- Page 1 JTGF English Français Wireless Transmitter for iPod Deutsch Transmetteur sans l pour iPod Svenska iPod用ワイヤレス トランスミ ッ ター Italiano Owner's Manual Mode d'emploi Español Bedienungsanleitung Bruksanvisning Nederlands Manual di istruzioni Manual de instrucciones Gebruiksaanwijzing 中文 取扱説明書 日本語 yitw12_om_JTGF_cover1.indd 2012/09/07 15:17:07...
- Page 2 yitw12_om_JTGF_cover1.indd 2012/09/07 15:17:07...
- Page 3 2 IMPORTANT: When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA. 3 NOTE: This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices. 4 Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures: 5 Relocate either this product or the device that is being affected by the interference. 6 Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s. 7 In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type cable. 8 If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Corporation of America A/V Division 6600 Orangethorpe Ave., Buena Park, CA 90620. 9 The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries. yitw12_om_U_caution.indd 2012/09/07 13:11:49...
-
Page 4: Compliance Information Statement (Declaration Of Conformity Procedure)
COMPLIANCE INFORMATION STATEMENT (DECLARATION OF CONFORMITY PROCEDURE) Responsible Party Yamaha Corporation of Yamaha Canada Music Ltd. America A/V Division Address 6600 Orangethorpe Avenue, 135 Milner Avenue, Toronto, Buena Park, CA 90620, USA Ontario, MIS 3R1, Canada Telephone 1-714-522-9011 1-416-298-1311 Type of Equipment Wireless Transmitter for iPod Model Name YIT-W12TX • This device complies with Part 15 of the FCC Rules and Industry Canada licence- exempt RSS standard(s). • Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received including interference that may cause undesired operation. See the “Troubleshooting” section at the end of this manual if interference to radio reception is suspected. FCC WARNING Change or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 5: For Canadian Customers
This equipment has very low levels of RF energy that are deemed to comply without testing of specific absorption ratio (SAR). This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Warranty policy for U.S. and Canada customer Your Yamaha product is covered by a limited warranty for one year from the date of purchase. In the unlikely event of failure due to defective materials or workmanship, Yamaha will repair or replace them at no charge. Please visit our website for full details. U.S.: (http://www.yamaha.com/yec/), Canada: (http://www.yamaha.ca/) FOR CANADIAN CUSTOMERS To prevent electric shock, match wide blade of plug to wide slot and fully insert. This Class B digital apparatus complies with Canadian ICES-003. Caution: Read this before operating this unit. 1 To assure the finest performance, please read this manual carefully. Keep it in a safe place for future reference. 2 Locate this unit away from other electrical appliances, motors, or transformers to avoid humming sounds. 3 Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit in an environment with high humidity (i.e. a room with a humidifier) to prevent condensation inside this unit, which may cause an electrical shock, fire, damage to this unit, and/or personal injury. 4 Avoid installing this unit where foreign object may fall onto this unit and/or this unit may be exposed to liquid dripping or splashing. On the top of this unit, do not place:... - Page 6 8 Do not attempt to modify or fix this unit. Contact qualified Yamaha service personnel when any service is needed. The cabinet should never be opened for any reasons. 9 Be sure to read the “Troubleshooting” section on common operating errors before concluding that this unit is faulty. WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. Radio waves may affect electro-medical devices. Do not use this unit near medical devices or inside medical facilities. Do not use this unit within 22 cm (9 in) of persons with a heart pacemaker implant or defibrillator implant. IMPORTANT Please record the serial number of this unit in the space below. MODEL: Serial No.: The serial number is located on the back side of the package. Retain this Owner’s Manual in a safe place for future reference. This unit may affect radio waves of iPhone when iPhone is charged by using this unit. In addition, radio waves of this unit and iPhone may interfere with each other. If you have a problem with your telephone call, disconnect your iPhone from this unit. We Want You Listening For A Lifetime Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is often undetectable until it is too late, Yamaha and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels. yitw12_om_U_caution.indd 2012/09/07...
- Page 7 About this manual • This manual describes all the “iPod” , “iPhone” and “iPad” as the “iPod” . “iPod” refers to “iPod” , iPhone” and “iPad” , unless otherwise specified. • Marks used in this manual NOTE This indicates precautions for use of the product and its feature limitations. HINT This indicates supplementary explanations for better use. The “ ” and “yAired” are trademarks of Yamaha Corporation. “Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance. iPad, iPhone, iPod, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. Windows™ Windows is a registered trademark of Microsoft Corporation in the United States and other countries. Windows XP, Windows Vista, and Windows 7 are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. yitw12_om_U.indd 2012/09/07 15:13:32...
