Precautionary measures
When using the appliance observe the following precautions:
1. Read all instructions carefully and save it for future use.
2. Use iron only for its intended purpose.
3. Before using, make sure that your mains voltage corresponds to the voltage specified on the
name plate of the iron.
4. Do not keep working iron the up sole, this may cause burns a soleplate or steam.
5. If you find damage to the appliance, contact an authorized service center.
6. In the event of damage to the power cord contact an authorized service center. Do not attempt
to replace the cord yourself.
7. Do not let cord touch hot soleplate. Let iron cool completely before you remove it in place.
8. Always turn off the iron from the mains while filling his water or when the water pour out of it,
and also before cleaning the iron.
9. Do not immerse the iron in water or other liquids. This can result in electric shock.
10. Do not let children use an iron alone. Do not leave children unsupervised near the included iron.
11. Do not leave the iron unattended connected to the mains.
12.
Do not use iron outdoors. The device is intended for household use only.
Description of the instrument.
STEAM IRON
Unit USI-193
Instruction manual

Advertisement

loading

Related Manuals for Unit USI-193

Summary of Contents for Unit USI-193

  • Page 1 STEAM IRON Unit USI-193 Instruction manual Precautionary measures When using the appliance observe the following precautions: 1. Read all instructions carefully and save it for future use. 2. Use iron only for its intended purpose. 3. Before using, make sure that your mains voltage corresponds to the voltage specified on the name plate of the iron.
  • Page 2 A. Soleplate Spraying Water Outlet Water Tank Inlet D. The position of the Self-Cleaning Regulator supply of steam Spraying Water Button G. Steam Shot Button H. Cord Brushing Ready Light Temperature Dial K. MAX. Water Level Soleplate Which is made of stainless steel material, it can be heated up and be used to iron the garment. Spraying nozzle When pressing spraying water button instantly, water is sprayed from this outlet.

  • Page 3: Operation Of Device

    Operation of device. 1. Hold the iron vertically, with a slight slope, fill the tank with water, using a measuring cup. You had better use purified water with less calcium particles. Water is not to exceed “Max” level on the tank (See pic 1). 2.

  • Page 4: Cleaning And Maintenance

    7. Steam shot function had better be used at max temperature, as it helps remove stubborn creases. 8. The iron has an anti-drip function. If iron long during is not used, the sole cools steam generation is automatically switched off to prevent drip through the holes of the sole. 9.

  • Page 5: Selecting The Ironing Temperature

    Model: USI-193 Power supple: 230 V ~ 50 Hz Power: 2200 W The head office of the manufacturer : «UNIT Handelsgesellschaft G.m.b.H.» 131, Gersthofer Str., A-1180, Vienna, Austria Exported by: «UNIT Electronics (H. K.) Limited» 3905 Two Exchange Square, 8 Connaught Place, Central, Hong Kong Made in People’s Republic of China (P.R.C.)
  • Page 6 Unit USI-193...
  • Page 9 «Off . 4. (Anti-Calc) Anti-Calc...
  • Page 10 V” “ ” : USI-193 : 230 ~ 50 : 2200...
