TRANSLATION OF THE ORIGINAL INSTRUCTIONS
We advise you to read this manual carefully, as it contains all the instructions for maintaining
the appliance's aesthetic and functional qualities.
For further information on the product: www.smeg.com
Table of contents
54
54
58
59
59
59
59
60
61
61
62
62
63
63
64
64
66
68
68
69
69
71
73
78
79
80
82
84
86
88
88
91
96
101
102
53
Advertisement
Table of Contents
Related Manuals for Smeg BG91CTN2
Summary of Contents for Smeg BG91CTN2
-
Page 1: Table Of Contents
5.4 Electrical connection 5.5 Instructions for the installer TRANSLATION OF THE ORIGINAL INSTRUCTIONS We advise you to read this manual carefully, as it contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com... -
Page 2: Instructions
Instructions 1 Instructions • Cleaning and maintenance must not be carried out by 1.1 General safety instructions unsupervised children. Risk of personal injury • Make sure that the flame- spreader crowns are correctly • During use the appliance and positioned in their seats with its accessible parts become their respective burner caps. - Page 3 Instructions • Keep the oven door closed • Before any operation on the during cooking. appliance (installation, maintenance, positioning or • If you need to move food or at movement) always wear PPM. the end of cooking, open the door 5 cm for a few seconds, •...
- Page 4 Instructions • Do not sit on the appliance. • Remove all trays and racks which are not required during • Racks and trays should be cooking. inserted as far as they will go into the side guides. The • Do not cover the bottom of the mechanical safety locks that oven cavity with aluminium or prevent them from being...
- Page 5 Instructions • Do not put empty pans or frying Installation pans on switched on cooking • THIS APPLIANCE MUST NOT zones. BE INSTALLED IN A BOAT OR • Do not use rough or abrasive CARAVAN. materials or sharp metal • This appliance must not be scrapers.
-
Page 6: Manufacturer Liability
Instructions • The adjustment conditions for • Have the electrical connection this appliance are shown on performed by authorised the gas setting label. technicians. • Have the gas connection • The appliance must be performed by authorised staff. connected to ground in •... -
Page 7: Appliance Purpose
Instructions • use of non-original spare parts. 1.6 Disposal This appliance conforms to the 1.3 Appliance purpose WEEE European directive • This appliance is intended for (2012/19/EU) and must be cooking food in the home disposed of separately from other waste at the end of its service life. -
Page 8: How To Read The User Manual
Instructions • Deliver the appliance to the 1.7 How to read the user manual appropriate recycling centre for This user manual uses the following reading electrical and electronic conventions: equipment waste, or return it to Instructions the retailer when purchasing an General information on this user equivalent product, on a one for manual, on safety and final... -
Page 9: To Save Energy
Instructions 1.8 To save energy 1.9 Information for European Control Bodies • Only preheat the appliance if the recipe requires you to do so. Fan forced mode • Unless otherwise indicated on the the ECO function used to define the energy package, defrost frozen foods efficiency class complies with the specifications of European standard EN... -
Page 10: Description
Description 2 Description 2.1 General Description 1 Upstand 6 Door 2 Cooking hob 7 Fan 3 Control panel 8 Storage compartment 4 Light bulb Rack/tray support frames 5 Seal... -
Page 11: Cooking Hob
Description 2.2 Cooking hob AUX = Auxiliary burner R = Rapid burner SR = Semi-rapid burner UR = Ultra-rapid burner 2.3 Control panel 1 Programmer clock 3 Indicator light For displaying the current time, setting The indicator light comes on to indicate that programmed cooking operations and the the oven is heating up. -
Page 12: Other Parts
Description 5 Hob burner knobs Cooling fan For lighting and adjusting the hob burners. The fan cools the ovens and comes into operation during cooking. Press and turn the knobs anti-clockwise to The fan causes a steady outflow of air that in order to light the relative burners. - Page 13 Description Rack Self-cleaning panels (on some models only) Used for supporting containers with food Useful for absorbing small grease residues. during cooking. Not all accessories are available Tray rack on some models. The oven accessories intended to come into contact with food are made of materials that comply with the provisions of current legislation.
-
Page 14: Use
3 Use High temperature inside the storage compartment Instructions Danger of burns High temperature inside the oven • Do not open the storage compartment during use when the appliance is on and still hot. Danger of burns • The items inside the storage compartment could be very hot after •... - Page 15 Malfunctions High temperature inside the storage compartment Any of the following indicate a malfunction and you should contact a service centre. Danger of fire or explosion • Yellowing of the burner plate. • Do not spray any spray product near •...
