This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
!
WARNING!
MATERIAL.
!
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Adults and especially children should be alerted to the hazards of high surface temperatures.
Notice to Installer: Leave these instructions with the grill owner for future reference.
N415-0543 DEC 12.18
N415-0543 DEC 12.18.indd 1
CABINET FRAME, CABINET AND COUNTER TOP MUST BE MADE FROM NON-COMBUSTIBLE
DANGER
Young children should be supervised near the gas grill.
214 Bayview Drive,
Barrie, Ontario, CANADA L4N 4Y8
grills@napoleonproducts.com
!
Do not try to light this appliance without
reading the "LIGHTING" instructions section
of this manual.
Do not store or use gasoline or other
flammable liquids or vapors in the vicinity
of this or any other appliance. An L.P.
cylinder not connected for use must not be
stored in the vicinity of this or any other
appliance. If the information in these
instructions is not followed exactly, a fire
or explosion may result, causing property
damage, personal injury or death.
Wolf Steel Ltd.
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
DO NOT DISCARD
BIPRO825-3
WARNING
www.napoleongrills.com
12/13/2018 10:19:04 AM
EN
FR
PG.33
PG.66
Advertisement
Table of Contents
Related Manuals for Napoleon BIPRO825RBISS-3
Summary of Contents for Napoleon BIPRO825RBISS-3
- Page 1 This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a building, garage, screened-in porch, gazebo or any other enclosed area. APPLY SERIAL NUMBER LABEL FROM CARTON Serial No. XXXXXX000000 MODEL NO. PG.33 DO NOT DISCARD PG.66...
- Page 2 This grill has been thoroughly inspected by a qualified technician before packaging and shipping to ensure that you, the customer, receive the quality product you expect from NAPOLEON. NAPOLEON warrants that components in your new NAPOLEON product will be free from defects in material and workmanship from the date of purchase, for the following period: Aluminum castings / stainless steel base .........
-
Page 3: Safe Operating Practices
WARNING! Failure to follow these instructions could result in property damage, personal injury or death. Read and follow all warnings and instructions in this manual prior to operating grill. Safe Operating Practices • This gas grill must be assembled exactly according to the instructions in the manual. If the grill was store assembled, you must review the assembly instructions to confirm correct assembly and perform the required leak tests before operating the grill. -
Page 4: General Information
General Information This Gas Barbecue is certified under Canadian and American National Standards, CSA 1.6-2015 and ANSI Z21.58-2015 respectively for Outdoor Gas Grills and should be installed to conform according to local codes. In absence of local codes, install to the current CAN B149.1 Natural Gas and Propane Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the United States. - Page 5 rigid pipe, copper tube or an approved flexible metal connector which complies with Z21.24/ CSA 6.10 or ANSI Z21.75/CSA 6.27. The installation must comply with CAN B149.1 Natural Gas and Propane installation code in Canada, or to the National Fuel Gas code, ANSI Z223.1 in the United States. The gas supply pipe must be sufficiently sized to supply the BTU/h specified on the rating plate, based on the length of the piping run.
-
Page 6: Electrical Precautions
BUILT IN NATURAL GAS HOOK-UP: The piping up to the gas grill is the responsibility of the installer and piping should be located as shown in the built-in instructions. A flexible metal connector is included to simplify the installation of the unit. Connect this connector to the flare fitting on the end of the manifold. Connect the other end of the connector to the gas piping. -
Page 7: Lighting Instructions
Lighting Instructions Smoker Burner Igniter Light Left Rear Right Right Left Right Left Smoker Warming Infra Infra Tube Burner Centre Centre Tube Tray Burner Burner Tube Burner Tube Burner Burner Burner Burner WARNING! Open lid Off Position WARNING! Ensure all burner controls are in the off position. Slowly turn on the gas supply valve. -
Page 8: Cooking Instructions
This may cause the control panel to become extremely hot to touch and the knobs to deform. Napoleon offers a wind deflector illustrated below. Install this wind deflector to help prevent the possibility of improper heat build up. - Page 9 Wood for smoking comes in various forms, chunks, chips, dust and pellets, it also comes in many varieties (flavours) from apple to walnut, each transmitting a different taste. Use only wood that you know has not been treated, or better still buy from your authorized Napoleon dealer. N415-0543 DEC 12.18 www.napoleongrills.com...
- Page 10 Any juices or oils that escape from the food drip onto the charcoal and vaporize into smoke giving the food its delicious grilled taste. The Napoleon infrared burner cooks in the same way. In each burner, 10,000 ports – each with its own tiny flame – cause the surface of the ceramic tile to glow red.
- Page 11 This helps it to cook faster and more evenly. To add a trademark taste to your cooking, try adding mesquite-flavoured woodchips to your Napoleon woodchip smoker, optional accessory. Pork chops Medium 6 min. per side Trim off the excess fat before grilling.
