Figure 1 Cisco VT Camera Components and Connections
3
1
4
1
Cisco VT Camera
2 USB cable and connector
3 Privacy shade (attaches to the
camera)
6
2
5
6
4
Flexible camera base
5 Opening on the bottom of the
camera
6 Tab on the flexible camera base
(snaps into the opening on the
bottom of the camera)