-
Page 16: Using The Accessories
3.1 Using the accessories 3.2 Using the hob All the appliance’s control and monitoring Racks and trays devices are located together on the front Racks and trays have to be inserted into the panel. The burner controlled by each knob side guides until they come to a complete is shown next to the knob. -
Page 17: Using The Storage Compartment
Correct positioning of the flame- 3.3 Using the storage compartment spreader crowns and burner caps The storage compartment is at the bottom of the cooker. To open it, pull the handle Before lighting the hob burners, make sure towards you. It can be used to store that the flame-spreader crowns are cookware or metallic objects necessary correctly positioned in their housings with... - Page 18 Functions list Grill The heat coming from the grill Static element gives perfect grilling results As the heat comes from above and above all for thin and medium below at the same time, this system thickness meat and, in combination is particularly suitable for certain with the rotisserie (where fitted), types of food.
-
Page 19: Cooking Advice
3.5 Cooking advice Fan with round heating element The combination of the fan and the General advice round heating element (incorporated • Use a fan assisted function to achieve in the rear of the oven) allows you to consistent cooking at several levels. cook different foods on several •... - Page 20 • With the Grill function, we recommend Advice for defrosting and proving that you turn the temperature knob to the • Place frozen foods without their maximum value near the symbol packaging in a lidless container on the optimise cooking. first shelf of the oven.
-
Page 21: Programmer Clock
3.6 Programmer clock Setting the time If the time is not set, the oven will not switch on. On the first use, or after a power failure, the digits will be flashing on the appliance’s display. 1. Hold down the clock key for two seconds. - Page 22 Timed cooking 7. Press the clock key to reset the programmer clock. Timed cooking is the function which allows a cooking operation It is not possible to set a cooking to be started and then ended after time of more than 10 hours. a specific length of time set by the user.
- Page 23 10. Return the function and temperature 4. Use the key to set the knobs to 0. required minutes. (for example 1 hour) 11. To turn off the buzzer just press any key 5. Press the menu key . The text of the programmer clock.
- Page 24 Modifying the set data Minute minder timer 1. Press the clock key The minute minder timer does not stop the cooking operation but 2. Use the value increase and value rather informs the user when the set time has run out. decrease keys to set the number of minutes required.
- Page 25 Cooking information table Weight Temperature Time Food Function Shelf (kg) (°C) (minutes) Lasagne 3 - 4 Static 220 - 230 45 - 50 Pasta bake 3 - 4 Static 220 - 230 45 - 50 Roasted veal Turbo/Round 180 - 190 90 - 100 Pork loin Turbo/Round...
-
Page 26: Cleaning And Maintenance
Cleaning and maintenance 4 Cleaning and maintenance Ordinary daily cleaning Always use specific products only that do Instructions not contain abrasives or chlorine-based acids. Pour the product onto a damp cloth Improper use and wipe the surface, rinse thoroughly and Risk of damage to surfaces dry with a soft cloth or a microfibre cloth. -
Page 27: Cleaning The Hob
Cleaning and maintenance 4.1 Cleaning the hob Igniters and thermocouples For correct operation the igniters and Cooking hob grids thermocouples must always be perfectly Remove the grids and clean them in clean. Check them frequently and clean lukewarm water and non-abrasive them with a damp cloth if necessary. -
Page 28: Cleaning The Door
Cleaning and maintenance 4.2 Cleaning the door 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure Removing the door that grooved sections A are resting For easier cleaning it is recommended to completely in the slots. - Page 29 Cleaning and maintenance Removing the internal glass panes 5. Remove the intermediate glass pane by lifting it upwards. For easier cleaning the internal glass panes of the door can be removed. 1. Open the door. 2. Position the locking hooks in the hinge holes to prevent accidental closing of the door.
-
Page 30: Cleaning The Oven Cavity
Cleaning and maintenance 4.3 Cleaning the oven cavity Removing racks/trays support frames In order to keep your oven in the best Removing the rack/tray support frames possible condition, clean it regularly after enables the sides to be cleaned more letting it cool down. easily. - Page 31 Cleaning and maintenance Removing self-cleaning panels and rack/ Regeneration of self-cleaning panels tray support frames (fitted only to some (catalysis cycle) (on some models only) models) The regeneration cycle of the self-cleaning Removing the side self-cleaning panels and panels is a cleaning method through the rack/tray support frames enables the heating suitable for removing small grease sides to be cleaned more easily.
-
Page 32: Vapor Clean
Cleaning and maintenance 4.4 Vapor Clean • Pour approximately 40 cc of water into the tray. Make sure it does not overflow Vapor Clean is an assisted out of the cavity. cleaning procedure which facilitates the removal of dirt. Thanks to this process, it is possible to clean the inside of the oven very easily. - Page 33 Cleaning and maintenance Vapor Clean setting End of the Vapor Clean cycle 1. Turn the function knob to the symbol 4. Open the door and wipe away the less stubborn dirt with a microfibre cloth. and the temperature knob to the 5.
