- Page 1 TRANSLATED FROM ORIGINAL USER MANUAL REFRIGERATED FLOWER COUNTER L-BK 05/2022...
-
Page 2: Table Of Contents
Table of contents 1. Application and device code meaning 2. Product characteristics 3. Cooling system diagram 4. Wiring system 5. Wiring system diagram 6. Drawings 7. Positioning, start-up and operation 8. Maintenance 9. Transport and equipment 10. Temperature controller manual 11. - Page 3 Please read this user manual carefully before using the device and keep it for future reference. Following the manual's recommendations guarantees long-lasting and failure-free exploitation of the device IT IS FORBIDDEN 1. Make repairs on your own and fail to comply with the rules contained in this manual regarding the connection and operation of the device;...
-
Page 4: Application And Device Code Meaning
1. APPLICATION AND DEVICE CODE MEANING The device is stationary-type equipment intended for storing and expose food cut flowers at a reduced temperature. DEVICE CODE MEANING Example of device code: L-BK/118/95 – type of the device: refrigerated counter – model: flower counter – device 118/95... -
Page 5: Product Characteristics
2. PRODUCT CHARACTERISTICS rated voltage: 230V~ / 50Hz refrigerant: HC-290; ODP = 0, GWP = 3 +1°C ÷ +10°C working temperature: sound pressure level: <70dB (A) Catalogue length/depth Device height Maximum quantity of Maximum Exposition of the device [mm] containers for load... -
Page 6: Wiring System Diagram
5. WIRING SYSTEM DIAGRAM SPR – compressor WA – aggregate switch MS – condenser fan MN – evaporator fan CKO – defrost ending sensor CRT – electronic temperature regulator sensor REG – electronic temperature controller... -
Page 7: Drawings
6. DRAWINGS mirror side glass pane front glass pane air guide glass pane evaporator insert shelf (exposition elevation) defrost water collection container condenser compressor... - Page 8 Pic. supports for mirror on pins (for mirror closing during shop being closed) bumpers supporting mirror on C-shape of side glass panes mirror * electronic temperature controller pocket for price list cover for defrost water collection container 4 swivel wheels (2 with break) protective grid of aggregate aggregate switch B detail...
-
Page 9: Positioning, Start-Up And Operation
7. POSITIONING, START-UP AND OPERATION To ensure proper operation, the device should be placed in an area with a good air circulation, away from heat sources and sunlight, free from dust (the device is not dustproof), at ambient temperature from +16°C to +25°C – 3rd climatic class. The manufacturer is not responsible for interferences of the device operation in temperature beyond given range for 3 climatic class. -
Page 10: Transport And Equipment
9. TRANSPORT AND EQUIPMENT While transporting secure the device to prevent its overturning, damage of the paint coat and breaking of the glass elements. When handling the device do not press the glass elements, do not grab the door or aggregate protective crate to lift the device. It is best to use belts and place them under the frame, between the feet (so that the belts do not slide). - Page 11 6. ALARM The symbol is visible when there is alarm activated. SWITCHES DESCRIPTION Information: Short pressing of any of the switches causes appearance of message related to the currently active function. 7. UP / ON OFF During normal operation of the controller; pressed for longer than 3 sec. will cause change of controller ON/OFF operation state, pressed along with the “DOWN”...
- Page 12 Set point setting (desired temperature value) To view and modify the set point: press the “SET” switch for 1 sec. – the set value will start flashing; increase or decrease the value using the “UP” or “DOWN” switches; ...
- Page 13 Symbol Parameter Unit Fabric setting min. max. Alarm bypass time after defrost °C Alarm and fan temperature differential Absolute or relative temperature for low °C temperature alarm Absolute or relative temperature for high °C temperature alarm Temperature alarm delay High temperature alarm activation = setting + AH High temperature alarm deactivation = setting + AH –...
-
Page 14: Notes
– – In certain operating conditions, the instrument may detect errors data errors in the data saved. These errors may compromise the correct operation of the instrument. If the microprocessor detects a data saving error, the display shows the message “EE”. If the fault persists, the controller needs to be replaced. If, on the other hand, the message disappears, it can continue to be used. -
Page 15: Interferences
12. INTERFERENCES The most often occurring interferences of the device operation: Reasons Symptoms Solution Contaminated Before cleaning of the condenser it is Visible dust layer on the condenser fins, condenser necessary to switch the device off. hot air coming out of the aggregate chamber, Impurities on the condenser should be ... - Page 16 Poland. The package should be removed according to the regulations of environmental protection. ”RAPA” S. Międlar W. i I. Szymańscy sp. j. Poland, 20-149 Lublin, 9 Ceramiczna Street BDO 000009031 SERVICE tel. +48 81 718 46 50 / 51 e-mail: service@rapa.pl...
