- Page 1 Base Node Installation Guide vIG_BN_2022-07 PN: 18-0007-001 Rev. 1.0 Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 0...
-
Page 2: Table Of Contents
............................... 34 OUNT RACKET SSEMBLY OOLS DC D DCOD 48-5 ........... 34 ............................19 OUNTING ......................... 20 PECIFICATIONS FOR RANSTECTOR EFENDER ............................. 34 OUNTING THE RACKET ARDWARE Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 1... - Page 3 BN 5GHz G1-BN5ASI002 BN CBRS (Cat B) G1-BN3ASI001 Note: Please download the latest version of this document at: www.taranawireless.com/bn_manual For other documentation and videos, see: https://www.taranawireless.com/support/#documentation Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 2...
-
Page 4: Safety And Warnings
Safety and Warnings Tarana G1 equipment is designed for installation and use by trained professionals and requires adherence to all relevant regulatory, safety, and telecom industry best practice guidelines for outdoor radios. General Warnings Failure to observe these safety precautions may result in personal injury or damage to equipment. -
Page 5: Eneral Ealth And Afety Nformation
LIFTING. Flammability The equipment is designed and constructed to The Tarana BN weighs ~20 kg (~42 lbs.). minimize the risk of smoke and fumes during a Use proper lifting techniques for lifting heavy equipment. Be sure to follow all fire. -
Page 6: Ealth And Afety Arning
Tout réglage ou modification faits à cet équipement hors du cadre édicté par ce guide d’utilisation ou par toute autre documentation supplémentaire pourraient causer des blessures ou endommager l’équipement et peut entraîner l’annulation de sa garantie. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 5... -
Page 7: General Hazards
RF signals. The maximum • Considerations ambient temperature applies to the immediate operating environment of the G1 product. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 6... - Page 8 Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 7...
-
Page 9: Preparation
BN Mounting Kit Contents: (4) M8 bolts: 1.25 x 120 mm Preparation Important: Tarana recommends that the BN be powered and get an initial (4) M8 bolts: 1.25 x 80 mm configuration prior to being mounted on the tower. -
Page 10: Ardware And Upplied It
Surge Protectors: Two models of DC Defender surge protectors are available. Model 1101-1027-KT (item B) should be used when the cable size used to power the BN is larger than 10AWG. A. DC Defender (DC Surge Protector) w/Mounting Kit: 1101-1110-KT B. -
Page 11: Powering The Bn
Important: Tarana recommends that the BN be powered and get an initial configuration prior to being mounted on the tower. The BN requires power and a connection on a data port for Tarana Cloud Suite (TCS) operation. The voltage required is -48 VDC supplied on the Harting power connector through the power port only. -
Page 12: Initial Configuration
Note: Using a standard Ethernet cable in this port will make removing the cable difficult and could damage the port. Harting Ethernet cable assemblies for this purpose are available through Tarana. Upon receiving power, the BN will undergo the booting and initialization process for a period of 5-7 minutes. There are a set of LEDs on the bottom edge of the BN that will cycle through patterns and colors during this time. - Page 13 DATA1 and DATA2 are optical SFP+ interfaces. Devices connected to these data ports must support SFP+ (10Gbps) or the ports will not come up. Tarana offers an industrial- temperature SFP+ module for data connection at the BN on the tower. This SFP+ module is MEF certified with an extended temperature range of -40 to +85°C. DATA3 is a copper interface and only supports 1Gbps.
-
Page 14: Configuration
G1 Administrator’s Guide. Enter the default login and password of “admin” and “admin123”, respectively. This will bring up the BN’s web interface. Enter the default IP gateway. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 13... - Page 15 Configuration settings in TCS will overwrite web UI settings. To avoid confusion or incorrect settings being applied, use TCS for configuration once the device is registered and connected to TCS. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 14...
