ORDER NO. MKE0304102C1
D1
Combination VCR
AG-513F / AG-520F
SPECIFICATIONS
1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic AG-513F

Summary of Contents for Panasonic AG-513F

  • Page 1 ORDER NO. MKE0304102C1 Combination VCR AG-513F / AG-520F SPECIFICATIONS...

  • Page 2: Safety Precautions

    2003 Matsushita Kotobuki Electronics Industries LTD. All rights reserved. Unauthorized copying and distribution is a violation of law. 1. SAFETY PRECAUTIONS GENERAL GUIDELINES 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Circuit Board Layout, Exploded Views and Replacement Parts List.
  • Page 3 injury from electrical shocks. It will also protect Combination VCR from being damaged by accidental shorting that may occur during servicing. 3. When servicing, observe the original lead dress, especially the lead dress in the high voltage circuits. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.
  • Page 4 power cord from the AC outlet. 7. Potentials, as high as 25.0 kV (For model with 13 inch CRT) or 30.0 kV (For model with 20 inch CRT) are present when this TV set is in operation. Operation of the TV set without the rear cover involves the danger of a shock hazard from the TV set power supply.
  • Page 5 measurements. 6. The potential at any point should not exceed 0.75 V RMS. A leakage current tester (Simpson Model 229 equivalent) may be used to make the hot checks. Leakage current must not exceed 1/ 2 mA. In case a measurement is outside of the limits specified, there is a possibility of shock hazard, and the receiver should be repaired and rechecked before it is returned to the customer.
  • Page 6 4. To prevent an X-Radiation possibly, it is essential to use the specified picture tube. HORIZONTAL OSCILLATOR DISABLE CIRCUIT TEST SERVICE WARNING : The test must be made as a final check before set is returned to the customer. 1. With the rear cover removed, supply about a 90 V AC power source to the set, turn on the set.

  • Page 7: Prevention Of Electrostatic Discharge

    3. PREVENTION OF ELECTROSTATIC DISCHARGE (ESD) TO ELECTROSTATICALLY SENSITIVE (ES) DEVICES Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors are semiconductor "chip" components.

  • Page 8: About Lead Free Solder (Pbf)

    leads of a replacement ES device, touch the protective material to the chassis or circuit assembly into which the device will be installed. CAUTION: Be sure no power is applied to the chassis or circuit, and observe all other safety precautions. 8.
  • Page 9 together for over 3 seconds. Fig. 1-1 2. TV power goes on and the unit goes into service mode. 4 digit for fault code and communication for I C bus code will be displayed. Fig. 1-2 Fig. 1-3 Fig. 1-4...
  • Page 10 Fig. 1-5 3. Press any operation button except for POWER on either the unit, or the remote to detect that a key has been pressed. The 1st digit changes to "0" only when key is detected. Fig. 1-6...

  • Page 11: Service Position

    Note: When 1 to 4 listed in Lock code occurs, the VCR stops and all VCR function buttons except for power become non-operational. 5.1.2. USAGE SCREEN MODE Function displayed on the TV monitor: - the total AC plugged in AC socket (in days)) - the total elapsed "Cylinder rotation"...
  • Page 12 5.1.3.2. Service Position (1) Fig. 2-1 5.1.3.3. Service Position (2) Fig. 2-2 Note: 1. It is possible that the S-Tab SW. may not work correctly in Service Position (2). (Recording can not be done). In this case, short the S- Tab SW.
  • Page 13 5.1.4. HOT CIRCUIT Primary circuit exists on the TV/VCR Main C.B.A. This circuit is identified as "HOT" on the C.B.A. and in the Service Manual. Use extreme care to prevent accidental shock when servicing. 5.1.5. SERVICE MODE In order to inhibit detection of the Supply & Takeup Photo Transistors, Reel Sensor, and Cylinder Lock, press and hold STOP/EJECT, PLAY/REPEAT, and CH DOWN buttons on the unit together over 5 seconds in power on condition.
  • Page 14 Fig. 4 5.1.8. HOW TO INITIALIZE MEMORY IC After the Memory IC (IC6004) or TV/VCR Main C.B.A. is replaced, be sure to set the Default value to Memory IC as shown in "Memory IC Reference Table" below. 1. Press and hold STOP, PLAY, and VOL- buttons on the unit together over 5 seconds with no cassette inserted.

  • Page 15: Electrical Adjustment

    4. Press and hold STOP, PLAY, and VOL- buttons on the unit together over 5 seconds again or press the POWER button OFF to release EVR Adjustment mode. The Default value will be written to Memory IC (IC6004). 5. Perform all EVR Adjustments. (Refer to "EVR (Electronic Variable Register) ADJUSTMENT WITH THE REMOTE CONTROL"...
  • Page 16 5.1.9.2. (Electrical Method) Apply +10.0 V DC Power Supply to the Loading Motor terminals. Loading DC + to Portion "a," DC - to Portion "b" Unloading DC - to Portion "a," DC + to Portion "b" CAUTION: Before applying DC Power Supply, be sure to cut the Motor Leads with a cutter, etc.
  • Page 17 5.1.10. HOW TO REMOVE A JAMMED TAPE CAUTION: Wiper Arm Unit may be damaged or its spring may be out of place when the jammed tape is removed by force. Remove a jammed tape as follows: 5.1.10.1. Manual Method When a tape jam is encountered, check the tape loading condition and use the following procedure to remove a tape jam.
  • Page 18 2. Remove the tape from the tape path. 3. Rewind the tape into the cassette by rotating the Center Clutch Unit counterclockwise. 4. Unhook Spring (A) of the Drive Rack Arm. 5. Remove Screw (A). 6. Lift the Cassette Up Ass’y. While pulling the Cassette Up Ass’y out far enough so that it clears the Drive Rack Arm, slide the Drive Rack Unit as indicated by the arrow to remove the cassette tape from the Cassette Up Ass’y.
  • Page 19 1. Perform Step 2 through Step 7 of Method -1. Note: After repairing mechanical trouble, make sure that all gear alignments are correct, especially the Wiper Arm Unit and Drive Rack Unit of Cassette Up Ass’y. (Refer to "EJECT Position Confirmation"...
  • Page 20 5.1.11. F.P.C. CONNECTION NOTE 5.1.11.1. F.P.C. between the Capstan Motor and the Cylinder Be careful with the direction of F.P.C. to connector as shown. Fig. 9 5.1.12. WIRE AND LEAD POSITION DIAGRAM Fig. 10...
  • Page 21 5.1.13. HOW TO SET TRACKING TO THE NEUTRAL POSITION Ejecting the cassette tape and then reinserting it will reset the tracking to the Neutral position. 5.1.14. BLACK SCREWS ON THE CHASSIS Black Screws are used on the Mechanism Chassis to identify screws that require adjustment. 5.1.15.

