SERVICE MANUAL
Ver 1.0 2001. 09
• MHC-DP1000D is composed of following models.
As for the service manual, it is issued for each component model,
then, please refer to them.
COMPONENT MODEL NAME
DVD DECK
RECEIVER SYSTEM
SS-DP1000DW (US,CND,AEP,UK)
FRONT SPEAKER
SS-DP1000D
REAR SPEAKER
SPEAKER
SS-RC270
SYSTEM
CENTER SPEAKER
SPECIFICATIONS
General
Power requirements
North American model:
European model:
Australian model:
Mexican model:
Thailand model:
Indian, Pakistani, Moroccan and Tunisian models:
Other models:
Power consumption
U.S.A. model:
Canadian model:
European model:
Other models:
Dimensions (w/h/d)
Mass
North American and European models:
Other models:
Supplied accessories:
Design and specifications are subject to change without notice.
Sony Corporation
9-873-315-01
2001I0200-1
Home Audio Company
© 2001.9
Sinagawa Tec Service Manual Production Group
MHC-DP1000D
HCD-DP1000D
(EXCEPT US,CND,AEP,UK)
SS-RS270
SS-CT270
120 V AC, 60 Hz
230 V AC, 50/60 Hz
230 – 240 V AC,
50/60 Hz
120 V AC, 60 Hz
220 V AC, 50/60 Hz
220 V AC, 50/60 Hz
120 V, 220 V or
230 – 240 V AC,
50/60 Hz
Adjustable with voltage
selector
205 watts
205 watts
190 watts
0.5 watts (at the Power
Saving Mode)
225 watts
Approx. 280 x 360 x 365mm
Approx. 11.0 kg
12.0 kg
AM loop antenna (1)
FM lead antenna (1)
Remote commander (1)
Batteries (2)
Video cable (1)
Front speaker pads (8)
Center and rear speaker
pads (12)
• Abbreviation
CND: Canadian model
SP : Singapore model
MY : Malaysia model
EA : Saudi Arabia model
PARTS LIST
Part No.
Description
Remark
ACCESSORIES
************
1-476-445-11
REMOTE COMMANDER (RM-SD270)
1-501-374-11
ANTENNA, LOOP
1-501-594-11
ANTENNA (FM)(AEP,UK)
1-501-659-71
ANTENNA (FM)(EXCEPT AEP,UK)
1-558-848-11
CORD, SPEAKER (SS-DP1000D/DP1000DW)(3m)
1-769-433-11
CORD, SPEAKER (SS-RS270) (10m)
1-769-433-41
CORD, SPEAKER (SS-CT270) (2.5m)
1-782-981-21
CORD, CONNECTION
4-210-254-01
CUSHION (FOOT)
4-232-032-01
COVER, BATTERY (FOR RM-SD270)
4-232-734-11
MANUAL, INSTRUCTION (SS-DP1000DW)
(ENGLISH,FRENCH,GERMAN,SPANISH,DUTCH,SWEDISH,
ITALIAN,PORTUGUESE,TURKISH,POLISH,HUNGARIAN,
GREEK,FINNISH,DANISH,CZECH,RUSSIAN)
4-232-961-01
FOOT (SS-RC270)
4-236-762-11
MANUAL, INSTRUCTION (ENGLISH)
4-236-762-21
MANUAL, INSTRUCTION (FRENCH)(CND,EA)
4-236-762-31
MANUAL, INSTRUCTION (SPANISH)(MX)
4-236-762-41
MANUAL, INSTRUCTION (ENGLISH,FRENCH,SPANISH)
4-236-762-51
MANUAL, INSTRUCTION (GERMAN,DUTCH,ITALIAN)(AEP)
4-236-762-61
MANUAL, INSTRUCTION (SWEDISH,POLISH)(AEP)
4-236-762-71
MANUAL, INSTRUCTION (ARABIC)(EA)
4-236-762-81
MANUAL, INSTRUCTION (TRADITIONAL CHINESE)(SP,MY)
4-236-763-11
MANUAL, INSTRUCTION (DANISH,FINNISH)(AEP)
4-236-763-21
MANUAL, INSTRUCTION (PORTUGUESE)(AEP)
4-236-763-31
MANUAL, INSTRUCTION (GREEK)(AEP)
4-236-763-41
MANUAL, INSTRUCTION (HUNGARIAN,CZECH)(AEP)
4-236-763-51
MANUAL, INSTRUCTION (TURKISH)(AEP)
4-236-763-61
MANUAL, INSTRUCTION (SLOVAK)(AEP)
4-236-764-11
MANUAL, INSTRUCTION (ENGLISH,THAI)(TH)
MINI Hi-Fi COMPONENT SYSTEM
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
E91 : 220V AC area model
AUS : Australian model
MX : Mexican model
TH : Thai model
(US,CND,UK,AUS,E91,EA)
(AEP,E)
