Grizzly H3559 Specifications

10
04
03
REF
06
07
05
03
04
PART #
01 X1681001 HEX HEAD BOLT
02 X1681002 V-BELT 4L280
03 X1681003 RIGHT HAND ARBOR NUT
04 X1681004 3" PLEATED FLANGES
05 X1681005 RETAINING RING
06 X1681006 ARBOR SHAFT
07 X1681007 BALL BEARING
08 X1681008 ARBOR PULLEY
09 X1681009 REAR CAST HOUSING
10 X1681010 FRONT CAST HOUSING
11 X1681011 LEFT HAND ARBOR NUT
-17-
05
07
08
01
01
02
DESCRIPTION
3
⁄ " ID
4
04
04
11
09
01
01
1
01
01