  • Page 22: Maintenance Chart

    the test unit. 2. Select corresponding RF channels. 3. Playback a recording of P.B.S. channel including clock set data and confirm this feature. 5.1.17. VARIABLE VOLTAGE ISOLATION TRANSFORMER An Isolation Transformer should always be used during the servicing of Combination VCR whose chassis is not isolated from the AC power line.

  • Page 23: Disassembly/Assembly Procedures

    6. DISASSEMBLY/ASSEMBLY PROCEDURES 6.1. CABINET SECTION 6.1.1. Disassembly Flowchart Perform all disassembly procedures in the order described in the "Disassembly Flowchart" shown below. When reassembling, use the reverse procedure. CAUTION: Disconnect AC plug before disassembly. Fig. D1...
  • Page 24 6.1.2. Disassembly Method Fig. D2...
  • Page 25 Fig. D3...
  • Page 26 6.1.2.1. Notes in chart 1. Removal of VCR Unit Fig. D4...
  • Page 27 Fig. D5 Installation of VCR Unit CAUTION: Opener Lever may be damaged when VCR Unit is installed, with Cassette Door-Lid and Opener Lever of Cassette Up Ass’y set incorrectly. A. When installing the VCR Unit, swing the Cassette Door-Lid all the way open until the Cassette Door tab clears the Opener Lever.
  • Page 28 2. Removal of Color Picture Tube Unit Place the Unit face down on a soft cloth before removing the Color Picture Tube Unit. 3. Installation of Mechanism Chassis Ass’y and TV/VCR Main C.B.A. When installing 2 Screws (449), slide the Holder Unit of the Cassette Up Ass'y (Refer to "WHEN LOADING WITHOUT A CASSETTE"...

  • Page 29: Mechanism Section

    B. Install the Mechanism Chassis and Cassette Up Ass’y straight onto the TV/VCR Main C.B.A. so that the Sensor LED clears the hole in the Mechanism Chassis and that 3 Connectors (P6201, P3001 and P4001) are aligned and seated securely. 5.
  • Page 30 6.2.2. Inner Parts Location Fig. J1-1...
  • Page 31 6.2.3. EJECT Position Confirmation Fig. J1-2...
  • Page 32 6.2.4. Full Erase Head and Cylinder Unit Fig. J2...

  • Page 33: Service Notes

    6.2.4.1. Reassembly Notes 1. After replacing the Cylinder Unit, clear the Total elapsed "Cylinder rotation" time (in hours) to 0. Refer to "USAGE SCREEN MODE" in SERVICE NOTES. 6.2.5. Capstan Belt, Support Angle, Intermediate Gear B, and Main Cam Gear Fig.
  • Page 34 6.2.5.1. Reassembly Notes 1. Alignment of Main Cam Gear, Drive Rack Arm, and Main Rod A. Confirm that the hole on Main Rod is a Through Hole with a hole on chassis. B. Confirm that the hole on Drive Rack Arm is a Through Hole with a hole on chassis.
  • Page 35 2. Confirmation/Alignment of Intermediate Gear B, Main Cam Gear, and Intermediate Gear A A. Confirm that the Hole A on Lift Gear is a Through Hole with a hole on chassis. B. Confirm that the hole on Intermediate Gear A is aligned with the hole on Lift Gear.
  • Page 36 Hole with Hole A on Support Angle in EJECT mode. The each mode Hole on Main Cam Gear should be a Through Hole with Hole B on Support Angle in each mode. Fig. J3-5 4. Drive Rack Arm Kit A. Main Cam Gear is supplied as a Drive Rack ArmKit only. Main Cam Gear Kit consists of a Drive Rack Arm,a Main Cam Gear and a Main Cam Push Nut.
  • Page 37 6.2.6.1. Reassembly Notes 1. Installation of Center Clutch Unit A. Fit the Center Clutch Unit into the Changing Gear. Fig. J4-2 6.2.7. Reel Gear, Main Rod, and SS Brake Arm Unit Fig. J5-1...
  • Page 38 6.2.7.1. Reassembly Notes 1. Alignment of Main Rod and T Loading Arm Unit A. Align the Gear of T Loading Arm Unit with Gear of Main Rod. Confirm that the Hole on Main Rod is a Through Hole with a hole on chassis.
  • Page 39 6.2.9. T Loading Arm Unit and S Loading Arm Unit Fig. J7-1 6.2.9.1. Reassembly Notes 1. Alignment of T Loading Arm Unit and S Loading Arm Unit A. Install the S Loading Arm Unit onto the chassis. B. Install the T Loading Arm Unit so that the hole on T Loading Arm Unit is aligned with the hole on S Loading Arm Unit.
  • Page 40 6.2.10. T Brake Unit, Tension Control Arm Unit, T Reel Table, S Reel Table, and Tension Arm Unit Fig. J8-1 6.2.10.1. Reassembly Notes 1. How to distinguish between S Reel Table and T Reel Table Fig. J8-2...
  • Page 41 6.2.11. Loading Post Base -T Unit and Loading Post Base -S Unit Fig. J9 6.2.12. Opener Piece, Drive Rack Arm, Pinch Arm Unit, P5 Arm Unit, and Intermediate Gear A Fig. J10-1...
  • Page 42 6.2.12.1. Reassembly Notes 1. Installation/Alignment of Intermediate Gear A, Lift Gear and P5 Arm Unit A. Rotate the Lift Gear so that Hole A on Lift Gear is a Through Hole with a hole on chassis. B. Install the Intermediate Gear A so that the hole on Intermediate Gear A is aligned with the hole on Lift Gear.
  • Page 43 Fig. J11 6.3. CASSETTE UP ASSEMBLY SECTION 6.3.1. Top Plate, Wiper Arm Unit, and Holder Unit Fig. K1-1...
  • Page 44 6.3.1.1. Reassembly Notes 1. Alignment of Wiper Arm Unit and Drive Rack Unit A. Slide the Drive Rack Unit to the far right as indicated by the arrow. B. Install the Wiper Arm Unit so that the hole on the Wiper Arm Unit is aligned with the hole on the Drive Rack Unit.
  • Page 45 2. Installation of Holder Unit A. Turn the Wiper Arm Unit so that the grooves on each end are aligned with the each groove on Side Plate L and R. B. Insert Holder Unit boss (A) and (B) into the grooves as shown in Fig.

