In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
This model is based on the LC-60LE632U/LC-70LE732U and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-60LE632U/LC-70LE732U
(S31O870LE732U) Service Manual.
(LC-60LE630U(A),6300U(A))
The new model can be identified with the following markings.
• As to the new service Parts, the mark A is printed on the model label.
LC-60LE6300U
LC-60LE6300U
OUTLINE, MODIFIED PARTS AND MAJOR SER-
VICE PARTS
OUTLINE................................................ . ............i
MODIFIED PARTS ................................. . ...........ii
MAJOR SERVICE PARTS ..................... . .......... iii
[1]
U(A),6300U/U(A)/U(B)) .......................... . ....... 1-1
[2]
SPECIFICATIONS (LC-70LE735U) ....... . ....... 1-2
[1]
OPERATION MANUAL (LC-60LE630U/
U(A),6300U/U(A)/U(B)) .......................... . ....... 2-1
[2]
[1]
60LE630U/U(A),6300U/U(A)/U(B)) ........ . ....... 3-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
LC-60LE630U/U(A),6300U/U(A)/U(B),LC-70LE735U
SERVICE MANUAL
LCD COLOR TELEVISION
MODELS
OUTLINE
(LC-60LE6300U(B))
The new model can be identified with the following markings.
• As to the new service Parts, the mark B is printed on the model label.
LC-60LE6300U
CONTENTS
[1]
ADJUSTMENT PROCEDURE (LC-
60LE630U/U(A),6300U/U(A)/U(B))................4-1
[1]
[1]
[2]
70LE735U) ....................................................6-2
[3]
[4]
70LE735U) ....................................................6-4
No. S81S460LE630U
LC-60LE630U/U(A)
LC-60LE6300U/U(A)/U(B)
LC-70LE735U
B
LC-60LE6300U
B
B
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
B
