Grizzly H5749 Specifications

705-2
705-1
705-1
Hole Pattern For
Arm Attachment
60mm
REF PART #
701 PSB48M CAP SCREW M6-1.0 X 35
702 PH5749702 LASER CLAMP ASSEMBLY
702-1 PH5749702-1 LASER CLAMP (TOP)
702-2 PH5749702-2 LASER CLAMP (BOTTOM)
703 PH5749703 LASER
704 PSB01M CAP SCREW M6-1.0 X 16
705 PH5749705 LASER BRACKET ASSEMBLY
705-1 PSB18M CAP SCREW M4-0.7 X 8
705-2 PW05M FLAT WASHER 4MM
705-3 PH5749705-3 LASER BRACKET (TOP)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
701
705-3
705-4
706
55mm
DESCRIPTION
COPYRIGHT © NOVEMBER 2003 BY GRIZZLY INDUSTRIAL, INC.
#5902 PRINTED IN TAIWAN
703
702
704
705
711
709
713
712
707
REF PART #
705-4 PH5749705-4 LASER BRACKET (BOTTOM)
706 PH5749706
707 PSB31M
708 PS05M
709 PH5749709
710 PH5749710
711 PH5749711
712 PLW04M
713 PW01M
714 PW03M
714
702-2
710
708
DESCRIPTION
STEEL ARM
CAP SCREW M8-1.25 X 25
PHLP HD SCR M5-0.8 X 8
POWER BOX
FUSE T1AL250V
FUSE COVER
LOCK WASHER 8MM
FLAT WASHER 8MM
FLAT WASHER 6MM
702-1