  • Page 46: Adjustment Procedures

    6.3.2. Opener Lever and Drive Rack Unit Fig. K2 7. ADJUSTMENT PROCEDURES 7.1. SERVICE FIXTURES AND TOOLS 7.2. MECHANICAL ADJUSTMENT 7.2.1. CLEANING PROCEDURE FOR THE UPPER CYLINDER UNIT 1. While slowly turning the Upper Cylinder Unit counterclockwise by hand, gently rub the Video Heads with a Head Cleaning Stick (VFK27) moistened with Ethanol.
  • Page 47 Note: 1. Do not rub vertically or apply excess pressure to the Video Heads. Do not turn the Upper Cylinder Unit clockwise while cleaning. 2. After cleaning, use a Dry Head Cleaning Stick (VFK27) to remove any Ethanol remaining on the cylinder tape path. Otherwise, tape damage will occur.
  • Page 48 3. If the reading is out of specification, make sure that there is no dust or foreign material between the Brake Pad of Tension Control Arm Unit and the S Reel Table. After cleaning, the reading of tension measurement is still out of specification, replace the Tension Arm Unit and the Tension Control Arm Unit.
  • Page 49 VHS Alignment Tape (VFMS0003H6) Post Adjustment Driver (VFK0329) H-Position Adjustment Driver (VFK0330) 7.2.2.2.1. ENVELOPE OUTPUT ADJUSTMENT The height of the P2 and P3 Posts replacement part is preadjust at the factory. Purpose: To achieve a satisfactory picture and secure precise tracking. Symptom of Misadjustment: If the envelope is output poorly, much noise will appear in the picture.
  • Page 50 Fig. M3-1 Fig. M3-2 6. After adjustment, confirm that the tape travels without curling at P2 and P3 posts. Fig. M3-3 7. Remove the jumper after completing the adjustment procedure. 7.2.2.2.2. AUDIO CONTROL HEAD TILT ADJUSTMENT Purpose: To confirm that the tape runs smoothly. In particular, confirm that the tape properly picks up the Audio Signal at the upper part of the head and the Control Signal at the lower part of the head.
  • Page 51 screw counterclockwise until the curling is eliminated. Fig. M4 7.2.2.2.3. AUDIO CONTROL HEAD HEIGHT ADJUSTMENT The height of the Audio Control Head replacement part is preset at the factory. Purpose: To be sure the tape runs properly along the Control Head. Symptom of Misadjustment: If the control signal is not properly picked up, Servo Operation cannot be achieved.
  • Page 52 To adjust the position and height of the Audio Control Head so that it meets the tape tracks properly. Symptom of Misadjustment: If the position of the Audio Control Head is not properly adjusted, the Audio S/N Ratio is poor. 1.

  • Page 53: Test Equipment

    fixture either clockwise or counterclockwise so that the envelope is at maximum. Fig. M7 6. Tighten Black Screw (D). 7. Remove the jumper between TP6003 and +5 V(TP6009). Note: Old type of H-Position Adjustment Driver (VFK0136) can be used for this adjustment.
  • Page 54 11. Audio Generator 7.3.2. HOW TO READ THE ADJUSTMENT PROCEDURES Fig.E1 7.3.3. FM VCO ADJUSTMENT (FOR MODEL WITH FM RADIO AND TV STEREO) Purpose: To set VCO free run frequency. Symptom of Misadjustment: Even when stereophony is received, only monaural sound will be output.
  • Page 55 1. Connect C9203(-) on the TV/VCR Main C.B.A. to GND. Fig. E3-1 2. Connect TP9201 on the TV/VCR Main C.B.A. to GND through a resistor (3.3 kW). Then, connect Frequency Counter to TP9201. Fig. E3-2 3. Adjust R9206 (FM VCO) so that the frequency is 38.0 kHz± 50 Hz. 7.3.4.
  • Page 56 7.3.4.1. EVR ADJUSTMENT ITEM The following Items need to be adjusted for EVR adjustment. - PG SHIFTER ADJUSTMENT - SUB CONTRAST ADJUSTMENT - FOCUS, SCREEN, CUT OFF, DRIVE ADJUSTMENT - SUB COLOR/SUB TINT ADJUSTMENT - V. HEIGHT/H. POSITION ADJUSTMENT - WHITE BALANCE ADJUSTMENT - SUB BRIGHTNESS ADJUSTMENT 7.3.4.2.
  • Page 57 You can select a desired channel by using the numbered keys on the remote control in EVR adjustment mode. 4. Press VOL -/+ key on the remote control so that the shaded area moves to the control function. Fig. E4-4 5.
  • Page 58 Press STOP button or press the POWER button OFF. The adjusted value will be written to Memory IC (IC6004). 7.3.4.4. HOW TO ENTER SERVICE MODE 1. Enter EVR adjustment mode. 2. Press DISPLAY key on the remote control for collapse scan. Note: Before pressing DISPLAY key on the remote control for collapse scan, select the desired control function and move the shaded...

  • Page 59: How To Enter

    1. Enter EVR PG Shifter Adjustment mode, refer to "HOW TO ENTER EVR PG SHIFTER ADJUSTMENT MODE." 2. Connect the channel-1 scope probe to TP3001 and the channel-2 scope probe to TP6205. Used TP6205 as a trigger. 3. Adjust value so that the trailing edge of the head switching pulse is placed 6 H±1 H (0.38 ms±0.06 ms) before the start of the vertical sync pulse.
  • Page 60 Mode : STOP Equipment : Oscilloscope, NTSC Video Pattern Generator 1. Supply a Crosshatch Pattern Signal to the Video Input Jack. 2. Connect the Oscilloscope to Pin 5 of P6001 on the TV/VCR Main C.B.A. or TP49 on the CRT C.B.A. 3.
  • Page 61 SUB BRIGHT (EVR), B DRIVE (EVR), G DRIVE (EVR), B CUT -OFF (EVR), G CUT -OFF (EVR), R CUT -OFF (EVR) Specification : Refer to descriptions below. INPUT : Video Input Jack, Monoscope Pattern Signal Mode : STOP Equipment : Oscilloscope, NTSC Video Pattern Generator 1.
  • Page 62 8. Turn the SCREEN CONTROL on the Flyback Transformer clockwise carefully and stop at the point where any color is first observed. 9. In EVR adjustment mode, select the two colors not observed in step 8 from the following control functions (B CUT -OFF, G CUT - OFF, or R CUT -OFF) and adjust so that the horizontal line becomes white.
  • Page 63 Adjustment : SUB COLOR (EVR), SUB TINT (EVR) Specification : C = 1.40 V[p-p]±0.15 V[p-p] (For model with 13 inch CRT) C = 1.50 V[p-p]±0.15 V[p-p] (For model with 20/25 inch CRT) INPUT : Video Input Jack, Rainbow Color Bar Mode : STOP Equipment :...
  • Page 64 Fig. E8-2 6. Select SUB TINT in EVR adjustment mode and increase level B 1 click above the same level. 7. Select SUB BRIGHT in EVR adjustment mode and reset to the original value. 7.3.9. V. HEIGHT/H. POSITION ADJUSTMENT Purpose: To set the standard vertical and horizontal picture size.
  • Page 65 (For model with 13 inch CRT) 1. Supply a Monoscope Pattern Signal to the Video Input Jack. 2. Select H-CENTER in EVR adjustment mode and adjust so that width A is approximately equal to width B. Note: Width A is wider than width B slightly. 3.

