This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
!
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Adults and especially children should be alerted to the hazards of high surface temperatures.
Notice to Installer: Leave these instructions with the grill owner for future reference.
N415-0574CE-GB-DE AUG 07.19
N415-0574CE-GB-DE AUG 07.19.indd 1
DANGER
Young children should be supervised near the gas grill.
Poppenbouwing 29-31, 4191 NZ Geldermalsen,
CCI No. 51509970, THE NETHERLANDS
R365 / R425
!
Do not try to light this appliance without
reading the "LIGHTING" instructions section
of this manual.
Do not store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance. An L.P. cylinder
not connected for use must not be stored in
the vicinity of this or any other appliance.
If the information in these instructions is
not followed exactly, a fire or explosion may
result, causing property damage, personal
injury or death.
Wolf Steel Europe BV
info@napoleongrills.nl
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
DO NOT DISCARD
ROGUE
WARNING
www.napoleon.com
EN
DE
PG.19
PG.38
8/9/2019 2:31:14 PM

Advertisement

Table of Contents
loading

Summary of Contents for Napoleon R365

  • Page 1 Serial No. XXXXXX000000 MODEL NO. PG.19 DO NOT DISCARD PG.38 ROGUE R365 / R425 DANGER WARNING Do not try to light this appliance without IF YOU SMELL GAS: reading the “LIGHTING” instructions section • Shut off gas to the appliance.
  • Page 2 NAPOLEON. NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and workmanship from the date of purchase, for the following period: Aluminum castings / stainless steel base ...........
  • Page 3: Safe Operating Practices

    Never use natural gas in a unit designed for liquid propane gas. • Never use lighter fluid in a gas grill. • Use charcoal briquettes only with a Napoleon charcoal tray designed for this unit. • Burner controls must be off when turning supply cylinder on. •...
  • Page 4 DIMENSIONS www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 4 8/9/2019 2:31:20 PM...
  • Page 5 DIMENSIONS N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 5 8/9/2019 2:31:21 PM...
  • Page 6: Gas Cylinder

    The recommended hose length is 0.9m. The hose must not be longer than 1.5m. • Ensure that the hose is twist and kink free when installed. • Replace the hose before expiry date printed on the hose. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 6 8/9/2019 2:31:24 PM...
  • Page 7: Technical Data

    Do not use enclosure to store excess hose, as there is a greater chance of the hose contacting a hot surface, it may melt and leak causing a fire. Technical Data The following table lists input values for the appliance. R365 Burner Orifice Size (Gross) Heat Input...
  • Page 8: Leak Testing Instructions

    Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Solutions department and have the grill inspected by a certified STOP gas installer.
  • Page 9: Lighting Instructions

    5. If lighting the unit with a match, clip the match into the supplied lighting rod. Hold the lit match down through the grill and sear plate while turning the corresponding burner valve to high. N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 9 8/9/2019 2:31:33 PM...
  • Page 10: Cooking Instructions

    Either trim the fat or reduce temperatures to inhibit this. Should a flare-up occur, move food away from the flames and reduce the heat. Leave the lid open. See Your All Season Grill cookbook by Napoleon for more detailed instructions. Infrared Main Burner Use (If Equipped): Follow the Infrared Burner Ignition procedures and operate on high for 5 minutes with the lid closed or until the ceramic burners glow red.
  • Page 11 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports – each with its own tiny flame – cause the surface of the ceramic tile to glow red.
  • Page 12 To add an exotic taste to your meat, High setting 3 min. each side. 6 min. – Well done try adding hickory-flavored woodchips to Napoleon’s woodchip smoker. Chicken High setting 2 min. each side. 20-25 min. The joint connecting the...
  • Page 13: Cleaning Instructions

    Remove the sear plates and brush debris from the burners with the brass wire brush. Sweep all debris from inside the gas grill into the drip pan. N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 13 8/9/2019 2:31:41 PM...
  • Page 14: Maintenance Instructions

    Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner.
  • Page 15 CAUTION! Check for abrasions, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Grill dealer or qualified gas installer. Aluminum Castings: Clean castings periodically with warm soapy water. Aluminum will not rust, but high temperatures and weathering can cause oxidation to occur on aluminum surfaces.
  • Page 16: Troubleshooting

    Humming regulators will not be replaced. Burners will not cross Dirty or corroded cross light Clean or replace as required. light each other. brackets. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 16 8/9/2019 2:31:47 PM...
  • Page 17 Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding Contact your authorized Napoleon the ceramic tile, or a weld dealer for instructions on ordering a failure in the burner housing.
  • Page 18: Ordering Replacement Parts

    3. A concise description of the problem (‘broken’ is not sufficient). 4. Proof of purchase (photocopy of the invoice). In some cases, Napoleon could request to have the parts returned to the factory for inspection before providing replacement parts. Before contacting Napoleon dealer, please note that the following items are not covered by the warranty: •...
  • Page 19 Gebäude, einer Garage oder einem anderen geschlossenen Bereich. SERIENNUMMER-AUFKLEBER VOM KARTON HIER ANBRINGEN Seriennr. XXXXXX000000 Model-Nr. BITTE SORGFÄLTIG AUFBEWAHREN ROGUE R365 / R425 WARNUNG GEFAHR WENN ES NACH GAS RIECHT: Vor dem Zünden dieses Geräts bitte unbedingt den Abschnitt „ZÜNDANLEITUNG” • Gaszufuhr zum Gerät absperren. lesen.
  • Page 20 Stolz erfüllt, montiert. Vor dem Verpacken für den Versand sind Ventile und Brenner auf einem Qualitätsprüfstand leckagegeprüft bzw. probegezündet und von einem qualifizierten Techniker inspiziert worden, damit der Kunde genau das Qualitätsprodukt erhält, das er von NAPOLEON erwartet. Die Firma NAPOLEON garantiert, dass ab Kaufdatum an den Komponenten Ihres neuen NAPOLEON- Produkts weder Material- noch Verarbeitungsmängel auftreten, während:...
  • Page 21 Niemals ein für den Gebrauch mit flüssigem Propangas ausgelegtes Gerät mit Erdgas betreiben. • Niemals flüssige Grillanzünder zum Anzünden eines Gasgrills verwenden. • Holzkohlenbriketts nur mit einer für dieses Gerät vorgesehenen Napoleon-Holzkohlenwanne verwenden. • Vor Öffnen der Gaszufuhr kontrollieren, dass die Brenner-Bedienelemente auf der Position „OFF” (Aus) stehen. •...
  • Page 22 ABMESSUNGEN www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 22 8/9/2019 2:31:56 PM...
  • Page 23 ABMESSUNGEN N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 23 8/9/2019 2:31:56 PM...
  • Page 24 Es wird eine Schlauchlänge von 0,9 m empfohlen. Der Schlauch darf nicht länger als 1,5 m sein. • Beim Anschließen ist darauf zu achten, dass der Schlauch knickfrei und nicht verdreht ist. • Der Schlauch ist vor dem aufgedruckten Ablaufdatum auszuwechseln. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 24 8/9/2019 2:31:58 PM...
  • Page 25 Bränden führen kann. • Alle Verbindungen mit Seifenlauge auf Gaslecks überprüfen. Folgen Sie den Anweisungen für die Suche nach Gaslecks in diesem Handbuch. Regler In der folgenden Tabelle sind die Anschlusswerte des Geräts aufgeführt. R365 Brenner Düsengrösse (Grob)Leistung Gasverbrauch (Insgesamt)
