Honeywell Central Hub Quick Reference Manual

Connecting the Gas Detector to HCH
1. Turn on the Honeywell Central Hub (HCH).
2. Connect the HCH and laptop or PC by a network cable.
3. Open Microsoft Edge browser and input the login URL, user name and
password on product label.
• Login: https://169.254.100.1
• User Name: hch300admin
• Password: Hon123%&
4. Set PAN ID and Channel on HCH on the tab "RF Configuration".
5. The Gas Detector should be set to the same PAN ID and Channel. You
can find the gas detectors on the tab "Device Information"
6. Use one of the three available uplink approaches (Ethernet, Wi-Fi, or
LTE) if you want to connect to Honeywell Safety Suite
For more operation details see the HCH User Manual.
Specifications
Dimensions 129x 45 x 193mm
Weight 950g (instrument)
1700g (with accesories and package)
Voltage DC12~24V/0.5A
USB-C USB port, slave mode, Power Input port, DC5V2A
Antennas GPS, LTE-D, LTE-M, Wi-Fi 2.4GHz
QRG PN: 3008-5854-001
ENGLISH, Revision A
© 2022, May 19th
What's in the Box
• 1 HCH300 instrument. • 1 LoRa antenna.
• 1 LTE antenna. • 1 Wi-Fi antenna.
• 1 network cable for configuration. • 1 power adapter.
• 1 copy of QRG manual. • Mounting bracket DIN.
Proper Product Disposal At End Of Life
The Waste Electrical and Electronic Equipment (WEEE) directive
(2012/19/EU) is intended to promote recycling of electrical and electronic
equipment and their components at end of life. This symbol (crossed/out
wheeled bin) indicates separate collection of waste electrical and electronic
equipment in the EU countries. This product may contain one or more
Nickel-metal hydride (NiMH), Lithium/ion, or Alkaline batteries. Batteries
must be recycled or disposed of properly.
At the end of its life, this product must undergo separate collection and
recycling from general or household waste. Please use the return and
collection system available in your country for the disposal of this product.
Contact Us
Honeywell
700 Mint St.
Charlotte, NC 28202, USA
For BW contact:
For RAE contact:
Phone : +1 800 538 0363
Phone : +1 888 749 8878
rae-callcenter@honeywell.com detectgas@honeywell.com
Software Support
US&C
Email: support.safetysuite@honeywell.com
Phone: +1 833 556 3515 Manuals and other
EMEA
information about this
Email: gastechsupportemea@honeywell.com
product are available at:
Phone: 0080081819691
https://sps.honeywell.com
QUICK
REFERENCE
GUIDE
Honeywell Central Hub
Wireless Gas Monitor Connector