  • Page 66: White Balance Adjustment

    7.3.10. WHITE BALANCE ADJUSTMENT Purpose: To set the standard white level for each color temperature. Symptom of Misadjustment: White becomes bluish or reddish. Test Point : TP50 (CRT C.B.A) Adjustment : FOCUS CONTROL (Flyback Transformer), SCREEN CONTROL (Flyback Transformer), SUB BRIGHT (EVR), G DRIVE (EVR), B DRIVE (EVR), R CUT -OFF (EVR),...
  • Page 67 INPUT : Video Input Jack, Monoscope Pattern Signal, White Pattern Signal Mode : STOP Equipment : NTSC Video Pattern Generator, White Pattern Generator, Oscilloscope 1. Supply a Monoscope Pattern Signal to the Video Input Jack. 2. Connect the Oscilloscope to TP50 on the CRT C.B.A. (Use TP47 for GND.) 3.

  • Page 68: Sub Brightness Adjustment

    clockwise carefully and stop at the point where any color is first observed. 9. In EVR adjustment mode, select the two colors not observed in step 8 from the following control functions (B CUT -OFF, G CUT - OFF, or R CUT -OFF) and adjust so that the horizontal line becomes white.

  • Page 69: Test Points And Control Location

    Specification : Refer to descriptions below. INPUT : ---------- Mode : STOP 1. Do not input any signal to the unit. 2. Set INPUT SELECT item to LINE in SET UP TV menu to display black screen. 3. Select SUB BRIGHT in EVR adjustment mode, and adjust so that the black screen starts to turn gray (lighting only).

  • Page 71: Schematic Diagrams

    8. SCHEMATIC DIAGRAMS 8.1. SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES 8.2. TV/VCR MAIN SCHEMATIC DIAGRAM 8.3. HEAD AMP SCHEMATIC DIAGRAM 8.4. CRT SCHEMATIC DIAGRAM (Model: AG-513F) 8.5. CRT SCHEMATIC DIAGRAM (Model: AG-520F) 8.6. INTERCONNECTION SCHEMATIC DIAGRAM 8.7. VOLTAGE CHART...

  • Page 72: Signal Waveforms

    8.8. SIGNAL WAVEFORMS 9. CIRCUIT BOARD LAYOUT 9.1. TV/VCR MAIN C.B.A. 9.2. HEAD AMP C.B.A. / CRT C.B.A. 10. BLOCK DIAGRAMS 11. EXPLODED VIEWS 11.1. MECHANISM (TOP) SECTION...

  • Page 73: Mechanism (Bottom) Section

    11.2. MECHANISM (BOTTOM) SECTION...

  • Page 74: Cassette Up Compartment Section

    11.3. CASSETTE UP COMPARTMENT SECTION...

  • Page 75: Chassis Frame Section

    11.4. CHASSIS FRAME SECTION (1)
  • Page 76 11.5. CHASSIS FRAME SECTION (2)

  • Page 77: Packing Parts And Accessories Section

    11.6. PACKING PARTS AND ACCESSORIES SECTION...

  • Page 78: Replacement Parts Lists

    12. REPLACEMENT PARTS LISTS BEFORE REPLACING PARTS, READ THE FOLLOWING: 12.1. REPLACEMENT NOTES 12.1.1. General Notes 1. Use only original replacement parts: To maintain original function and reliability of repaired units, use...

  • Page 79: Special Note

    only original replacement parts which are listed with their part numbers in the parts list. 2. IMPORTANT SAFETY NOTICE Components identified by the sign have special characteristics important for safety. When replacing any of these components, use only the specified parts. 3.

  • Page 80: Mechanical Adjustment Procedures

    perform "TAPE INTERCHANGEABILITY ADJUSTMENT" in MECHANICAL ADJUSTMENT procedures. 3. In early units, a washer is used. When servicing the washer or the P5 Arm Unit, replace only the P5 Arm Unit with a new one, and remove the washer. 4. Main Cam Gear is supplied as a Main Cam Gear Kit (Ref. No. 8) only.
  • Page 81 COMPLX CMP: Complex Component W FLMPRF: Wirewound Flameproof C.B.A.: Circuit Board Assembly P.C.B.: Printed Circuit Board E.S.D.: Electrostatically Sensitive Devices 3. When replacing 0 resistor, a wire can be substituted for it. 4. Since the UHF/VHF TUNER/TV DEMODULATOR UNIT (Ref. No. 743) has already been pre-adjusted at the factory, do not try to adjust the UHF/VHF TUNER/TV DEMODULATOR UNIT.

  • Page 82: Mechanical Replacement Parts List

    12.2. MECHANICAL REPLACEMENT PARTS LIST Definition of Parts supplier: 1. Parts with mark "MKE" in the Remarks column are supplied from MKE. 2. Parts without mark in the Remarks column are supplied from MKI. MECHANICAL REPLACEMENT PARTS Ref. No. Part No. Part Name &...
  • Page 83 Ref. No. Part No. Part Name & Description Remarks VXLS1098 T LOADING ARM UNIT LSDG0116 REEL GEAR LSDG0111 INTERMEDIATE GEAR B LSMA0532 SUPPORT ANGLE LSDV0009 CAPSTAN BELT SQUARE,ELASTOMER 2MM 2 LSXL0087 SS BRAKE ARM UNIT LSMB0196 SS BRAKE SPRING VMFS0311 CUSHION LSXY0483 CASSETTE UP ASS'Y...

  • Page 84: Electrical Replacement Parts List

    VHDS0498 SCREW W/WASHER,STEEL Ref. No. Part No. Part Name & Description Remarks VHNS0070 MAIN CAM PUSH NUT,STEEL XWGV2D5G WASHER,NYLON XYC26+SF6J SCREW W/WASHER,STEEL XTV3+8JR TAPPING SCREW,STEEL XTV4+12A TAPPING SCREW,STEEL THE492-4 SCREW W/WASHER,STEEL ( A ) LHT60002Y SCREW,STEEL ( B ) XTV4+16A TAPPING SCREW,STEEL VHDS0493 TAPPING SCREW,STEEL...

