Using the Built-in Tilt Stand
Complete
Figure
You can use the stand to place the camera on the floor or table
to shoot from a low angle or when taking a selfie.
1. ① Place your finger at the
indent of the stand located
at the bottom of this unit.
② Move your finger in the
direction of the arrow.
・The front edge of the stand lifts
up.
2. ① Lift the stand upright.
② Slide the stand in the
direction of the arrow to the
position indicated by the
line in the figure.
If the stand does not move, do
・
not force it. Proceed to step 3.
3. Tilt the stand as shown in the figure.
Place the camera as shown in the
・
complete figure.
■ Storing the stand
① Lift the stand upright and slide
it in the direction of the arrow.
② Align the marks on the camera
Indent
and the stand.
③ Flip the stand down to store.
Front Edge
Caution
If the stand is detached, reattach the stand immediately as instructed in the
Detailed User Guide to avoid losing it or accidentally swallowing it.
Dtailed User Guide: http://manual3.jvckenwood.com/c4g/ah/
Approx. 2 mm
B5H-0029-00
C4G
0514TOH-SW-VM
Mark
