AV SELECTOR
SELECTEUR AV
SELECTOR AV
JX-S333
POWER
SOURCE
SELECT
1
2
3
4
DUBBING LOCK
LINK
(MONITOR SELECT)
INSTRUCTIONS
MANUEL D'INSTRUCTIONS
MANUAL DE INSTRUCCIONES
For Customer Use:
Enter below the Serial No. which is
located on the rear or bottom of
cabinet. Retain this information for
future reference.
Model No.
JX-S333
Serial No.
LNT0042-001A
Advertisement
Table of Contents
Related Manuals for JVC JX-S333-J
Summary of Contents for JVC JX-S333-J
- Page 1 AV SELECTOR SELECTEUR AV SELECTOR AV JX-S333 POWER SOURCE SELECT DUBBING LOCK LINK (MONITOR SELECT) INSTRUCTIONS MANUEL D’INSTRUCTIONS MANUAL DE INSTRUCCIONES For Customer Use: Enter below the Serial No. which is located on the rear or bottom of cabinet. Retain this information for future reference.
-
Page 2: Safety Information
1700 VALLEY ROAD, WAYNE, N.J. 07470 Telephone: (973) 315-5000 Thank you for purchasing this JVC product. Before you begin operating this unit, please read the instructions carefully to be sure you get the best possible performance. If you have any questions, consult your JVC dealer. -
Page 3: Table Of Contents
Contents INTRODUCTION BASIC OPERATION ADVANCED OPERATION OTHERS Check the contents Check the contents of the carton your JX-S333 came in. The following items should be found in the carton box: This unit (JX-S333) Registration card and Safety guide Safety Information ... 2 Check the contents ... -
Page 4: Major Features
Major Features • Video signal converter (S-video to component video signals) is incorporated. • Various input/output connectors—four input connectors (S-video/component video), two output connectors (S-video), and one monitor output (S-video/component video) give you the centralized management of your home theater system. •... -
Page 5: System Configuration Example
System Configuration Example The AV Selector Expands the The AV Selector Expands the Dimensions of the AV World. Dimensions of the AV World. Recording components VCRs (S-VHS/VHS) DVD player Playback components DVD recorder DBS tuner POWER AV receiver Projector TV monitor... -
Page 6: Connectors, Controls And Indicators
Connectors, Controls and Indicators Front View STANDBY/ON button Press to turn the power ON or OFF (in standby mode). STANDBY/ON indicator This indicator lights in green when the power is ON, while it lights in red when the power is OFF (in standby mode). If the power has been switched OFF to the Standby mode and then ON again, it can be operated using the same settings... - Page 7 Rear view INPUT connectors (INPUT Equipped with S-VIDEO/component video (Y, Cb/Pb, Cr/ Pr)/AUDIO. Connect to the output connectors of the playback components (up to four components). Incoming S-video signals can be converted and emitted through the component video output of the MONITOR OUT connectors.
- Page 8 Connectors Controls, and Indicators (Remote Control Unit) Remote Control Unit POWER button Press to turn the power ON or OFF (in standby mode). SOURCE SELECT buttons Press to select an input component. ☞ DUBBING LOCK button (MONITOR SELECT) Press to fix the output signals through the OUTPUT 1 and 2 connectors.
-
Page 9: Using The Remote Control Unit
— (“AA”-size (R6/UM-3) batteries. • JVC uses two types of the remote control signal code for operating the AV selector—A and B. This remote control unit can transmit B code signals. -
Page 10: Watching Video
Watching Video Do not connect the AC power cord until all other connections have been made. Connect a VCR to INPUT • This shows an example of several possible connections. Also refer to the instruction books of the other components you are using for operation and connection details. - Page 11 POWER SOURCE Turning the power on SELECT Selecting a VCR DUBBING LOCK LINK (MONITOR SELECT) • When you want to watch a video on another VCR, press the SOURCE SELECT button to select the line number that the VCR is connected to. •...