  • Page 85: Integrated Circuits

    1. All parts are supplied from MKI. PRINTED CIRCUIT BOARD ASSEMBLY Ref. No. Part No. Part Name & Description Remarks LSEP2012X TV/VCR MAIN C.B.A. ( A ) E.S.D. RTL LSEP2012E TV/VCR MAIN C.B.A. ( B ) E.S.D. RTL LSEP2009A HEAD AMP C.B.A. LRP63004D CRT C.B.A.
  • Page 86 Ref. No. Part No. Part Name & Description Remarks IC6005 RN5VS47CA-TR IC, CMOS STANDARD LOGIC E.S.D. TRANSISTORS Ref. No. Part No. Part Name & Description Remarks Q431 2SA733-TQ TRANSISTOR SI PNP Q431 2SA1175 TRANSISTOR SI PNP Q431 2SA1175-TH TRANSISTOR SI PNP Q501 B1AACN000013 TRANSISTOR SI NPN Q531...
  • Page 87 Ref. No. Part No. Part Name & Description Remarks Q3001 B1ADCF000076 TRANSISTOR SI PNP Q3002 2SD1819A0L TRANSISTOR SI NPN CHIP Q3002 B1ABCF000020 TRANSISTOR SI NPN CHIP Q3002 B1ABCF000111 TRANSISTOR SI NPN Q3002 B1ABCF000112 TRANSISTOR SI NPN Q3301 2SD1819A0L TRANSISTOR SI NPN CHIP Q3301 B1ABCF000020 TRANSISTOR SI NPN CHIP Q3301...
  • Page 88 Ref. No. Part No. Part Name & Description Remarks D401 B0EAKL000049 DIODE SI D401 B0EAKL000044 DIODE SI D401 B0EAKL000045 DIODE SI D502 MA2C165001VT DIODE SI D502 B0AACK000004 DIODE SI D502 1SS119 DIODE SI D503 B0HAGP000011 DIODE SI D503 B0HAJP000012 DIODE SI D504 MAZ40470MF DIODE ZENER 4.7V...
  • Page 89 Ref. No. Part No. Part Name & Description Remarks D803 B0EAKT000027 DIODE SI D803 B0EAKT000030 DIODE SI D803 B0EALT000004 DIODE SI D804 B0AAKT000010 DIODE SI D804 B0AAKT000009 DIODE SI D804 B0EAKT000007 DIODE SI D804 B0EAKT000027 DIODE SI D804 B0EAKT000030 DIODE SI D804 B0EALT000004 DIODE SI...
  • Page 90 D4591 MAZ4110NHF DIODE ZENER 11V Ref. No. Part No. Part Name & Description Remarks D4592 MAZ41100LF DIODE ZENER 11V D4592 MAZ4110NHF DIODE ZENER 11V D5501 MAZ40620L1KT DIODE ZENER 6.2V D5602 MA2C165001VT DIODE SI D5602 B0AACK000004 DIODE SI D5602 1SS119 DIODE SI D5603 MA2C165001VT DIODE SI D5603...
  • Page 91 Ref. No. Part No. Part Name & Description Remarks R502 ERJ6GEYJ332V MGF CHIP 1/10W 3.3K R503 EROS2THF9101 PRECISION METAL FILM 1/4W 9.1K ( A ) R503 EROS2THF8201 PRECISION METAL FILM 1/4W 8.2K ( B ) R503 EROS2TKF9101 PRECISION METAL FILM 1/4W 9.1K ( A ) R503 EROS2TKF8201 PRECISION METAL FILM 1/4W 8.2K ( B )
  • Page 92 R572 ERJ6GEYJ331V MGF CHIP 1/10W 330...
  • Page 93 Ref. No. Part No. Part Name & Description Remarks R573 ERDS2TJ221 CARBON 1/4W 220 R574 ERJ6GEYJ273V MGF CHIP 1/10W 27K R581 ERDS1FJ2R2 CARBON 1/2W 2.2 ( A ) R581 ERDS1FJ1R5P CARBON 1/2W 1.5 ( B ) R582 ERDS1FJ3R9P CARBON 1/2W 3.9 ( A ) R582 ERDS1FJ1R5P CARBON 1/2W 1.5 ( B )
  • Page 94 Ref. No. Part No. Part Name & Description Remarks R3035 ERJ6GEYJ103V MGF CHIP 1/10W 10K R3036 ERJ6GEYJ102V MGF CHIP 1/10W 1K R3037 ERJ6GEYJ102V MGF CHIP 1/10W 1K R3038 ERJ6GEYJ222V MGF CHIP 1/10W 2.2K R3077 ERJ6GEYJ101V MGF CHIP 1/10W 100 R3084 ERJ6GEYJ102V MGF CHIP 1/10W 1K R3086...
  • Page 95 Ref. No. Part No. Part Name & Description Remarks R5317 ERDS2TJ101 CARBON 1/4W 100 R5324 ERJ6GEYJ101V MGF CHIP 1/10W 100 R5401 ERJ6GEYJ561V MGF CHIP 1/10W 560 R5402 ERJ6GEYJ394V MGF CHIP 1/10W 390K R5403 ERJ6GEYJ221V MGF CHIP 1/10W 220 R5405 ERJ6GEYJ822V MGF CHIP 1/10W 8.2K R5406 ERJ6GEYJ101V...
  • Page 96 Ref. No. Part No. Part Name & Description Remarks R6045 ERJ6GEYJ102V MGF CHIP 1/10W 1K R6046 ERJ6GEYJ102V MGF CHIP 1/10W 1K R6049 ERJ6GEY0R00V MGF CHIP 1/10W 0 R6050 ERJ6GEYJ102V MGF CHIP 1/10W 1K R6053 ERJ6GEYJ222V MGF CHIP 1/10W 2.2K R6054 ERJ6GEYJ102V MGF CHIP 1/10W 1K R6055...
  • Page 97 Ref. No. Part No. Part Name & Description Remarks R6146 ERJ6GEYJ273V MGF CHIP 1/10W 27K R6149 ERJ6GEYJ273V MGF CHIP 1/10W 27K R6150 ERJ6GEYJ912V MGF CHIP 1/10W 9.1K R6160 ERJ6GEYJ562V MGF CHIP 1/10W 5.6K R6161 ERJ6GEYJ562V MGF CHIP 1/10W 5.6K R6162 ERJ6GEYJ562V MGF CHIP 1/10W 5.6K R6163...
  • Page 98 Ref. No. Part No. Part Name & Description Remarks C401 ECEA1HGE2R2B ELECTROLYTIC 50V 2.2UF C402 ECA1CM471B ELECTROLYTIC 16V 470 C408 ECA1HGE010KB ELECTROLYTIC 50V 1UF C409 ECA1VM101B ELECTROLYTIC 35V 100 C413 ECQB1H104KF3 POLYESTER 50V 0.1UF C414 ECA1EM102E ELECTROLYTIC 25V 1000 C418 ECA1VM221B ELECTROLYTIC 35V 220UF C459...
  • Page 99 C811 F1B2E152A044 CERAMIC 250V 1500PF...
  • Page 100 Ref. No. Part No. Part Name & Description Remarks C811 F1B2E152A045 CERAMIC 250V 1500PF C811 F1B2E1520002 CERAMIC 250V 1500PF C811 F1B2E1520006 CERAMIC 250V 1500PF C1001 ECKATS103MF CERAMIC 250V 0.01UF C1001 ECKETS103MF CERAMIC 125V 0.01UF C1001 VCKST3G103MY CERAMIC 250V 0.01UF C1001 VCKSU3D103MY CERAMIC 125V 0.01UF C1002 ECKATS332ME8 CERAMIC 250V 3300PF...
  • Page 101 Ref. No. Part No. Part Name & Description Remarks C3010 ECJ2VF1H103Z C CHIP 50V 0.01UF C3013 ECJ2VF1C224Z C CHIP 16V 0.22UF C3015 ECEA0JKA470 ELECTROLYTIC 6.3V 47UF C3016 ECEA1CKA100 ELECTROLYTIC 16V 10UF C3019 ECEA1HKA2R2 ELECTROLYTIC 50V 2.2UF C3020 ECEA1CKA220 ELECTROLYTIC 16V 22UF C3021 ECEA1HKA2R2 ELECTROLYTIC 50V 2.2UF...
  • Page 102 Ref. No. Part No. Part Name & Description Remarks C4018 ECJ2VB1H103K C CHIP 50V 0.01UF C4020 ECEA1HKA010 ELECTROLYTIC 50V 1UF C4102 ECQB1562JF POLYESTER 100V 5600PF C4103 ECJ2VB1H103K C CHIP 50V 0.01UF C4104 ECJ2VB1H103K C CHIP 50V 0.01UF C4105 ECEA1CKA220 ELECTROLYTIC 16V 22UF C4171 ECEA1HKA010 ELECTROLYTIC 50V 1UF...
  • Page 103 Ref. No. Part No. Part Name & Description Remarks C6021 ECEA0JKA101 ELECTROLYTIC 6.3V 100UF C6023 ECJ2VB1H103K C CHIP 50V 0.01UF C6025 ECEA0JKA470 ELECTROLYTIC 6.3V 47UF C6029 ECJ2VF1H104Z C CHIP 50V 0.1UF C6040 ECJ2VB1H102K C CHIP 50V 1000PF C6041 ECJ2VB1H102K C CHIP 50V 1000PF C6044 ECJ2VF1E104Z C CHIP 25V 0.1UF...

