- Page 1 Cisco 827 and SOHO 77 Routers Hardware Installation Guide Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 526-4100 Customer Order Number: DOC-786854= Text Part Number: 78-6854-03...
- Page 2 Modifications to this product not authorized by Cisco Systems, Inc. could void the FCC approval and negate your authority to operate the product. The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system.
-
Page 3: Table Of Contents
C H A P T E R Preparing for Installation Safety Unpacking the Box Preventing Router Damage Mounting the Router Mounting on a Table Mounting on a Wall Installing the Router 78-6854-03 viii viii viii Cisco 827 and SOHO 77 Routers Hardware Installation Guide Preface... - Page 4 A P P E N D I X System Specifications Port Connector Pinouts Cabling Specifications Ethernet Cable Specifications Maximum Cable Distances N D E X Cisco 827 and SOHO 77 Routers Hardware Installation Guide 2-11 2-12 2-14 2-15 2-16 2-16...
-
Page 5: Preface
This symbol means reader be careful. In this situation, you might do something that could result in equipment damage or loss of data. 78-6854-03 Overview”—Describes the Cisco 827 and SOHO 77 routers and their features. “Installation”—Provides information on preinstallation, mounting, connecting, and “Troubleshooting”—Describes problems with the router and how to identify and solve Cables”—Provides Cisco part numbers for cables that you can... - Page 6 Antes de começar a trabalhar com qualquer equipamento, familiarize-se com os perigos relacionados com circuitos eléctricos, e com quaisquer práticas comuns que possam prevenir possíveis acidentes. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Preface 78-6854-03...
-
Page 7: Related Documentation
Related Documentation In addition to this Cisco 827 Routers and SOHO 77 Hardware Installation Guide, the documentation for the Cisco 827 routers includes the following: Cisco 820 Series and SOHO Series Router Cabling and Setup Quick Start Guide •... -
Page 8: Ordering Documentation
Nonregistered Cisco.com users can order documentation through a local account representative by • calling Cisco Systems Corporate Headquarters (California, USA) at 408 526-7208 or, elsewhere in North America, by calling 1 800 553-NETS (6387). Documentation Feedback You can send comments about technical documentation to bug-doc@cisco.com. -
Page 9: Reporting Security Problems In Cisco Products
Access to all tools on the Cisco Technical Support Website requires a Cisco.com user ID and password. If you have a valid service contract but do not have a user ID or password, you can register at this URL: http://tools.cisco.com/RPF/register/register.do 78-6854-03 security-alert@cisco.com psirt@cisco.com Cisco 827 and SOHO 77 Routers Hardware Installation Guide Obtaining Technical Assistance... -
Page 10: Submitting A Service Request
You and Cisco will commit resources during normal business hours to restore service to satisfactory levels. Severity 4 (S4)—You require information or assistance with Cisco product capabilities, installation, or configuration. There is little or no effect on your business operations. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Preface 78-6854-03... -
Page 11: Obtaining Additional Publications And Information
• iQ Magazine is the quarterly publication from Cisco Systems designed to help growing companies learn how they can use technology to increase revenue, streamline their business, and expand services. The publication identifies the challenges facing these companies and the technologies to help solve them, using real-world case studies and business strategies to help readers make sound technology investment decisions. - Page 12 Preface Obtaining Additional Publications and Information Cisco 827 and SOHO 77 Routers Hardware Installation Guide 78-6854-03...
-
Page 13: Chapter 1 Product Overview
Product Overview The Cisco 827 and SOHO 77 routers can connect a corporate telecommuter or small office to an Internet service provider (ISP) over asymmetric digital subscriber line (ADSL) lines to the following types of networks: Corporate LANs • Internet •... -
Page 14: Features
Wall-mounting feature Router Overview Table 1-2 tells how many Ethernet and telephone ports each Cisco 827 router and SOHO 77 router has. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Description Provides connection to 10BASE-T (10-Mbps) Ethernet networks. Compatible with 10/100-Mbps devices. -
Page 15: Front Panels
A D SL CD RX D TX D A D S L Figure 1-5 show the front panels of the SOHO 77 routers. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Router Overview R X D T X D... -
Page 16: Back Panels
TO H U B TO PC TO HUB/TO PC button Determines cable type for Ethernet device connection. Cisco 827 and SOHO 77 Routers Hardware Installation Guide CD RX D TX D A D SL CD RX D TX D A D S L Figure 1-8 show the back panels of the Cisco 827 routers. - Page 17 8 2 7 AD SL Console port Connects to PC or terminal Figure 1-10 show the back panels of the SOHO 77 routers. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Router Overview Power switch = On. = Standby or no...