-
Page 16: Mgmt P
Note: For safety, the radios are muted by default. After verifying functionality, mute the radios again until after the BN is installed on site. 2. Click “SAVE CONFIG”. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 15... -
Page 17: Tcs Confirmation
TCS Confirmation From the left column, click on Devices> List. To verify the BN is accessible from the Tarana Cloud Suite (TCS), use an Internet Verify that “BN” is selected from the RN/BN switch. connection external to the BN. Finally, verify the BN is online as indicated by its Serial Number being in Note: The BN communicates to the TCS across Data Port 1, 2, or 3. - Page 18 Unassigned folder. The BN must be assigned to a Sector before an RN will associate to it. For more information on Network Configuration, see the G1 Admin Guide. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 17...
-
Page 19: Physical Installation
The maximum load on the lifting eye is 100 lbs. (45 Kg). anti-seize, dry film coating. There is no need to apply anti-seize lubricant to these fasteners. Figure 3: BN Mounting Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 18... -
Page 20: Ole
Gradually engage (4) bolts ensuring clamp halves stay parallel to each other and are spaced evenly on either side of the clamp. Figure 4: Measure Pole Diameter Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 19... -
Page 21: Mounting The Bn To The Bracket
11 lb.-ft). • Figure 6: Twisted Bracket Ears Figure 5: Torque Sequence Figure 7: Aligned Ears in High-Tilt Position Mounting the BN to the Bracket Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 20... - Page 22 NOT between the BN and the bracket. Torque all 4 of these bolts using the same torque sequence demonstrated earlier. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 21...
- Page 23 Continue with the same sequence for all bolts at approximately 70% (10 N- m/ 7.4 lb.-ft). • Repeat the torque sequence for all bolts until each bolt is stabilized at 15 N- m/ 11 lb.-ft. • Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 22...
-
Page 24: Zimuth
• Repeat the torque sequence for all bolts until each bolt is stabilized at 15 N- m/ 11 lb.-ft. • Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 23... - Page 25 Continue with the same sequence for all bolts at approximately 70% (10 N- • m/ 7.4 lb.-ft). • Repeat the torque sequence for all bolts until each bolt is stabilized at 15 N- m/ 11 lb.-ft. • Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 24...
-
Page 26: Power And Connectivity
Note: At this time, the Reset button should not be used. NOTE: “B" will replace all instances of "A" when the cable size used to power the BN is larger than 10AWG. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 25... -
Page 27: Grounding
BN mounting site. Install the Harting RJ45 pigtail assembly into MGMT Gigabit Ethernet of the BN for out-of-band management. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 26... - Page 28 At the end of this period, the LEDs will settle into one of a few common states as described below. For more information about LED behavior on G1 products, see the G1 Admin Guide. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 27...
-
Page 29: Bn Web Ui
IP address, a static address must be used for the out-of-band management address (if used). It is optional to assign in-band management traffic to a VLAN. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 28... -
Page 30: U Radios
TCS Confirmation Unmute Radios To verify the BN is accessible from Tarana Cloud Suite (TCS), use an Internet Click the “transmitting” icon in the upper right corner of the window. connection external to the BN. Note: This can be done from the NOC. - Page 31 From TCS, login to the BN’s Web UI. information if something is not working as expected. Note: This will require OP Admin rights. Log in to the BN Web UI Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 30...
-
Page 32: Appendix A: Dc Defender Installation (1101-1110-Kt)
This includes the DC Defender (PN 73-0025-001) and mounting kit (PN 48-0122-001) 1 Harting terminated DC cable for the Tarana node side of the DC Defender installation PN 33-0004-XXX (where XXX = length in meters) 1 DC cable for the power source side of the DC Defender installation (not... -
Page 33: Dc Cable Assembly
The complete DC Defender assembly with cover removed is shown below. performed on the ends of 2 DC cables - one connecting to the Tarana node, and the Note: The left two terminal lugs should be connected to the DC power source. The other connecting to the DC power source. - Page 34 Use minimum 8 AWG wire for a ground attachment. Install the DC Defender as close to the Tarana Base Node as possible. Mount the unit in the orientation shown, with the strain-reliefs facing the ground.
