal and the presence or absence of remote control of “TA” inside PTY. The PTY represents the characteristics of the Radio programming (eg. SPORT), if they are musical or spoken (active MS means music) and if it has the capacity to handle traffic information (active TP), and if in that moment is transmitting (active TA).
-
Page 28: Enabling Of Dns, Psn-Main And Psn-Eon
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.15 Enabling of DNS, PSN-MAIN and PSN-EON The window Enable PSN DNS is used to determine which DNS will be transmitted, and what EON are enabled to be transmitted. You can also activate in time, over 24 hours, 2 or more DNS. One of the active DNS should always have start time at 00:00 otherwise from 00:00 until the first time will be transmitted the DNS-1 (default DNS). -
Page 29: Insertion Of Radio Texts
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.16 Insertion of Radio Texts The “Radio Texts” window allows you to define up to 16 texts with a maximum length of 64 characters, which are broadcast from equipment on 2A and/or 2B groups. These messages are transmitted in order in which they are located and after the last message you start over again. The “Rip” attribute defines how many times a message is repeated before moving on to the next on list. The “type” parameter defines how the radio will process the message, or if it is defined as type “A” the radio will write a new message over the old one without deleting it and if it is of type “B” radio delete the previous message and write the new one. The difference... -
Page 30: Insertion Of Frequency List
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.17 Insertion of Frequency List When an issuer has more frequencies on which transmits should fill one or more lists in order to provide all the frequencies to listening radio. This program allows you to fill up to a maximum of 100 lists of 25 type “A” frequencies or up to 100 lists of 12 type “B” frequencies for each of the DNS. Alternative frequencies are managed with the “Alternative Frequencies Main PSN” window. To edit or to view a detailed list of frequencies make DOUBLE CLICK with mouse on the list, to create a new one please scroll the list until the end and then make DOUBLE CLICK below the last list available. -
Page 31: Insertion Of Eon Frequencies List
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA To create a type “B” list select a frequency in the range “list header type B”, making sure that only the first 12 frequencies of the list enter in a list of type B against the 25 frequencies of a type A list. 6.18 Insertion of EON frequencies list Each EON can have its own frequencies list that will be sent on 14A and/or 14B groups. As opposed to alternative frequencies of Main-PSN, these are mapped and so this software allows you to compile long lists up to 100 bytes or rather 33 couples of frequencies. -
Page 32: Ps Messages
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA If you enable the EON transmission that no have alternative frequencies, the equipment will transmit at least the information relating to the name, PI-EON and PTY. 6.19 PS messages The RDS equipments can handle 8 long messages that will scroll on display of car radio in a linear manner (sliding) or in groups of 8 characters (A Blocks). - Page 33 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA Pressing the “EDIT” / “CAMBIA” button, when is selected a scrolling message, opens the editing window for scrolling messages that contain a section of free text to write your own message long up to 128 characters. The repetitions Field determines the persistence of the message between one shift and the next, the minimum acceptable value is 1, the maximum is 59. Press O.K. to confirm the update or press “CANCEL” to keep the old message. The DNS field acts only...
-
Page 34: Transmission Groups
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 6.20 Transmission Groups Each DNS can transmit the RDS groups in a personalized way. Advanced users can create their own sequence using the Manual Configuration section. With the “EMPTY LIST” button you delete all groups. With the “DELETE” button you remove the selected group from the list. - Page 35 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA The Address section allows you to assign an identification number of the position in which it will be installed (1-1023) and an identification number of the equipment itself (1-63). This allows to the RDS to recognize only the messages for all and those addressed to him personally. If a device is configured as a Site=9 and equipment=5 it will be recognized itslef on 4 addresses. Address 1: Site = 0 Equipment = 0 Address 2: Site = 9 Equipment = 0 Address 3: Site = 0 Equipment = 5 Address 4: Site = 9 Equipment = 5 The R.T.C. section allows you to set the time and enable the clock transmission through the 4A groups to minute change.
- Page 36 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA Some equipment has the management of state on TMC, that is an alarm that can be read and set via UECP protocol. The time defines after how many minutes without TMC flow must intervene the alarm status. The state, however, shows if in the last minute are transmitted, or not, the 8A and 3A groups and if the alarm has expired. TMC OFF: groups not transmitted with TIMEOUT not set TMC run: 8A and 3A groups transmitted with TIMEOUT not set...
-
Page 37: Technical Annex
/RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA 7. Technical Annex 7.1 RDS board - RDS4003KIT User Manual / 34 Rev. 1.0 - 01/02/22... - Page 38 /RDS-TFT2HE, /RDS-TFT3HE & /RDS-TFT4HE ELETTRONICA / 34 User Manual Rev. 1.0 - 01/02/22...
- Page 39 ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________...
- Page 40 R.V.R Elettronica Via del Fonditore, 2 / 2c Zona Industriale Roveri · 40138 Bologna · Italy Phone: +39 051 6010506 · Fax: +39 051 6011104 e-mail: info@rvr.it ·web: http://www.rvr.it The RVR Logo, and others referenced RVR products and services are trademarks of RVR Elettronica in Italy, other countries or both. RVR ® 1998 all rights reserved. All other trademarks, trade names or logos used are property of their respective owners.
