VB-STND-008
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.
Model No. VS18670
P/N: VB-STND-008
Advertisement
Table of Contents
Related Manuals for ViewSonic VB-STND-008
Summary of Contents for ViewSonic VB-STND-008
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Safety Precautions
• This product has no parts which can be repaired by the user. Any damage caused by the user's own disassembly is not covered by warranty. • This product is special use with ViewSonic® commercial Touch Display only, Use with other model is capable of resulting in instability causing possible injury. -
Page 4: Table Of Contents
Contents Safety Precautions ............3 Introduction ..............5 Package Contents ....................5 Product Overview ....................7 Front and Side View ....................7 I/O Ports and Controls ....................7 Control Pad ......................8 Initial Setup ..............9 Assembling the Product ..................9 Storing the Caster Covers ..................17 Making Connections .......... -
Page 5: Introduction
Introduction Package Contents Letter Item Quantity Description Note Bolts M6 x 14mm Nuts Bolts M5 x 25mm Bolts M6 x 25mm Bolts M8 x 25mm Bolts M4 x 8mm Hex Tool Wrench Left Covers x2 Caster Covers Right Covers x2 Attachable Cord Clamps Control Pad USB Type A to... - Page 6 Letter Item Quantity Description Note 2 (one Trolley Bases per side) Mounting Brackets Power Extension Cord Power Cord Keyboard Tray NOTE: The power cord included in your package may vary depending on your country. Please contact your local reseller for more information.
-
Page 7: Product Overview
Product Overview Front and Side View I/O Ports and Controls Label Port Description USB A USB A Port Lift Up/Down, Tilt Up/Down Buttons Adjust Lift Height RJ45 RJ45 Port AC Out Power Output Socket AC In Power Input Socket Only use the USB-A port to connect with IFP. Lift can be controlled via the app on the IFP. Only use the RJ45 port to connect with the Control Pad. -
Page 8: Control Pad
Control Pad Lift Up Lift Down Tilt Up Tilt Down... -
Page 9: Initial Setup
Initial Setup Assembling the Product Step 1 1. Prepare the following items: Trolley Body Trolley Base 2. Align the three holes on the Trolley Base (M) to the bolts underneath the Trolley Body. Using the wrench (H), secure the Trolley Base to the Trolley Body with the nuts (B). - Page 10 3. Ensure all nuts are tightened properly on the assembled Trolley Cart. Trolley Cart...
- Page 11 Step 2 Attach the Mounting Brackets (N) to the IFP. Depending on the size of the IFP, use either M5 (C), M6 (D), or M8 (E) bolts. Refer to the IFP user guide to find the right bolt size. NOTE: This product does not include an IFP. Step 3 Attach the Keyboard Tray (Q) to the middle support.
- Page 12 Step 4 1. Lift the IFP up and hook the Mounting Brackets onto the Trolley Cart. NOTE: It is recommended to perform this step with two or more people to avoid personal injury and/or damage to the IFP and Trolley Cart. 2.
- Page 13 Step 5 1. Unscrew the M4 x 8mm bolts (F) and remove the Protective Cover from the Trolley Cart. Attach the Chrome Box onto the Trolley Cart. NOTE: This product does not include an Chrome Box. Protective Cover...
- Page 14 2. Reattach the Protective Cover onto the Trolley Cart with the M4 x 8mm bolts, covering the Chrome Box. 3. Ensure all parts are accurately and securely held together, as shown in the diagrams below.
- Page 15 Step 6 After moving the Trolley Cart to desired location, push down on the wheel brakes to lock the Trolley Cart in place.
- Page 16 Step 7 Install the Caster Covers (I) to further secure the Trolley Cart in place NOTE: It is recommended to install the Caster Covers to avoid personal injury and/or damage to the IFP and Trolley Cart 1. Ensure the wheels are aligned with the Trolley Cart. 2.
-
Page 17: Storing The Caster Covers
Storing the Caster Covers The Caster Covers are magnetic. Refer to the diagram below for the position of the magnet. When moving the Trolley Cart, attach the Caster Covers to the left and right supports. -
Page 18: Making Connections
Making Connections Connecting to Power 1. Connect the power cord to the Trolley Cart. 2. Connect the power cord to a power outlet. 3. Use the cord clamp to secure the cords in place. 18 18... -
Page 19: Connecting To The Control Pad
Connecting to the Control Pad Connect the Control Pad to the Trolley Cart via the RJ45 Port. NOTE: The Control Pad has a magnet on the back. The Control Pad can be attached to any metal zone on the Trolley Cart. Make sure the attached area does not obstruct the Lift functions. -
Page 20: Connecting To The Ifp
Connecting to the IFP 1. Connect the IFP to the AC power output of the Trolley Cart. 2. Connect the USB Type A cord to both the IFP and the Trolley Cart. HDMI IN TOUCH OUT AUDIO OUT AUDIO IN SPDIF RS232 12 13... -
Page 21: Controlling The Lift
Press and hold to raise the VB-STND-008. Lift Up Press and hold to lower the VB-STND-008. Lift Down Press and hold to tilt the VB-STND-008 backward. Tilt Up Press and hold to tilt the VB-STND-008 forward. Tilt Down 21 21... -
Page 22: Using The App On The Ifp
Using the app on the IFP 1. Select the More Options Icon (...) from the side tool bar. 2. Select Trolley Cart Control. - Page 23 Lift Up Press and hold to raise the VB-STND-008. Lift Down Press and hold to lower the VB-STND-008. Press and hold to tilt the VB-STND-008 forward. Tilt Down Tilt Up Press and hold to tilt the VB-STND-008 backward. Adjust the Lift to desired height. Long press to save Preset Position 1 current height as Preset Position 1.
-
Page 24: Appendix
Appendix Specifications Item Specifications Swivel 360° by 4” silent wheel Height Adjust 560 mm (22.05 in) Range Wall Mount 800 x 600 mm max. Pattern Material Aluminum Alloy, Plastic, Steel Wall Mount 75 kg max. (165 lb max.) Loading Keyboard Tray 10 kg max. -
Page 25: Troubleshooting
Troubleshooting This section describes some common problems that you may experience when using the Trolley Cart. Problem or Issue Possible Solutions • Plug another electrical device into the power outlet to verify that the outlet is supplying power. • Ensure the power cord is properly and securely connected to No power the device and power outlet. -
Page 26: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 27: Declaration Of Rohs2 Compliance
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law. -
Page 28: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®... -
Page 29: Copyright Information
VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 30: Customer Service
