Anti-Tip Device ............................2, 3,33,41
Operating Instructions, Tips
Aluminum Foil ...................................5, 15, 18
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ......................6, 7
Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-22
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 15
Broiling, Broiling Guide ....................18, 19
Clock and Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control Settings...................lO, 14, 16, 18
Door Latch ..............14, 16, 18,20,21,48
Light; Bulb Replacement . . . . . . . . . . . . . . . . . 10,28
Preheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 17
Roasting, Roasting Guide ................l6, 17
Self-Cleaning Instructions ..............20
Shelves ..................................1 1, 14-16,27
Surface Cooking .........................................8, 9
Control Settings ..........................................8
Electric Ignition ............................................8
Care and Cleaning ....................23-3O
Broiler Pan and Rack......................5, 18, 19,27
Burner Assembly ........................................2 3-25
Door Removal ...............................................26
Lift-up Cooktop .............................................30
Oven Bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Oven Vents ....................................4, 5, 11,30
Storage Drawer ............................................2g
GE Appliances
Self-Cleaning Gas Range
Problem So[ver........................47,
More questions ?...call
GE Answer Center@ 800.626.2000
Preparation
Flame Size ..................................9, 39,46,47
Flooring Under the Range .........................34
Installation Instructions ......................32 -46
Leveling ..........................................................4l
Minor Adjustments......................................3 1
Thermostat Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Consumer Services ...................5l
Appliance Registration ..................................2
-
22
Important Phone Numbers ........................5 1
Model and Serial Number Location ...........2
Warranty ........................................Back Cover
Models: JGBP24GEI JGBP30WEP
48
.................................31-46
Advertisement
Related Manuals for GE XLMT JGBP24GEN
Summary of Contents for GE XLMT JGBP24GEN
- Page 1 Self-Cleaning Gas Range Problem So[ver......47, More questions ?...call Anti-Tip Device ......2, 3,33,41 GE Answer Center@ 800.626.2000 Operating Instructions, Tips Preparation .........31-46 Aluminum Foil ........5, 15, 18 Flame Size ........9, 39,46,47 Features ............6, 7 Flooring Under the Range ......34...