  • Page 26 Bleibt die Leckage bestehen, Flaschenventil zudrehen, Regler abnehmen und Grill vom Gaslieferanten oder STOP Händler untersuchen lassen. Das Gerät darf erst wieder benutzt werden, wenn die Leckage behoben ist. Gaszufuhr abstellen. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 26 8/9/2019 2:32:04 PM...
  • Page 27 Sie das Streichholz in den mitgelieferten Streichholzhalter ein. Das brennende Streichholz nach unten halten, durch den Grill und die Glühplatte führen und dabei das entsprechende Brennerventil auf hohe Flamme drehen. N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 27 8/9/2019 2:32:09 PM...
  • Page 28 Durchmesser zwischen 16 und 24 cm. Diese sind in die Mitte des Kochfelds zu platzieren, es sei denn, Griffe oder Stiel befinden sich direkt über den Flammen. Immer Griffe oder Stiel nach hinten oder der Seite drehen, um das Risiko, Pfanne oder Topf vom Grill zu stoßen, zu verringern. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 28...
  • Page 29 Haube. Dies erlaubt auch das bessere Überwachen des Grillguts, um Anbrennen zu vermeiden. Schutz der Infrarotbrenner: Die Infratrotbrenner des Napoleon-Grills sind für eine lange Lebensdauer ausgelegt. Es sind jedoch einige Maßnahmen erforderlich, um Risse in den keramischen Brenneroberflächen zu vermeiden, die zu Brennerfehlfunktionen führen können.
  • Page 30 Grillgut entweichen, tropfen hinunter in die Holzkohle, sodass ein Rauch aufsteigt, der dem Grillgut den herrlichen Grillgeschmack verleiht. Die Infrarotbrenner der Napoleon-Grills funktionieren genauso. Jeder der Brenner hat 10.000 Löcher. Aus jedem Loch tritt eine Flamme aus, die die Keramikoberfläche zur Rotglut bringen.
  • Page 31 Stufe Seite ¾ durchschneiden, damit das Fleisch flach auf dem Grill liegt. So wird es schneller und gleichmäßiger gegrillt. Mesquitspäne im Räucherkasten des Napoleon-Grills verleiht dem Fleisch einen ganz besonderen Geschmack. Schweinekotelett Mittlere Stufe 6 Min. pro Seite Vor dem Grillen überschüssiges Fett abschneiden.
  • Page 32 Grillgut herunter auf die Brennerfläche fällt. Es bleiben jedoch möglicherweise Rückstände kleben. Rückstände am besten gleich nach dem Grillen verbrennen, indem der Grill 5-10 Minuten lang auf der höchsten Stufe. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 32 8/9/2019 2:32:15 PM...
  • Page 33 Pfanne mit einem Spachtel oder Schaber auskratzen; Inhalt in die Einweg-Fettschale fegen. Schale je nach Häufigkeit der Benutzung alle zwei bis vier Wochen auswechseln. Ersatzschalen gibt es beim Napoleon-Händler. Reinigen der Aussenseite des Gasgrills: Lackierte, Porzellan- oder Rostfreistahlteile nicht mit Scheuermitteln säubern.
  • Page 34 75% der Grillfläche mit Vollmetall (d.h. von einem Grillblech oder einer großen Pfanne) abgedeckt sein. ACHTUNG! Schlauch : auf Abrieb, Schmelzstellen, Einschnitte und Risse untersuchen. Wenn einer dieser Defekte vorliegt,darf der Gasgrill nicht benutzt werden. Schlauch von Ihrem Napoleon-Händler oder einem Fachbetrieb auswechseln lassen. Alugussteile: regelmäßig mit warmem Seifenwasser säubern. Normalerweise rostet Aluminium nicht.
  • Page 35: Fehlerbehebung

