HANDY COOLER HC-7717 Instructions

First Ever Personal Hand Held Air Cooler
INSTRUCTIONS
HC-7717 version 2.12
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
SAVE THESE INSTRUCTIONS.
Product Description
Output Air Vent
Rotatable Duct
Power Control
Hand Strap Connector
Installing the batteries
-
The battery compartment is located on the handle, behind the
hand strap.
1) To remove, slide the battery cover down.
2) Install four new AA alkaline batteries.
3) Replace the battery cover.
Battery Cover
slide down
1
Installing the cooling filter
-
1) Turn the unit OFF.
2) Remove the filter cover together with the cooling filter by
pushing on the top lever and pulling outwards.
THEN PULL
OUT
Filter Cover
Filter Cover
(Air Inlet Grill)
3) (FIRST TIME USE: Remove filter from cover. Soak the
cooling filter under tap water and massage thoroughly with
USB Adaptor
soap. Treat this sponge-material filter with care. Do not apply
Input
vigorous force while washing.)
4) If residual water from previous applications remain on the
filter: remove the filter from the cover, then squeeze out any
Battery Compartment
residual water from the cooling filter.
5) With the cooling filter placed on the cover lying flat as
depicted below; fill water bottle included with either tap,
distilled or mineral water; then pour 30ML EVENLY and
SLOWLY throughout the surface.
Cooling Filter
PRESS DOWN
Cooling Filter
Pour 30ML
evenly and slowly
Filter Cover
2
6) Replace the filter cover together with the filter by inserting
with bottom pivot first, then pushing the cover towards the
main unit to lock close.
THEN PUSH TO CLOSE
Filter Cover
Cooling Filter
SLIDE BOTTOM FIRST
Note: Do not over-soak the cooling filter. Do not soak under
running tap water. It is difficult soak accurately 30ML of water.
Always use the water bottle.
Note: The unit is not waterproof. Avoid external water contact.
Note: If water leakage is experienced during operation, you have
poured too much water into the filter (see step 5); or you have
not squeezed out excessive water properly before soaking the
filter (see step 4).
3