-
Page 35: Appendix B: Dc Defender Installation (1101-1027-2)
1 DC Defender 1101-1027-2 Pole mounting kit 1000-1702 1 Harting terminated DC cable for the Tarana node side of the DC Defender installation PN 33-0004-XXX (where XXX = length in meters) 1 DC cable for the power source side of the DC Defender installation (not... -
Page 36: Dc Cable Assembly
This cable assembly will be performed on the ends of 2 DC cables - one connecting to the Tarana node, and the other connecting to the DC power source. Strip the DC cable insulation to 1.4”. The drain, red, and black wires will be exposed. -
Page 37: Ssembly
Note: The left two terminal lugs should be connected to the DC power source. The right two terminal lugs should be connected to the Tarana node. Positive polarity The complete DC Defender DCOD 48-5 assembly with cover removed is shown on the pairs of terminal lugs is located on the left. -
Page 38: Dc Dole Efender Ount
#10 sized hardware. The mount foot also adapts to 4” diameter pole mounting kits with 4.5” center-to-center holes and larger hardware. Install the DC Defender as close to the Tarana Base Node as possible using the provided hardware and the concealed mounting holes. Mount the unit in the orientation shown, with the “UP”... -
Page 39: Appendix C: Cbrs Installations
Click on Installation Parameters. registration.trial.cloud.taranawireless.com:443 Enter your CPI-ID. Then click Confirm. Note: Check that the number entered is your CPI-ID and not your CPI Certificate number. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 38... - Page 40 After entering the BN installation parameters, verify that the BN is broadcasting, which is indicated by the Radio Control icon in the BN’s web Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 39...
-
Page 41: Cbrs Steps In Tcs
Network Configuration. Edit the Operator page to configure these parameters. Note: The FCC OR-ID is assigned to customers by the Spectrum Access System provider (Google or Federated Wireless). Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 40... - Page 42 SAS. If it were light green, this would indicate that the spectrum had been granted but not authorized. In this case, the radios would be off. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 41...
-
Page 43: Supplier's Declaration Of Conformity (5Ghz)
Supplier’s Declaration of Conformity (5GHz) Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 42... -
Page 44: Supplier's Declaration Of Conformity (Cbrs)
Supplier’s Declaration of Conformity (CBRS) Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 43... -
Page 45: Regulatory Information
Safety IEC/EN 62368-1: 2014, Second Edition, + Compliance Modifications not expressly approved by Tarana Wireless Inc. could void the user's A11:2017 authority to operate the equipment. • IEC 60950-22:2016 for use in conjunction... - Page 46 This product must be professionally installed. Le produit final doit être installé par un professionnel. Modifications not expressly approved by Tarana Wireless Inc. could void the user's Tarana Wireless Inc n’approuve aucune modification apportée à l’appareil par authority to operate the equipment.
-
Page 47: Resolution 680: Brazil
Restrita (Resolução nº 680): “Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados – Para maiores informações, consulte o site da Anatel https://www.gov.br/anatel/pt-br/ Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 46... -
Page 48: Usa Cbrs Band Categoryb Device
USA CBRS Band Category B Device CBSD Protocol The Tarana BN requires installation by a CPI (Certified Professional Installer) as The SAS-CBSD protocol is based on the HTTPS (HTTP over TLS) protocol. The defined in Section 96.39 and 96.45 of FCC part 96 requirements. The BN is... - Page 49 CBSD. The SAS responds with an array of Registration Requests, each containing a registration response to a CBSD with parameters that indicate whether the registration succeeded or failed. Tarana Wireless, Inc. Proprietary ©2021. All rights reserved. BN Installation Guide vIG_BN_2022-07 — 48...
-
Page 50: Warranty
Warranty Tarana warrants that commencing from the date of shipment to you (and in case of resale to you by a Tarana partner, commencing not more than 90 days after our original shipment), and continuing for a period of twelve (12) months, the hardware will be free from defects in material and workmanship under normal use. This limited warranty is not transferrable.