  • Page 104: Line Noise Filter

    Ref. No. Part No. Part Name & Description Remarks L501 G0D680000001 COIL ( B ) L501 ELH5L4108 COIL ( B ) L501 G0D510000001 COIL ( B ) L553 VLQSW07D220M COIL 22UH L803 ELF21V018A LINE NOISE FILTER L803 LLN63055A COIL L1001 ELF15N005A COIL LINE FILTER 0.5A 18M L1001...
  • Page 105 Ref. No. Part No. Part Name & Description Remarks P552 LSJWS4N250LL PIN HEADER ( A ) P552 LSJWS4N360LL PIN HEADER ( B ) P801 VEKS5809 CONNECTOR CABLE W/OUT PLUG 200V P803 LSJP0814 CONNECTOR 2P P3001 K1KA12A00232 CONNECTOR 12P P4001 VJSS0888 CONNECTOR 2P P4002 LSJWR6N120CL...
  • Page 106 Ref. No. Part No. Part Name & Description Remarks F801 K5D402AQ0002 FUSE 125V 4A F801 K5D402AB0002 FUSE 125V 4A F801 K5D402ADA002 FUSE 125V 4A F801 K5D402ADA006 FUSE 125V 4A F1001 K5D162AQ0004 FUSE 125V 1.6A F1001 K5D162ADA001 FUSE 125V 1.6A F1001 K5D162ADA008 FUSE 125V 1.6A PR1001 UNH000600A IC PROTECTOR 1.5A...