-
Page 34: Extraordinary Maintenance
Cleaning and maintenance 4.5 Extraordinary maintenance 4. Slide out and remove the light bulb. Replacing the internal light bulb Live parts Danger of electrocution • Unplug the appliance from the mains. The oven is fitted with a 40W light Do not touch the halogen light bulb. - Page 35 Cleaning and maintenance Installing and removing the seal To remove the seal: • Unhook the clips located in the 4 corners and in the centre, then pull the seal outwards. To refit the seal: • Hook the clips located in the 4 corners and in the centre onto the seal.
-
Page 36: Installation
Installation 5 Installation Connection with a rubber hose Verify that all following conditions are met: 5.1 Gas connection • The hose is attached to the hose connector with safety clamps Gas leak • No part of the hose is in contact with hot Danger of explosion walls (max. - Page 37 Installation Carefully screw the hose connector 3 to the Connection with a steel hose appliance’s gas connector 1 (½” thread Make the connection to the gas mains ISO 228-1), placing the seal 2 between using a continuous wall steel hose whose them.
- Page 38 Installation Connection to LPG Room ventilation Use a pressure regulator and make the The appliance should be installed in connection on the gas cylinder following rooms that have a permanent air supply in accordance with the standards in force. the guidelines set out in the standards in force.
-
Page 39: Adaptation To Different Types Of Gas
Installation 5.2 Adaptation to different types of Improper installation Risk of malfunction • In the case of conversion to Town Gas G110 – 8 mbar (category 1a), do not use the burners provided, but request the special G110 burners kit from our Technical Assistance Service. - Page 40 Installation 2. Replace the nozzles using a 7 -mm Adjusting the minimum setting for LPG socket wrench according to the gas to Tighten the screw located at the side of the be used (see "Nozzle and burner tap rod clockwise all the way. specification tables").
- Page 41 Installation Gas types and Countries Gas types IT GB-IE FR-BE DE AT NL ES PT SE RU DK PL HU 1 Natural gas G20 • • • • • • • • • • 20 mbar • G20/25 20/25 mbar 2 Natural gas G20 •...
- Page 42 Installation Burner and nozzle characteristics tables 1 Natural gas G20 Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600 2 Natural gas G20 – 25 mbar Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (H8) Reduced flow rate (W)
- Page 43 Installation 7 LPG G30/31 Rated heating capacity (kW) 1.75 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1600 Rated flow rate G30 (g/h) Rated flow rate G31 (g/h) 8 LPG G30/G31 – 37 mbar Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W)
-
Page 44: Positioning
Installation 5.3 Positioning Any wall units positioned above the worktop of the appliance must be at a Heavy appliance minimum distance of at least Y mm. If a Crushing hazard hood is installed above the hob, refer to the hood instruction manual to ensure the correct clearance is left. - Page 45 Installation Appliance overall dimensions 900 mm 600 mm B - Class 2 subclass 1 min. 150 mm (Built-in appliance) 900 - 915 mm 750 mm 450 mm 900 mm Minimum distance from side walls or other flammable material. Minimum cabinet width (=A). C - Class 2 subclass 1 (Built-in appliance) The appliance must be installed by...
-
Page 46: Electrical Connection
Installation Dimensions of the appliance: locations of Positioning and levelling gas and electric connections (mm) Heavy appliance Risk of damage to the appliance • Insert the front feet first and then the rear ones. After making the electrical and/or gas connections, screw the four adjustable feet supplied with the appliance. - Page 47 Installation 3. Assemble the fastening bracket. Fastening to the wall The anti-tip devices must be installed in order to prevent the appliance from tipping over. 1. Screw the wall fastening plate to the rear of the appliance. 4. Align the base of the hook on the fastening bracket with the base of the slot on the wall fastening plate.
- Page 48 Installation 5. Align the base of the fastening bracket 7. Move the bracket onto the wall and with the ground and tighten the screws mark the position of the holes to be to fix the measurements. drilled in the wall. 6.
- Page 49 Installation 5.4 Electrical connection Assembling the upstand The upstand provided is an Power voltage integral part of the product; it must Danger of electrocution be fastened to the appliance prior to installation. • Have the electrical connection performed by authorised technicians. The upstand must always be positioned and •...
-
Page 50: Instructions For The Installer
Installation The appliance can work in the following 5.5 Instructions for the installer modes: • The plug must be accessible after • 220-240 V 1N~ installation. Do not bend or trap the power cable. • The appliance must be installed according to the installation diagrams.
