Installation Instructions
Compact Gas Range
Questions? Call GE Appliances at 1.800.GE.CARES (1.800.432.2737) or visit
GEAppliances.com. In Canada, call 1.800.561.3344 or visit GEAppliances.ca.
IN THE COMMONWEALTH
OF MASSACHUSETTS
WARNING
FIRE OR EXPLOSION
HAZARD
FOR YOUR SAFETY:
WARNING
Tip-Over Hazard
• A child or adult can tip the range and be killed.
• Verify the anti-tip bracket has been properly
installed and engaged.
• Ensure the anti-tip bracket is re-engaged when
the range is moved.
• Do not operate the range without the anti-tip bracket
in place and engaged.
• Failure to do so can result in death or serious burns
to children or adults.
GEAppliances.com
GEAppliances.ca
NEW
WARNING
TOOLS YOU WILL NEED
BEFORE YOU BEGIN
IMPORTANT —
IMPORTANT
—
IMPORTANT
—
IMPORTANT
—
Note to Installer
Note to consumer
Servicer
MATERIALS YOU MAY NEED
Mobile Home - Additional Installation
Requirements
SINGLE OVEN
Advertisement
Related Manuals for GE JGAS640RMSS
Summary of Contents for GE JGAS640RMSS
- Page 1 Installation Instructions TOOLS YOU WILL NEED MATERIALS YOU MAY NEED Compact Gas Range Questions? Call GE Appliances at 1.800.GE.CARES (1.800.432.2737) or visit GEAppliances.com. In Canada, call 1.800.561.3344 or visit GEAppliances.ca. IN THE COMMONWEALTH OF MASSACHUSETTS WARNING FIRE OR EXPLOSION BEFORE YOU BEGIN...
-
Page 2: Dimensions And Clearances
DIMENSIONS AND DIMENSIONS AND CLEARANCES (CONT.) CLEARANCES GAS PIPE AND ELECTRICAL OUTLET LOCATIONS CAUTION To prevent drafts from affecting burner operation, seal all openings in floor under appliance and behind appliance wall. CONVERTING TO PROPANE (LP) GAS (OR CONVERTING BACK TO NATURAL GAS FROM PROPANE (LP) GAS) This range leaves the factory set for use with natural gas. -
Page 3: Gas Supply
GAS SUPPLY ELECTRICAL CONNECTIONS WARNING Fire Hazard: Do not use DO NOT, UNDER ANY CIRCUMSTANCES, WARNING a flame to check for gas leaks. CUT OR REMOVE THE THIRD (GROUND) Shock Hazard: This PRONG FROM THE POWER CORD. DO appliance must be properly grounded. WARNING NOT USE AN ADAPTER. - Page 4 Quality of Flames CHECK SURFACE LEVEL THE RANGE BURNERS WARNING Never completely remove the leveling leg as the range will not (A) Soft blue flames— be secured to the anti-tip device properly. (B) Yellow tips on outer cones— NOTE: Set Bake function to 350°F. Burner should CHECK BAKE BURNER light in 30 to 90 seconds.
- Page 5 Instrucciones de instalación HERRAMIENTAS NECESARIAS MATERIALES NECESARIOS Cocina de gas compacta ¿Preguntas? Llame a GE Appliances al 800.GE.CARES (800.432.2737) o visita GEAppliances.com. En Canadá, llame 1.800.561.3344 o visita GEAppliances.ca. EN EL COMMONWEALTH DE MASSACHUSETTS ADVERTENCIA RIESGO DE INCENDIO O EXPLOSIÓN ANTES DE COMENZAR Casa Rodante –...
- Page 6 DIMENSIONES Y ESPACIOS DIMENSIONES Y ESPACIOS (CONT.) UBICACIONES DE LA TUBERÍA DE GAS Y DEL TOMACORRIENTE ELÉCTRICO PRECAUCIÓN Para evitar que una corriente de aire afecte el funcionamiento del quemador, selle todas las aberturas sobre el piso debajo del electrodoméstico y detrás de la pared del mismo.
- Page 7 SUMINISTRO DE GAS CONEXIONES ELÉCTRICAS ADVERTENCIA Riesgo de incendio: NUNCA, BAJO NINGUNA CIRCUNSTANCIA, ADVERTENCIA No use una llama para controlar las pérdidas de gas. CORTE NI ELIMINE EL TERCER CABLE (TIERRA) Riesgo de DEL CABLE DE CORRIENTE. NO USE UN ADVERTENCIA Descarga: Este electrodoméstico deberá...
- Page 8 Calidad de las Llamas CONTROLE LAS NIVELACIÓN DE LA CABEZAS DE LOS COCINA QUEMADORES ADVERTENCIA (A) Llamas azul suave — (B) Puntas amarillas en conos externos — NOTA: CONTROL EL QUEMADOR PARA HORNEAR Para retirar la parte inferior del horno: Configure la función Bake (Hornear) en INSTALE Y CONTROLE 350º...
