- Page 1 PWE3810-M User Manual Refreshment Centre...
-
Page 2: Table Of Contents
Contents Contents Safety information Unit positioning Appliance description Unit connection Main components Usage Rating plate Maintenance and cleaning Technical specifications Signals for users Package content What to do if... Installation Environment concerns Safety information Fundamental safety warnings Warning The appliance must be earthed in compliance with legislation. Electrical and Water connection must be carried out by qualified technicians following the instructions Warning Keep all packaging (plastic bags, polystyrene foam) away from children Warning The appliance is not to be used by people (including children) with reduced physical,... -
Page 3: Safety Information
Safety information Designated use Warning This is a household appliance only It is not intended to be used in: • Staff kitchen areas in shops • Offices and other working environments • Farm houses • By clients in hotels, motels, and other residential type of environments •... -
Page 4: Appliance Description
Safety information Surface treatment Warning Before performing any washing operation, the appliance must be switched off and unplugged from the power supply Warning Do not use solvents or abrasive detergents. A soft damp cloth will suffice Environmental protection Electrical appliances must not be disposed of as household waste. Appliances with this symbol covered by European Directive 2002/96/EC. -
Page 5: Rating Plate
Main components Filter head CO bottle ₂ 10Water pressure reducer 11Water discharge tap 12Water inlet 13Filter cartridge 14Rating plate 15Power switch 16Power supply socket Rating plate Under no circumstances should you attempt to repair the machine yourself. Repair carried out by inexperienced people could cause injury or serious malfunctioning. -
Page 6: Technical Specifications
Technical specifications Technical specifications Technical specifications Power Supply Voltage 230-240 V Frequency 50 Hz Power consumption MAX 260 W Cold still water dispense capacity 2lt @ 1 l/min. Cold sparkling water dispense capacity 2lt @ 1 l/min. Ice shards 200g / 2h Dispense temperature <... -
Page 7: Installation
Installation Installation Warning It is necessary to install the appliance properly. The power supply and water connection data in the Technical Specifications chart must be observed Unit positioning • Check for minimum requirements • Spacers installation • Support brackets installation •... - Page 8 Unit positioning The Refreshment Centre must be installed in a cabinet and the cabinet must be firmly fixed to the wall. Leave room behind the appliance as described in these instructions to avoid overheating. Spacers installation To ensure a smooth installation of the appliance, you need the same internal width as shown in the picture below.
- Page 9 Unit positioning For a correct installation, take the single support bracket and place it directly in contact with both the shelf of the cabinet and the spacer if previously used. Otherwise the bracket will be in direct contact with both shelf and side of the cabinet.
- Page 10 Unit positioning Pull out the sliding rail until the cabinet underneath becomes visible. Fix the sliding rail, the support bracket and the spacer with the provided self-threading screws 4.5x16. When extracting the sliding rails, only one of the frontal holes will become visible. After mounting the corresponding screw, move the rail again to see the second hole and mount the corresponding screw.
-
Page 11: Unit Connection
Unit positioning Frontal spacer M4x12 screws Unit connection All the operations below require the appliance to be extracted from cabinet. Remove the grid of the drip tray to easily pull out the Refreshment Centre. After extracting the appliance, place the grid back in its original position. Electrical connection Warning Before starting the plug-in, make sure voltage and frequency match the related information on the rating plate and on the technical specifications table. - Page 12 Unit connection 230V AC Socket Clip to fix cord Secure water discharge tap Warning Water leakage will occur when the discharge tap is open Warning Close the water discharge tap if open. A red safety screw prevents the accidental opening of the tap. During regular appliance operation, when not otherwise indicated, the tap shall be closed and the screw inserted.
- Page 13 Unit connection Water inlet 3/4” Filter cartridge first installation Warning Make sure there are no water leaks Warning Dry well the base of the appliance before installing it into the cabinet The head of the filter cartridge is on the left side of the appliance. Remove the cap from the filter cartridge, hold the filter head tight and insert the new filter cartridge in the head by pushing it up and rotating it counter-clockwise.
- Page 14 Unit connection CO bottle first installation ₂ Warning While screwing on the new CO bottle, CO leaks might occur ₂ ₂ The CO bottle is placed on the left side of the appliance. ₂ The appliance can operate with both disposable and rechargeable CO bottles. ₂...
-
Page 15: Usage
Usage Usage Front touch control panel Warning To prevent damages to the touch control panel, do not touch it with wet or oily hands Empty CO bottle LED ₂ Power LED (to be used also during water tank draining) Ambient water LED Cold sparkling water LED Cold still water LED Ice shards LED... - Page 16 Usage Water plastic knob Water pressure gauge Make sure that the tap between the water mains and the flexible hose is open. After any pressure regulation, verify the new adjusted level by dispensing a little water. Pressure has to be regulated between 2 and 3 bar operating on the plastic knob. To regulate the pressure, pull up the water plastic knob.
-
Page 17: Maintenance And Cleaning
Usage Dispensing during normal usage Warning Do not insert any object in the ice shards nozzle. This may damage the section with consequent ice melting In order to fill a big bottle or jug, carefully pull out the water dispense nozzle. Place a glass on the drip tray, then select the desired beverage or the ice shards. - Page 18 Maintenance and cleaning Drainage of the water tank Warning If you had to stop pressing the power icon, please press it again and keep it pressed in order to complete the step Warning After the procedure always remember to close the water discharge tap to avoid water leakage 1.
- Page 19 Maintenance and cleaning 1. Remove the grid of the drip tray to easily pull out the Refreshment Centre. After extracting the appliance, place the grid back in its original position 2. Remove the safety strip of the CO holder to extract the used bottle ₂...
- Page 20 Maintenance and cleaning 3. Rotate the used filter cartridge clockwise and pull it down to extract it 4. Insert the new filter cartridge in the filter head by pushing it up and rotating it counter-clockwise 5. Turn on the power switch 6.
- Page 21 Maintenance and cleaning 6. Extract the inlet filter with rounded-jaw pliers 7. Clean the inlet filter 8. Insert the inlet filter and place it in its original position 9. Insert the water inlet hose and place it in its original position 10.
- Page 22 Maintenance and cleaning Water may come out from the filter cartridge, therefore place a cloth on the filter head and cartridge to prevent the cabinet from getting wet. If there is water on the base, dry it carefully. 4. Rotate the filter cartridge clockwise and pull it down to extract it 5.
-
Page 23: Signals For Users
Maintenance and cleaning 20. Push back the appliance until it is locked into position 21. Dispense 3 litres of cold still water 22. Dispense 1 litre of cold sparkling water 23. Dispense all ice shards Signals for users Signals for users on the front panel LED type Message Flashing LED:... -
Page 24: What To Do If
What to do if... What to do if... All repairs should be carried out by authorised technicians Warning Problem Cause Resolution Cold sparkling water sprays CO gas Carbonator limit reached Stop the dispensing and wait 20 ₂ seconds, then start dispensing again Water is not dispensed No water supply Check water supply... -
Page 25: Environment Concerns
What to do if... Pressure has to be regulated between 2 and 3 bar. Check CO pressure ₂ Warning Never exceed the indicated inlet value For further information see the chapter on first installation. Please check the gauge while dispensing cold sparkling water. Pressure has to be regulated 0.5 bar above inlet water value operating on the CO plastic knob. - Page 26 Environment concerns where you purchased the product. Packaging material The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the community waste disposal facilities. Warning When the appliance is no longer being used: •...
- Page 27 www.electrolux.com...
