Sony KDS-50A3000 Service Manual

Sp-4 chassis
Hide thumbs Also See for KDS-50A3000:
Table of Contents

Advertisement

Quick Links

Download this manual
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME
KDS-50A3000
KDS-55A3000
KDS-60A3000
ORIGINAL MANUAL ISSUE DATE: 8/2007
: UPDATED ITEM
REVISION DATE
SUBJECT
8/2007
No revisions or updates are applicable at this time.
8/2007
Added Optional Colored Speaker Grille P/N's information. Replaced Page 115.
9/2007
Updated Self-Diagnostic information. Replaced page 8-9.
Corrected information in Disassembly section, Replace pages 10 -16.
Corrected PN for Power Supply and added PN for Plug Holder. Replaced page 67.
10/2007
Updated TOC to add Appendix C: HV Cable Removal. Replaced page 3.
Updated Disassembly section to include HV Cable Removal instructions. Replaced page 13.
Updated illustration to show HV Plug Holder. Replaced page 67.
Added Appendix C: HV Cable Removal.
9-883-759-04
REMOTE COMMANDER
RM-YD016
RM-YD016
RM-YD016
SXRD PROJECTION TELEVISION
SP-4
DESTINATION
US/CND
US/CND
US/CND
CHASSIS
