VOLUME: Adjust volume
TREBLE: Adjust treble
BASS: Adjust bass
MIC VOL: Adjust microphone volume
ECHO: Adjust echo
MIC INPUT: Wired microphone input
This system can be used with PC, DVD, VCD, MP3, Electronic Piano, Radio and any device with audio output.
The amplifying circuit is designed with high performance and high fidelity, and equipped with professional and high quality speaker, it can make the sound field positioning clear and layered.
The system voice effect is outstanding, the bass is surging and shocking, the middle tone is strong and bright, the treble is crisp and pleasant.
Professional electronic frequency division circuit, so that the division point of the machine more accurate, better effect.
The use of professional design and manufacture of large capacity batteries, as well as audio power supply capacitor makes the local power reserve margin more larger, more stable, better dynamic, higher SNR.
When charging, connect the supplied power adapter to AC 90V-240V~ for charging. The charging time should be 6 ~ 8 hours. After being fully charged, unplug the power supply to avoid damage to the battery due to long-term charging.
Battery level indicator: There is a battery level indicator on the display. When the battery power is low, the entire power indicator icon will flash, so please charge in time. When charging, the battery indicator icon will flash. After the flashing stops, the battery should continue to charge for 1 ~ 2 hours, which can prolong the battery life.
Note: If the battery is used out, please recharge the battery within 48 hours. Do not leave the empty battery for a long time, otherwise the battery will be damaged.
*Image diagram, for reference only
Guitar jack: Connect guitar.
Guitar Volume: Adjust the guitar volume.
Music files in USB and TF cards should be formatted as FAT32 on the computer.
The order about music play is based on file name, if the music file names are as "01,02,03"in sequence. This product will play the file "01"first.
Copy MP3 or WMA music files to USB/TF cards. It is recommended to delete unnecessary files and folders to speed up card reading and reduce card reading problems
*Image diagram, for reference only *Image diagram, for reference only
*Image diagram, for reference only
Please insert USB or TF card first and then press" ●/►" into recording mode. When recording music at the first time, an new file "RECORD" will be created in the card and all recordings will be saved into the file. These recording files are automatically named as"FILE0000, FILE0001......" in sequence. When recording music, press" ●/► "to puase it and press again to continue. Press"M" or" ●/► "to quit recording mode.
Please press " ●/► " into recording-play mode(automatically play the musics recording before). Usually the machine will play the last recording music first. Press PREV( |◄◄) or NEXT( ►►|) to select the music. Press Replay on the remote control to replay music. If you would like to replay single music or all musics, please press Replay repeatedly.
USB port: insert USB and play music.
TF port: insert TF card and play music.
Supports MP3, WMA, and WAV music formats, outstanding sound performance, high fax stereo design.
M: to switch external audio, MP3 / Bluetooth functions.
►||: press this key to pause the music, and press again to continue.
|◄◄ / ►►|: when playing, select the PREVIOUS/NEXT music.
Bluetooth connection method: Turn on the speaker, press the'M'key on the speaker panel, and the screen will show 'BLUE'.Use your phone to connect the Bluetooth of the speaker. The Bluetooth name is VS-0808.
If the connection fails, please restart the device or the phone and try again.
The use range of the Bluetooth is 32ft in the open area.
Common problems | Possible Cause | Solution |
There is no sound when power is on |
|
|
Distortion of sound |
|
|
Mic is silent |
|
|
MP3 is silent |
|
|
Output power: 250W
Input sensitivity: 500±30mV
SNR: ≥65dB
Frequency response: 26Hz~18KHz
Power supply: AC 90V-240V~
*Above specifications are the specifications of the sampling machine and are for reference purpose only.
*Because of continuous product improvement.specifications will keep changing at any time without prior notification.
