ProCurve Switch vl Modules
Specifications
Port Type Cable Specifications
10-GbE SR Multimode fiber-optic cable designed for Gigabit
Ethernet: 62.5/125 μm (core/cladding) diameter
or 50/125 μm, low metal content,
complying with the ITU-T G.652 and ISO/IEC 793-
2 Type B1 standards.
9/125 μm (core/cladding) diameter, low metal
10-GbE LR
content, single mode fiber-optic cables,
complying with the ITU-T G.652 and ISO/IEC 793-
2 Type B1 standards.
9/125 μm (core/cladding) diameter, low metal
10-GbE ER
content, single mode fiber-optic cables,
complying with the ITU-T G.652 and ISO/IEC 793-
2 Type B1 standards.
Note: Conditioning patch cord cables are not supported.
12 fiber 50/125 μm (core/cladding) diameter,
CX4 Media
Converter multimode Fiber ribbon cable. 12 fiber 62.5/125
μm (core/cladding) diameter, multimode Fiber
ribbon cable is also supported.
Port Type Cable Specifications
CX4 Shielded twisted-pair cables complying with the
802.3ak standard.
30

Fiber-Optic Cables

Copper 10-GbE Cables

Connector Supported Length
Type
62.5 μm cable:
SC ■
• 160 Mhz*km = 2-26 meters
• 200 Mhz*km = 2-33 meters
50 μm cable:
■
• 400 Mhz*km = 2-66 meters
• 500 Mhz*km = 2-82 meters
• 2000 Mhz*km = 2-300 meters
SC single-mode cable: 2 meter - 10 km
SC single-mode cable: 2 meters - 30 km (40
kilometers, on an engineered fiber optic
link that meets standards in the
specification).
MTP 1-300 meters
Connector Supported Length
Type
CX4 0.5-15 meters