-
Page 18: Leds
On when power is supplied to the router and when the router completes the self-test procedure and begins operating. PHONE 1, 2, 3, 4 Green On when basic telephone service is in use. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Ethernet ports Connect to ADSL port Ethernet network... - Page 19 ETHERNET 1, 2, 3, 4 Green ETHERNET RXD ETHERNET TXD Table 1-5 summarizes the function of the LEDs on the Cisco 827 router and SOHO 77 router. Table 1-5 LED Functions on Cisco 827 Router and SOHO 77 Router Color...
- Page 20 Chapter 1 Product Overview Router Overview Cisco 827 and SOHO 77 Routers Hardware Installation Guide 78-6854-03...
-
Page 21: Chapter 2 Installation
Preventing Router Damage Mounting the Router • • Installing the Router Using the Router LEDs to Check Links • Configuring the Router • 78-6854-03 C H A P T E R Cisco 827 and SOHO 77 Routers Hardware Installation Guide... -
Page 22: Preparing For Installation
European Union standards. Connecting the port to this type of public network can cause severe injury or damage your router. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Chapter 2 ) appears above a port, you must not connect the... -
Page 23: Unpacking The Box
Power cord (black) • Desktop power supply • Console cable, RJ-45-to-DB-9 (light blue) • • ADSL cable (lavender) Ethernet cable (yellow) • Product documentation • 78-6854-03 Router Box Contents Cisco 827 and SOHO 77 Routers Hardware Installation Guide Preparing for Installation... -
Page 24: Preventing Router Damage
If you plan to configure the software using a terminal or PC connected to the router, provide the terminal Step 4 or PC. If you plan to use the cable lock feature available on the Cisco 827, SOHO 77, and Cisco 827-4V routers, Step 5 you must provide a Kensington or equivalent locking cable. -
Page 25: Mounting The Router
78-6854-03 shows the mounting brackets. Front panel of router Mounting 7 in. (19.35 cm) bracket Bottom of router Cisco 827 and SOHO 77 Routers Hardware Installation Guide Mounting the Router Mounting bracket... -
Page 26: Installing The Router
Connect the Ethernet devices to the router. Connect the ADSL line. Connect an optional analog telephone or fax machine. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Figure 2-2. The last page of this manual provides a template for... -
Page 27: Connect Ethernet Devices
Connect Ethernet Devices Table 2-2 lists the Ethernet devices you can connect to Cisco 827, Cisco 827-4V, and SOHO 77 routers; the connections for each device; and the settings of the router TO HUB/TO PC button (the default setting is IN). - Page 28 Cisco 1528 Micro Hub 10/100 with an MDI/MDI-X button as an example. Determine the button name and setting for your particular hub. See your hub documentation for details. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Router TO Ethernet Cable...
- Page 29 4. If applicable, check setting of hub equivalent of router TO HUB/TO PC. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Installing the Router 2-3. 1. Set TO HUB/TO PC button. Cisco 827H and...
- Page 30 Connecting a Server, PC, or Workstation to the Router To verify the connection, check that the Ethernet 1 LED is on after you complete the router installation. Cisco 827 and SOHO 77 Routers Hardware Installation Guide 2-10 1. Set TO HUB/TO PC button.
-
Page 31: Connect An Adsl Line
ADSL line to a cable wall jack. router, but the process is the same for Cisco 827, Cisco 827H, SOHO 77, and SOHO 77H routers.) Do not work on the system or connect or disconnect cables during periods of lightning activity. -
Page 32: Connect An Analog Telephone Or Fax Machine (Cisco 827-4V Routers Only)
For example, in the United Kingdom, you must buy an adapter that also provides a master socket, which causes incoming calls to ring the connected devices. For information on recommended master sockets, see Cisco 827 and SOHO 77 Routers Hardware Installation Guide 2-12 M od el C is... -
Page 33: Connect A Terminal Or Pc To The Router's Console Port (Optional)
(CLI) or for troubleshooting. To connect a terminal or PC, follow the steps in applies to connecting all Cisco 827 series routers and SOHO 77 series routers.) Unless you are an experienced network administrator, it is recommended that you use the Cisco Router Note Web Setup software to configure the router. -
Page 34: Connect The Ac Adapter
Connect the AC Adapter To connect the power supply, follow the steps in but the process is the same for the Cisco 827, Cisco 827H, SOHO 77, and SOHO 77H routers.) The device is designed to work with TN power systems. -
Page 35: Using The Router Leds To Check Links
Use the LEDs on the front of the router to check the links between the router and attached Ethernet devices or telephones. Use 827-4V, and SOHO 77 routers. Table 2-5 LED Patterns for CIsco 827, Cisco 827-4V and SOHO 77 Routers Power/Link LEDs to Check Power... -
Page 36: Configuring The Router
In Netscape, the default selection in the File menu is set to work online. Step 3 Type in the universal resource locator (URL) http://10.10.10.1. The CRWS home page will appear in one or two minutes. Cisco 827 and SOHO 77 Routers Hardware Installation Guide 2-16 Chapter 2 Installation... - Page 37 The router installation is complete when you have connected to a website. 78-6854-03 Configuration," add TCP to the list of protocols. Then return to 2-16," and complete the procedure. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Configuring the Router Step 3 “Using Cisco...