  • Page 107: Head Amp C.b.a

    Ref. No. Part No. Part Name & Description Remarks TUX77809 CLAMPER ( A ) XTV3+8J TAPPING SCREW,STEEL ( A ) XYN3+F10S SCREW W/WASHER,STEEL XYN3+F6S SCREW W/WASHER,STEEL XTV3+10J TAPPING SCREW,STEEL PNA4611M00HC INFRARED RECEIVER UNIT VMTS0059 CUSHION,RUBBER VMFS0136 CUSHION ( B ) ENG36706GY TUNER,UHF/VHF NR ( B ) LML69001A...
  • Page 108 Ref. No. Part No. Part Name & Description Remarks C3504 ECJ2VF1H103Z C CHIP 50V 0.01UF C3505 ECEA1CKA470 ELECTROLYTIC 16V 47UF C3506 ECJ2VF1E104Z C CHIP 25V 0.1UF C3507 ECJ2VB1H102K C CHIP 50V 1000PF C3508 ECJ2VF1E104Z C CHIP 25V 0.1UF C3511 ECJ2VF1E104Z C CHIP 25V 0.1UF C3512 ECJ2VF1E104Z C CHIP 25V 0.1UF C3513...
  • Page 109 Ref. No. Part No. Part Name & Description Remarks D351 MAZ41500MF DIODE ZENER 15V D351 B0BA01400041 DIODE ZENER VOLTAGE REGULATION D RESISTORS Ref. No. Part No. Part Name & Description Remarks R351 ERG1ANJ153H METAL OXIDE 1W 15K R351 ERG1ANJP153H METAL OXIDE 1W 15K R351 ERG2SJ153H METAL OXIDE 2W 15K...
  • Page 110 TRANSISTORS Ref. No. Part No. Part Name & Description Remarks Q351 2SC3063 TRANSISTOR SI NPN Q351 2SC3271F-N TRANSISTOR SI NPN Q351 2SC3619 TRANSISTOR SI NPN Q352 2SC3063 TRANSISTOR SI NPN Q352 2SC3271F-N TRANSISTOR SI NPN Q352 2SC3619 TRANSISTOR SI NPN Q353 2SC3063 TRANSISTOR SI NPN...
  • Page 111 Ref. No. Part No. Part Name & Description Remarks P353 K3B10AA00001 CRT SOCKETS MISCELLANEOUS Ref. No. Part No. Part Name & Description Remarks TMM7443-1 CLAMPER 13. SCHEMATIC DIAGRAMS FOR PRINTING WITH LETTER SIZE...
  • Page 112 REC VIDEO SIGNAL - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 113 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 114 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 115 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 116 AG-513F / AG-520F 8.2. TV/VCR MAIN SCHEMATIC DIAGRAM TV/VCR MAIN I (SYSTEM CONTROL/SERVO/CCV/OSD/OPERATION) SCHEMATIC DIAGRAM CAPSTAN SERVO CYLINDER SERVO TP6009 WA12.5 TO M IV UNSW_5V_SYSCON TP6099 TO M IV GND_SYSCON TP6008 WA20 R6173 D6002 R6168 R6172 D6007 R6169 Q6011 P6001 IS USED FOR...
  • Page 117 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 118 AG-513F / AG-520F TV/VCR MAIN II (SIGNAL PROCESS/AUDIO/DEMODULATOR) SCHEMATIC DIAGRAM U7001 ENG36706GY UHF/VHF TUNER JK4701 VIDEO AUDIO(L) PATTERN ANTENNA C7003 PT R7007 L7001 C7002 D3091 D3092 D4710 D4709 P7002 1000P C7004 PT R7006 FM ANT C7005 PT C7001 P7001 R3091...
  • Page 119 REC VIDEO SIGNAL PB VIDEO SIGNAL - - - - - - - - be sure to use the part number listed in the parts list. AG-513F REC AUDIO SIGNAL PB AUDIO SIGNAL Do not use the part number on this diagram.
  • Page 120 AG-513F / AG-520F TV/VCR MAIN III (TV Y/C PROCESS) SCHEMATIC DIAGRAM REC VIDEO SIGNAL PB VIDEO SIGNAL R5601 2700 Q5601 R5611 C5607 (BUFFER) D5601 R5613 Q5302 R5302 (BUFFER) R5308 D5304 D5602 R5304 MA165 R5612 R5309 R5303 R5614 D5603 270K MA165...
  • Page 121 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 122 AG-513F / AG-520F TV/VCR MAIN IV (POWER SUPPLY) SCHEMATIC DIAGRAM IMPORTA CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE 4A 125/250V FUSE. REPLACE ONLY WITH THE SAME TYPE 1.6A 125/250V FUSE.
  • Page 123 - - - - - - - - be sure to use the part number listed in the parts list. WHEN REPLACING ANY OF THESE COMPONENTS, AG-513F Do not use the part number on this diagram. USE ONLY THE SPECIFIED PARTS.
  • Page 124 TV/VCR MAIN V (TV) SCHEMATIC DIAGRAM TO M III TO M III HOLD_DOWN J504 TO M II GND_AMP TO M II DC_16V R557 R532 L501 R558 470/2W WA7.5 A,B,C,D,E,F 470/2W A,B,C,D,E,F ELH5L423 G,H,I A,B,C,D,E,F 330/2W 560/2W G,H,I C556 TO M II,M III H_PULSE G,H,I 0.33...
  • Page 125 AG-513F / AG-520F COMPARISON CHART NOTE: OF MODELS & MARKS FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, MARK MODEL REFER TO BEGINNING OF SCHEMATIC SECTION. - - - - - - - - - - - - - - - -...

  • Page 126: Head Amp Schematic Diagram

    AG-513F / AG-520F 8.3. HEAD AMP SCHEMATIC DIAGRAM HEAD AMP SCHEMATIC DIAGRAM C3517 C3518 C3501 C3502 R3501 L3501 C3504 C3505 100U 0.01 47/16V C3506 C3541 PB +5V ENVE IC3501 AN3361SB LP/SLP (HEAD AMP) LOGIC WF73 C3503 C3533 0.01 L3502 L3503...
  • Page 127 - - - - - - - - REC VIDEO SIGNAL be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...

  • Page 128: Video Signal

    8.4. CRT SCHEMATIC DIAGRAM (Model: AG-513F) CRT SCHEMATIC DIAGRAM (E) VIDEO SIGNAL R351 15K/1W R354 or 2W 2700 WF60 Q351 2SC1473-QNC TO TV/VCR MAIN BLUE R357 C.B.A. P5301 P351 3900 SW +12V C351 R360 390P GREEN BLUE R363 C357 D351...

  • Page 129: Crt Schematic Diagram

    AG-513F / AG-520F COMPARISON CHART IMPORTANT SAFETY NOTICE: NOTE: OF MODELS & MARKS COMPONENTS IDENTIFIED BY THE SIGN HAVE FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, MARK MODEL SPECIAL CHARACTERISTICS IMPORTANT FOR SAFETY. REFER TO BEGINNING OF SCHEMATIC SECTION.
  • Page 130 AG-513F / AG-520F 8.5. CRT SCHEMATIC DIAGRAM (Model: AG-520F) CRT SCHEMATIC DIAGRAM (G) VIDEO SIGNAL R351 R354 2700 G,H,I TO TV/VCR MAIN WF60 C.B.A. P5301 Q351 2SC1473-QNC R357 TO TV/VCR MAIN BLUE 3900 G,H,I,J C.B.A. P5301 P351 3300 SW +12V...
  • Page 131 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...