-
Page 12: Dubbing (Multi-Dubbing)
Dubbing (Multi-dubbing) Do not connect the AC power cord until all other connections have been made. You can dub a video program from VCR 1 to VCR 2 and vice versa. This shows an example of several possible connections. Also refer to the instruction books of the other components you are using for operation and connection details. - Page 13 • Turn on the power to the JX-S333. • Turn on the TV monitor and select the input connected to the MONITOR OUT connectors on the JX-S333. Preparation • Turn on the power to VCRs to prepare for dubbing. POWER SOURCE SELECT Selecting VCR 1...
-
Page 14: Watching A Video Program While Recording Another One (Dubbing Lock)
Watching a Video Program While Recording Another One Do not connect the AC power cord until all other connections have been made. Connect the playback VCR (VCR 1) to the INPUT 1, and the recording VCR (VCR 2) to the OUTPUT 2. - Page 15 • Turn on the power to the JX-S333. • Turn on the TV monitor and select the input connected to the MONITOR OUT connectors on the JX-S333. Preparation • Turn on the power to all other connected components. POWER SOURCE SELECT Selecting VCR 1 Selecting DBS tuner...
-
Page 16: Centralized Management Of Your Home Theater System
Centralized Management of Your Home Theater System Do not connect the AC power cord until all other connections have been made. You can watch the DVD playback picture through your home theater system while dubbing the tapes on the VCRs. This shows an example of several possible connections. - Page 17 • Turn on the power to the JX-S333. • Turn on the TV monitor and select the input connected to the MONITOR OUT connectors on the JX-S333. Preparation • Turn on the power to all other connected components. POWER SOURCE SELECT Selecting VCR 1 Selecting DVD player...
-
Page 18: Useful Tips
Useful Tips S-VIDEO input/output connectors • The S-VIDEO input/output connectors are those for the Y/C (luminance/chrominance) separate video signals. Component connectors • Component connection is recommended when connecting a DVD player or DBS tuner (equipped with component input connectors) to a TV monitor. Since a DVD disc is encoded with a component video (Y color difference) signal format it can reproduce better quality color than the composite or S-video signal used in... -
Page 19: Dubbing Lock Function
DUBBING LOCK function • DUBBING LOCK button Provides the dubbing lock function for prevention of accidental operational mistakes as well as a monitor select function for watching a video program while recording another. Dubbing lock function When the DUBBING LOCK button is pressed while the VCR for recording is in use, the POWER ( LINK buttons are disabled. -
Page 20: Link Function
Useful Tips (continued) LINK function • Using the LINK function, you can turn on and off the power to the JX-S333 by detecting the incoming S-video signals. Therefore, it is not required to turn on the power to the JX-S333 manually. -
Page 21: Block Diagram
Block Diagram... -
Page 22: Troubleshooting
Troubleshooting • The JX-S333 incorporates a microcomputer, which may malfunction due to external interference or noise. If this trouble cannot be resolved by checking the items in the following table, reset the microcomputer by turning off the JX-S333, unplugging its power cord from the wall outlet, plug- ging it in again and then checking the operation. - Page 23 Symptom Watching No picture displayed •Is the SOURCE SELECT button for on TV monitor. the source component selected correctly? •Is the TV monitor connected properly to the MONITOR OUT connector? •Is the TV monitor’s input selector set correctly? No picture displayed •...
-
Page 24: Specifications
Specifications Design and specifications subject to change without notice. Product name AV selector Input/output connectors Inputs: Outputs: Monitor outputs: Reference level Video inputs • S-VIDEO Y: • Component signals Maximum input • S-VIDEO V: • Component signals Video outputs • S-VIDEO Y: (Reference level) •... -
Page 25: Glossary / Index
Glossary / Index Multi-dubbing Capability of using more than one VCR for dubbing by selecting any of them as the player and recorder. S-VIDEO signal Signal obtained by separating the composite video signal into the luminance and chrominance signals. This makes the video clearer with fewer blurs in the colors. - Page 26 © 2005 Victor Company of Japan, Limited Printed in Japan...