- Page 38 Chapter 2 Installation Configuring the Router Cisco 827 and SOHO 77 Routers Hardware Installation Guide 2-18 78-6854-03...
-
Page 39: Chapter 3 Troubleshooting
Troubleshooting This chapter describes symptoms of problems that could occur with the Cisco 827 or SOHO 77 routers, identifies the likely underlying problems, and provides steps for solving the problems. The problems are grouped into the following areas: Problems during first startup •... -
Page 40: Problems During First Startup
Improperly • connected cable. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Solutions Perform the following steps: Make sure that the power switch is set to ON. Make sure that all connections to and from the power supply are secure. -
Page 41: Problems After Router Is Running
Contact your ADSL line or WAN ADSL line or WAN service provider to determine whether service. there is a problem with the ADSL or WAN service. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Problems After Router Is Running... - Page 42 Chapter 3 Troubleshooting Problems After Router Is Running Cisco 827 and SOHO 77 Routers Hardware Installation Guide 78-6854-03...
-
Page 43: Appendix
32 to 104°F (0 to 40°C) 10 to 85% relative humidity 0 to 10,000 ft (3000 m) 100 to 250 VAC 50 to 60 Hz 100 to 240 VAC 50 to 60 Hz Cisco 827 and SOHO 77 Routers Hardware Installation Guide... -
Page 44: Port Connector Pinouts
Unused Unused Table A-3 shows the Ethernet connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H, SOHO 77, and SOHO 77H routers. Cisco 827 and SOHO 77 Routers Hardware Installation Guide Design Specification -24V and -71V Table A-2. Table Table A-4. - Page 45 Appendix A Specifications and Cables Table A-3 Console Connector Pinouts (RJ-45) 78-6854-03 Function Cisco 827 and SOHO 77 Routers Hardware Installation Guide Port Connector Pinouts...
- Page 46 Cisco 827-4V router. Table A-4 Cisco 827-4V Router Telephone Connector Pinouts (RJ-11) Table A-5 shows ADSL connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H, SOHO 77, and SOHO 77H routers. Table A-5 ADSL Connector Pinouts (RJ-11)
-
Page 47: Cabling Specifications
Appendix A Specifications and Cables Table A-6 shows the power connector pinouts for the Cisco 827, Cisco 827-4V, and SOHO 77 routers. Table A-6 Cisco 827, Cisco 827-4V, and SOHO 77 Power Connector Pinouts Table A-7 shows the power connector pinouts for the Cisco 827H and SOHO 77H routers. -
Page 48: Cabling Specifications
Ethernet and telephone cables that you can use to connect equipment to the router. Table A-9 Maximum Cable Distances Cable Ethernet cables Telephone cable Cisco 827 and SOHO 77 Routers Hardware Installation Guide Category Shielding Category 3 or 5 Shielded twisted-pair (STP) – Unshielded twisted-pair (UTP) -
Page 49: I N D E X
1-3, 1-4 ETHERNET RXD LED 2-15 ETHERNET TXD LED 2-15 European Union standards fax machine, connecting 2-12 feature summary Flash memory frequency specifications front panels (figure) Cisco 827 and SOHO 77 Routers Hardware Installation Guide I N D E X IN-1... - Page 50 2-13 mounting router note statements defined PC, connecting 2-10, 2-13 PHONE LEDs 2-15 pinouts ports, for specific routers Cisco 827 and SOHO 77 Routers Hardware Installation Guide IN-2 power problems specifications power connector, locking power supply connecting 2-14 power switch (figure)
- Page 51 2-3, ?? to 2-3 voltage specifications A-1, A-2 wall brackets (figure) wall mounting 2-5, 2-6 warnings, installation warning statements defined weight specifications workstation, connecting 2-10 78-6854-03 Cisco 827 and SOHO 77 Routers Hardware Installation Guide Index IN-3...
- Page 52 Index Cisco 827 and SOHO 77 Routers Hardware Installation Guide IN-4 78-6854-03...
