ECCO SAFETY GROUP Code 3 HB12PAK Series Installation And Operation Instructions Manual

IMPORTANT!
Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
!
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/or death to
those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety information
contained
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to ensure
the safety of you and those you are seeking to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that output performance of the
system is maximized and the controls are placed within convenient reach of the operator so that s/he can operate the system without losing
eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag deployment
area may reduce the effectiveness of the air bag or become a projectile that could cause serious personal injury or death. Refer to the
vehicle owner's manual for the air bag deployment area. It is the responsibility of the user/operator to determine a suitable mounting location
ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors), people,
vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning signal. Never take the right-
of-way for granted. It is your responsibility to be sure you can proceed safely before entering an intersection, driving against traffic, respond-
ing at a high rate of speed, or walking on or around traffic lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws regarding
warning signal devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The manufacturer as-
sumes no liability for any loss resulting from the use of this warning device.
Specifications:
Size: 0.99" dia. (lighthead only)
Input Voltage: 12-24 VDC
Maximum Current Draw:
Single Color:
Dual Color:
Important! This unit is a safety device, and it must be connected to its own separate, fused power point to assure its continued operation should any other
electrical accessory fail.
1.06 A (Red, steady on)
1.24 A (Blue, steady on)
1.30 A (Amber, steady on)
1.27 A (White, steady on)
0.61 A (AW, Amber steady on)
0.81 A (AW, White steady on)
0.59 A (BR, Red steady on & Blue
steady on)
Installation and Operation Instructions
HB12PAK SERIES
Maximum Power:
Single Color:
Dual Color:
Operating Temperature Range: -40° to 70°C
Lumens:
Dual Amber - 130 lm
Dual Blue - 39.1 lm
Dual Red - 64.5 lm
Dual White - 99.7 lm
Single Amber - 226.2 lm
Single Blue - 49.4 lm
Single Red - 84.32 lm
Single White - 209.8 lm
13.57 W (Red, steady on)
15.87 W (Blue, steady on)
16.64 W (Amber, steady on)
16.26 W (White, steady on)
7.81 W (AW, Amber steady on)
10.37 W (AW, White steady on)
7.55 W (BR, Red steady on & Blue steady on)
Page 1 of 4