  • Page 132: Interconnection Schematic Diagram

    8.6. INTERCONNECTION SCHEMATIC DIAGRAM INTERCONNECTION SCHEMATIC DIAGRAM CYLINDER UNIT HEAD AMP C.B.A. TV/VCR MAIN C.B.A. (8 Pins) A,B,C,D,G,H,I,K P3501 P3001 (7 Pins) E,F,J (12 Pins) VIDEO AUDIO IN L-CH (3 Pins) A,B,C,D,G,H,I,K P3503 (6 Pins) E,F,J EARPHONE JACK AUDIO CONTROL/ERASE HEAD UNIT P4092 P4002...
  • Page 133 AG-513F / AG-520F COMPARISON CHART IMPORTANT SAFETY NOTICE: NOTE: OF MODELS & MARKS COMPONENTS IDENTIFIED BY THE SIGN HAVE FOR SCHEMATIC DIAGRAM AND CIRCUIT BOARD LAYOUT NOTES, MARK MODEL SPECIAL CHARACTERISTICS IMPORTANT FOR SAFETY. REFER TO BEGINNING OF SCHEMATIC SECTION.
  • Page 134 - - - - - - - - 11.9 TP552 -5.9 TP5504 -0.1 - - - - - - - - TP553 TP5505 AG-513F Q551 -0.3 TP554 19.5 TP5506 - - - - - - - - Q4001 TP556 200.0 AG-520F TP558 24.2...
  • Page 135 TP6107 TP6108 TP6109 TP6111 TP6201 Q6001 TP6202 12.0 TP6203 12.0 TP6204 11.3 11.7 TP6205 Q6002 TP6206 TP6207 11.3 12.1 TP6208 TP6209 Q6003 TP6401 Q6004 Q6005 Q6006 Q6009 Q6010 IC6002 TP6001 TP6002 IC6003 TP6003 TP6004 --- VOLTAGE CHART TP6005 AG-513F/AG-520F TP6006...
  • Page 136 131.1 131.1 - - - - - - - - - - - - - - - - Q352 Q352 AG-513F - - - - - - - - 127.9 127.9 AG-520F - - - - - - - -...
  • Page 137 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - AG-513F TV/VCR MAIN C.B.A. - - - - - - - - AG-520F - - - - - - - - +0.26Vp-p...
  • Page 138 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - AG-513F CRT C.B.A. CRT C.B.A. - - - - - - - -...
  • Page 139 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - AG-513F - - - - - - - - AG-520F HEAD AMP C.B.A.

  • Page 140: Power Supply Block Diagram

    (SYS. CTL) TP1070 Q1071 C1072 D1071 PR1070 SMOOTHING SW-5V RECTIFIER REGULATOR CIRCUIT D1016 Q1070 SWTICHING PWER ON-ON IC1001 (ERROR VOLTAGE DET) (WITH TV STEREO) IC1002 SHUNT REGULATOR TP892 IC801 TP891 +130V (TO T551(9)) REGULATOR +130V POWER SUPPLY BLOCK DIAGRAM AG-513F/AG-520F...

  • Page 141: Video Signal Path Block Diagram

    CCD 1H DELAY NOT USED VIDEO (FROM IC5301(31)) R HEAD P3503 3.58MHz Q3001 BUFFER IC3201 TP3001 (TO IC5301(1)) PB VIDEO (FROM IC6001(23)) (TO IC5301(48)) HEAD SW PULSE TUNER VIDEO (TO IC5301(46)) (FROM IC6001(58)) LINE VIDEO PB(L) VIDEO SIGNAL PATH BLOCK DIAGRAM AG-513F/AG-520F...

  • Page 142: Audio Signal Path Block Diagram

    15.75kHz IC4501 (TV SOUND OUTPUT) EARPHONE TRAP TP4505 JACK Q4171 DC VOLTAGE AUDIO CONTROL OUTPUT AMP P4591 SPEAKER (FROM IC6001(19)) P4591 BEEPER (FROM IC6001(35)) AUDIO AMP MUTE(L) (FROM IC6001(32)) TV VOLUME CONTROL (WITH MONAURAL) AUDIO SIGNAL PATH BLOCK DIAGRAM AG-513F/AG-520F...

  • Page 143: System Control Block Diagram

    OSC 1 OPERATION SW6001 SAFETY TAB SW BUTTON PLAY REW/ KEY DATA 2 REC/TIME SAFETY TAB BROKEN(H) /REPEAT REVIEW Q6002 (TO IC3501(25)) STOP SW+12V VIDEO DELAY REC(H) KEY DATA 3 ----- POWER DELAY REC+12V /EJECT Q6001 SYSTEM CONTROL BLOCK DIAGRAM AG-513F/AG-520F...

  • Page 144: Servo Block Diagram

    (TO IC3001(49)) ROTARY SW CAP TORQUE LIMIT (WITH 4HEAD MODEL) SLOW HEAD AMP /STILL SELECT CYLINDER P6201 CONTROL SIGNAL (TO IC3501(32)) MOTOR INTEGRATION GENERATOR HEAD AMP SW DRIVE CYLINDER TP6208 TP6202 (FROM IC3501(33)) MOTOR ENVELOPE DET SERVO BLOCK DIAGRAM AG-513F/AG-520F...

  • Page 145: Tv / Y/C Process Block Diagram

    OVER DETECTOR VOLTAGE DETECTOR Q581 T551 OVER VIDEO+B ANODE IC502,Q501 CURRENT Q551, T501 HEATER FOCUS DETECTOR Q571 FLY BACK COLLECTOR SCREEN HORIZONTAL BUFFER TRANSFORMER D5304 DRIVE (FROM IC801(4)) +130V Q5302 NOT USED BUFFER TV / Y/C PROCESS BLOCK DIAGRAM AG-513F/AG-520F...
  • Page 146 FOR PROPER PARTS CONTENT FOR THE MODEL YOU ARE SERVICING, SAFETY D4171 Q4171 R4173 TP6006 R6115 TAB SW R4591 PLEASE REFER TO THE SCHEMATIC DIAGRAM AND PARTS LIST. AG-513F R4701 R6113 TP4002 R4172 R4592 D3091 D3092 R3302 C3303 - - - - - - - -...
  • Page 147 - - - - - - - - R365 - - - - - - - - - - - - - - - - LRP63004 AG-513F P3501 - - - - - - - - AG-520F LSJB2009 - - - - - - - - - - - - - - - - CRT C.B.A.
  • Page 148 - - - - - - - - - - - - - - - - Example: - - - - - - - - AG-513F The connections between C.B.A.s are shown below. - - - - - - - - AG-520F Ref.
  • Page 149 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 150 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 151 U7001 ENG36706GY UHF/VHF TUNER - - - - - - - - be sure to use the part number listed in the parts list. AG-513F REC AUDIO SIGNAL PB AUDIO SIGNAL Do not use the part number on this diagram.
  • Page 152 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 153 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 154 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...
  • Page 155 WHEN REPLACING ANY OF THESE COMPONENTS, D’ INCENDIE N’ UTILISERQUE DES FUSIBLE DE MÉME D’T INCENDIE N’I UTILISERQUE DES FUSIBLE DE MÉME AG-513F 1.6A 125/250V 4A 125/250V Do not use the part number on this diagram.
  • Page 156 - - - - - - - - - - - - - - - - be sure to use the part number listed in the parts list. AG-513F Do not use the part number on this diagram. - - - - - - - -...

This manual is also suitable for:

Ag-520f

Table of Contents