-
Page 12: Cleaning Instructions
Cleaning The Outer Grill Surface: Do not use abrasive cleaners or steel wool on any painted, porcelain or stainless steel parts of your Napoleon Grill. Doing so will scratch the finish. Exterior grill surfaces should be cleaned with warm soapy water while the metal is still warm to the touch. To clean stainless surfaces, use a stainless steel or a non-abrasive cleaner. -
Page 13: Maintenance Instructions
Maintenance Instructions We recommend this gas grill be thoroughly inspected and serviced annually by a qualified service person. At all times keep the gas grill area free from combustible materials, gasoline and other flammable vapors and liquids. Do not obstruct the flow of ventilation and combustion air. WARNING! Always wear protective gloves and safety glasses when cleaning your grill. - Page 14 Regulator Hose (when applicable): Check for abrasions’, melting, cuts, and cracks in the hose. If any of these conditions exist, do not use the gas grill. Have the part replaced by your Napoleon Gas Grill dealer or qualified gas installer.
- Page 15 Protection Of Infrared Burners: The infrared burners of your grill are designed to provide a long service life, though care must taken to prevent cracking of their ceramic surfaces. Fractures will cause the burners to malfunction. The following provides a few of the causes of cracks and the steps you can take to avoid them.
-
Page 16: Troubleshooting
Troubleshooting Problem Possible Causes Solution Low heat / Low flame For propane - improper lighting Ensure lighting procedure is followed carefully. when valve turned to procedure. All gas grill valves must be in the off position high. when the tank valve is turned on. Turn tank on slowly to allow pressure to equalize. - Page 17 Cracked ceramic tile. Allow burner to cool and inspect very closely for cracks. If any cracks are found, contact your authorized Napoleon dealer to order a replacement burner assembly. Leaking gasket surrounding the Contact your authorized Napoleon dealer for...
-
Page 18: Warranty Information
3. A concise description of the problem (‘broken’ is not sufficient). 4. Proof of purchase (photocopy of the invoice). In some cases, Napoleon could request to have the parts returned to the factory for inspection before providing replacement parts. Before contacting Napoleon dealer, please note that the following items are not covered by the warranty: •... -
Page 19: Getting Started
CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly. - Page 20 BUILT-IN UNIT OPENING DIMENSIONS MODEL OPENING DIMENSIONS NOTES BIPRO825 52 3/8” 20 5/8” 8 7/8” 1330mm 524mm 225mm SIDE BURNER 12 3/4” 16 1/2” 4 1/2” OPENING OF AT LEAST 5 SQ IN MUST BE PROVIDED FOR N370-0504 -LPG 324mm 419mm 114mm COMBUSTION AIR FOR SIDE BURNER.
- Page 21 N080-0354 N080-0355 N570-0042 (10-24 X 3/8") N415-0543 DEC 12.18 www.napoleongrills.com N415-0543 DEC 12.18.indd 21 12/13/2018 10:19:24 AM...
- Page 22 APPLY A DAB OF SILICONE TO EACH FLANGE TO SECURE IN PLACE. www.napoleongrills.com N415-0543 DEC 12.18 N415-0543 DEC 12.18.indd 22 12/13/2018 10:19:27 AM...
- Page 23 N415-0543 DEC 12.18 www.napoleongrills.com N415-0543 DEC 12.18.indd 23 12/13/2018 10:19:28 AM...
- Page 24 BIPRO825 BUILT-IN INSTRUCTIONS 4” (102mm) minimum, bottom of the grill to top of the electrical panel. GFI Outlet 9⅝” (244mm) 8” (203mm) maximum 7” (178mm) LOCATED INSIDE CABINET WARNING! Failure to follow these instructions could result in property damage, personal injury or death.
- Page 25 NON-METALIC CABINET ONLY LOCATED INSIDE CABINET N415-0543 DEC 12.18 www.napoleongrills.com N415-0543 DEC 12.18.indd 25 12/13/2018 10:19:34 AM...
- Page 26 COUNTER TOP REQUIRED. IM-UGC825 (NOT INCLUDED) www.napoleongrills.com N415-0543 DEC 12.18 N415-0543 DEC 12.18.indd 26 12/13/2018 10:19:37 AM...
- Page 27 IM-UGC825 N570-0038 (1/4”-20 X 1/2”) N450-0008 (1/4”-20) N415-0543 DEC 12.18 www.napoleongrills.com N415-0543 DEC 12.18.indd 27 12/13/2018 10:19:39 AM...
- Page 28 LOCATED INSIDE CABINET www.napoleongrills.com N415-0543 DEC 12.18 N415-0543 DEC 12.18.indd 28 12/13/2018 10:19:43 AM...
- Page 29 N415-0543 DEC 12.18 www.napoleongrills.com N415-0543 DEC 12.18.indd 29 12/13/2018 10:19:43 AM...
- Page 30 www.napoleongrills.com N415-0543 DEC 12.18 N415-0543 DEC 12.18.indd 30 12/13/2018 10:19:45 AM...
- Page 31 Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Solutions department and have the grill inspected by a certified STOP gas installer.
- Page 32 Rotisserie Kit Assembly Instruction (optional) Assemble rotisserie kit components as shown. Ensure stop bushing is tightened on the inside of hood casting. www.napoleongrills.com N415-0543 DEC 12.18 N415-0543 DEC 12.18.indd 32 12/13/2018 10:19:51 AM...
