PD1233
PD1233T
Pen Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.
Model No. VS18287
P/N: PD1233 | PD1233T
Advertisement
Table of Contents
Related Manuals for ViewSonic PD1233T
Summary of Contents for ViewSonic PD1233T
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Safety Precautions
Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •... -
Page 4: Table Of Contents
Pen Display Driver ....................8 Connecting the Pen Display ..................9 Using the Display ............10 Using the Pen Tether ....................10 Using the Touch Function (PD1233T only) ............11 Adjustable Stand Legs ...................12 Changing to Portrait Orientation ................13 Setting the Display Area ..................14 Pen Input Area Mapping ..................15... - Page 5 Regulatory and Service Information ......22 Compliance Information ..................22 FCC Compliance Statement ................... 22 Industry Canada Statement ................... 22 CE Conformity for European Countries ..............22 Declaration of RoHS2 Compliance................. 23 Indian Restriction of Hazardous Substances ............24 Product Disposal at End of Product Life ..............24 Copyright Information ..................25 Customer Service ....................
-
Page 6: Introduction
Instalar PenDisplayDriver Instalar PenDisplayDriver https://www.viewsonicglobal.com/public/products_download/software/pendisplay/PenDisplayDriver.zip ViewSonic Pen Display Website: https://www.viewsonic.com/viewsign/products Customer service contact information: USA- ViewSign@viewsonic.com / China- ViewSign@cn.viewsonic.com / Global- ViewSign@tw.viewsonic.com Install PenDisplayDriver ViewSonic Pen Display Website: https://www.viewsonic.com/viewsign/products Installer PenDisplayDriver Customer service contact information: USA- ViewSign@viewsonic.com / China- ViewSign@cn.viewsonic.com / Global- ViewSign@tw.viewsonic.com... -
Page 7: Product Overview
Product Overview Mini HDMI Port Pen Tether Pen Holder Wall Mounting Display Screen/ Anchor Point Touch Screen¹ Points 8. Pen 9. Pen Holder Security Lock Adjustable Repositionable Attachment Slot Stand Leg Point Touch screen only available on PD1233T. -
Page 8: Making Connections
Pen Display Manager can be used to map the active area and adjust the feel of the pen. 1. Open the ViewSign Console installation file and install the driver. 2. After the installation completes, you will need to restart the computer. NOTE: For further ViewSign Console information, please visit: https://manuals.viewsonic.com/ViewSign_Software... -
Page 9: Connecting The Pen Display
Connecting the Pen Display 1. Turn the device over so the bottom side is facing up. Bottom 2. Connect the Mini HDMI end of the Mini HDMI 3 in 1 cable to the Mini HDMI Port of the device. 3. Connect the Main USB A cable and HDMI cable to the PC. The Secondary USB A cable can be connected to a fully powered USB port on the computer, or to an AC Main USB A outlet using the supplied power adapter. -
Page 10: Using The Display
Using the Display Using the Pen Tether The Pen Tether can be attached to the Pen and to the available anchor point. -
Page 11: Using The Touch Function (Pd1233T Only)
Using the Touch Function (PD1233T only) The PD1233T can detect up to 10 fingers simultaneously depending on the application. When using the touch function, please note: • The touch function may need about five (5) seconds to resume if the USB cable is removed and plugged in again, or the computer resumes from Sleep Mode. -
Page 12: Adjustable Stand Legs
Adjustable Stand Legs There are three (3) adjustable stand legs on the pen display. This allows for a viewing angle of 0°, 15°, or 20° in portrait orientation; and 0°, 9°, 13° in landscape orientation. Landscape Portrait 12 12... -
Page 13: Changing To Portrait Orientation
Changing to Portrait Orientation In order to use the adjustable stand in portrait orientation, one adjustable stand leg must be unscrewed, rotated, and screwed back into place. Additionally, it is recommended that the pen holder is also rotated. NOTE: A small cover plate hides the screws, please remove first. 13 13... -
Page 14: Setting The Display Area
Setting the Display Area After the pen display is connected to the computer, the Display settings will need to be adjusted. To access your computer’s Display settings: • Go to: Start > Settings > System > Display, or • Right Click on the Desktop and select Display settings. Once inside the Display settings, ensure the pen display is selected and: •... -
Page 15: Pen Input Area Mapping
Pen Input Area Mapping To set the proper pen input area, 1. Open Pen Display Manager either by going to: Start > ViewSonic > Pen Display Manager or selecting the Pen Display Manager icon from the System Tray. Additionally, the driver can also be accessed from ViewSign Console - either the widget or by right-clicking the ViewSign Console icon in the system tray and selecting Pen Display Driver. - Page 16 4. Select the Pen tab to adjust Tip Feel and check the Current Pressure. NOTE: Tip Feel alters how much actual pressure it takes to achieve maximum pressure. • Soft - requires less actual pressure to see a difference in pen pressure levels.
-
Page 17: Appendix
• 800 x 600 @ 60Hz • 720 x 400 @ 70Hz • 640 x 480 @ 60Hz Touch Type Supported Capacitive touch, 10 point (for PD1233T only) Power USB (5V/2A) or AC Input Voltage Display Area 256.32 x 144.18 mm (10.09” x 5.68”) -
Page 18: Product Dimensions
Item Specifications Model EMP-001 Type Electromagnetic resonance Power Supply Battery-less Resolution 5080 LPI (lines per inch) Pressure Levels 2048 Report Rate Average 250 PPS (points per second) Pen Tilt Angle +/- 45° OS Supported Win10, Win8, Win 7, Win XP Product Dimensions 14.3 mm 287 mm... -
Page 19: Troubleshooting
• Check if other nearby electrical devices are causing Display interference interference. • The optimal resolution is 1920 x 1080. • For PD1233T, touching the display with your fingers may leave fingerprints and skin oil making the The display is not clear display unclear. -
Page 20: Maintenance
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. -
Page 21: Replacing A Pen Nib
Replacing a Pen Nib When the pen nib gets too short or develops a sharp edge, it can be replaced with spare nibs. To replace a pen nib: 1. Use the nib removal tool to pull the old nib straight out of the pen. 2. -
Page 22: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 23: Declaration Of Rohs2 Compliance
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law. -
Page 24: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®... -
Page 25: Copyright Information
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 26: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia www.viewsonic.com/au/ Bangladesh www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) www.viewsonic.com/hk-en/ India www.viewsonic.com/in/... -
Page 27: Limited Warranty
“What the warranty excludes and does not cover” section). How long the warranty is effective: ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase. - Page 28 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 29 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 30: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 31 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 32 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
- Page 33 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...