    Dies ist kein Defekt. Das Geräusch Druckregler. heißen Tagen. wird durch interne Vibrationen im Druckregler hervorgerufen und beeinträchtigt weder die Leistung noch die Sicherheit des Gasgrills. „Summende” Druckregler werden nicht ersetzt. N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 35 8/9/2019 2:32:24 PM...
  • Page 36 Risse oder Sprünge in der Brenner abkühlen lassen und sorgfältig keramischen Oberfläche. auf Risse untersuchen. Falls Sie Risse feststellen sollten, wenden Sie sich an einen autorisierten Napoleon-Händler, um eine Ersatz-Brennereinbaugruppe zu bestellen. Dichtung der keramischen Wenden Sie sich an einen autorisierten Oberfläche ist undicht, oder...
  • Page 37 (Speichern Sie diese Informationen hier als künftige Referenz) Für Ersatzteile und Garantieanfragen, kontaktieren Sie Ihren Napoleonhändler, bei dem das Produkt gekauft wurde. Vor Sie Ihren Händler kontaktieren, lesen Sie bitte die Napoleon Grills Website, um mehr über Reinigung, Wartung, Troubleshooting und Ersatzteilmontage zu erfahren: https://www.napoleon.com/de/de/willkommen Um eine Reklamation einzureichen, sind folgende Unterlagen erforderlich: 1.
  • Page 38: Getting Started

    Sie sich an unseren Kundendienst unter +1-866-820-8686 zwischen 9 Uhr und 15 Uhr Eastern Standard Time. Tools required for assembly (tools not included) Erforderliche werkzeuge für die montage (werkzeuge nicht enthalten) 10 mm www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 38 8/9/2019 2:32:34 PM...
  • Page 39 Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire. WARNUNG! Den Schlauch von heißen Oberflächen fernhalten. Schmelzen des Schlauchs kann zu Bränden führen. N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 39 8/9/2019 2:32:40 PM...
  • Page 40 Einige Druckminderer-Schlauch-Sets haben eine Mutter und ein Linksgewinde, während bei anderen ON zum Anschluss und OFF zum Abtrennen gedrückt werden muss. Bitte beachten Sie die untenstehenden Anweisungen für das jeweilige Modell. FIG. 1 FIG. 2 FIG.3 FIG.4 www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 40 8/9/2019 2:32:46 PM...
  • Page 41 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Solutions department and have the grill inspected by a certified STOP gas installer.
  • Page 42 Bleibt die Leckage bestehen, Flaschenventil zudrehen, Regler abnehmen und Grill vom Gaslieferanten oder STOP Händler untersuchen lassen. Das Gerät darf erst wieder benutzt werden, wenn die Leckage behoben ist. Gaszufuhr abstellen. www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 42 8/9/2019 2:33:13 PM...
  • Page 43 R365/R425 Parts List/Stückliste Item Part # Description R365 R365SB R425 R425SB N520-0051 warming rack N520-0050 warming rack S83015 cast cooking grid kit S83016 stainless cooking grid kit S83008 cast cooking grid kit S83013 stainless cooking grid kit S87001 burner & sear plate kit...
  • Page 44 R365/R425 Parts List/Stückliste Item Part # Description R365 R365SB R425 R425SB N010-1243-SER control panel assembly 50mbar N010-1244-SER control panel assembly flame side burner 30mbar N010-1246-SER control panel assembly flame side burner 50mbar N010-1247-SER assembly control panel 30 mbar N010-1249-SER assembly control panel 50 mbar...
  • Page 45 R365/R425 Parts List/Stückliste Item Part # Description R365 R365SB R425 R425SB 69812 rotisserie kit CE 69813 rotisserie kit GB 69815 rotisserie kit IL 61365 cover 61425 cover 61426 cover folded side shelves 56365 griddle 56018 stainless steel griddle 67732 charcoal tray...
  • Page 46 R425SB-1CE www.napoleon.com N415-0574CE-GB-DE AUG 07.19 N415-0574CE-GB-DE AUG 07.19.indd 46 8/9/2019 2:33:19 PM...
  • Page 47 Notes N415-0574CE-GB-DE AUG 07.19 www.napoleon.com N415-0574CE-GB-DE AUG 07.19.indd 47 8/9/2019 2:33:20 PM...
  • Page 48 Napoleon products are protected by one or more U.S. and Canadian and/or foreign patents or patents pending. N415-0574CE-GB-DE N415-0574CE-GB-DE AUG 07.19.indd 48 8/9/2019 2:33:21 PM...