- Page 8 Introduction YIT-W12 consists of YIT-W12TX and a dedicated USB cable. YIT-W12TX is a wireless transmitter designed for iPod series and PCs. YIT-W12TX employs the Yamaha “yAired” technology to establish a wireless connection with another Yamaha product that supports “yAired” and enables playback of the iPod or PC on your Yamaha product. Also the supplied USB cable can be used for charging the iPod connected to the transmitter, or to play music or videos for an extended time. For information on iPod and PC operating systems supported by YIT-W12TX, see “Specifications” (p.10). iPod Yamaha product that supports “yAired” NOTE Do not cover the built-in wireless antenna that is located at the lower-left corner of the transmitter. Doing so may weaken the wireless signals. Hold the iPod as illustrated on the left when operating the iPod. Do not cover the built-in wireless antenna that is located at the lower-left corner of the transmitter. Doing so may weaken the wireless signals. yitw12_om_U.indd 2012/09/07 15:13:33...
-
Page 9: Supplied Items
Supplied items USB cable (0.3 m [1 ft]) * For connecting the transmitter to a PC Wireless transmitter (YIT-W12TX) (Be sure to use the supplied USB cable when connecting the transmitter to a PC.) Setting the group ID To establish a wireless connection (yAired) between the transmitter and another Yamaha product, you need to set both the products to the same group. Change the group ID of the transmitter or your Yamaha product if their group IDs are not same. Group ID switches (on the side of the transmitter) Description A1 to A3, B1 to B3 Audio delay is less than that of the C1–C3 set. C1 to C3 Wireless connection is more stable than with the A1–A3 and B1–B3 sets. Use when playing music stored on a PC via the transmitter. NOTE • Use a blunt-tip metal tool (such as tweezers) to switch the group ID. Be careful not to get injured. yitw12_om_U.indd 2012/09/07 15:13:33... -
Page 10: Playing Back Ipod Music
Playing back iPod music Check that the transmitter and your Yamaha product are set to the same group ID. Connect your iPod to the transmitter. A wireless connection between the transmitter and your Yamaha product will be established. (Flashes green rapidly) iPod recognition in progress (Flashes green slowly) preparing for a wireless connection (Lights up green) wireless connection established (Flashes red) iPod low battery or error indication (p.7) Start playback on your iPod. -
Page 11: Charging An Ipod
• Data synchronization between the iPod and PC may start automatically when they are connected. You cannot play back iPod audio on your Yamaha product during data synchronization. Please wait until data synchronization is completed, or cancel it as necessary. Playing back PC music Check that the transmitter and your Yamaha product are set to the same group ID (C1, C2 or C3). Connect the transmitter to your PC with the supplied USB cable. USB cable (supplied) The USB driver software will be automatically installed on your PC (only the first time the transmitter is connected to the PC). - Page 12 Start playback on your PC. After a wireless connection between the transmitter and your Yamaha product is established, the Yamaha product automatically selects the transmitter (YIT) as the input source and starts to play the PC audio. (Lights up green) wireless connection established NOTE • The transmitter automatically stops if your Yamaha product is turned off or if an input source other than the transmitter is selected. To play back the PC audio again, disconnect the transmitter from the PC and then reconnect them. • If PC audio is not available on your Yamaha product, the transmitter may not be selected as the audio playback device on your PC. Check the audio device settings on your PC. For details, refer to the manuals of the PC. • Do not use a USB hub when connecting the transmitter to a PC. • You cannot play back PC audio on your Yamaha product when an iPod is connected to the transmitter. HINT • Your Yamaha product automatically turns on if you start playback on your PC. • Some Yamaha products will terminate the wireless connection and turn off automatically if a certain period of time elapses after PC playback is stopped. • You can enjoy videos on the PC monitor. Updating the firmware of the transmitter New firmware that provides additional features or product improvements will be released as needed. Updates can be downloaded from our website. Please check our website regularly for Information.
-
Page 13: Troubleshooting
Refer to the table below when the unit does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, contact the nearest authorized Yamaha dealer or service center. First, check the following: The power cable of your Yamaha product is connected to an AC wall outlet securely. The latest firmware is installed on the transmitter or your iPod. Problem/Cause Remedy A wireless connection cannot be made. (The green indicator is off.) Your iPod is not connected to the Reconnect the iPod to the transmitter. - Page 14 There is a device using 2.4-GHz band Move those devices away from the range (such as microwave ovens, transmitter and your Yamaha product, or cordless phones and Wi-Fi devices) turn off the power of the wireless devices. If nearby. you are using a wireless router, change the wireless channel to the highest one (e.g. 13 ch). No sound is coming from the Yamaha product although a wireless connection is established. The volume of your Yamaha product is Turn up the volume. too low. The mute function is activated on your Cancel the mute function. Yamaha product. An input source other than the Select the transmitter (YIT) as the input transmitter (YIT) is selected on your source. Yamaha product. Headphones are connected to your Disconnect the headphones from the iPod.
- Page 15 No sound is coming from the Yamada product when playing back music stored on an iPod. Your iPod is not connected to the Reconnect the iPod to the transmitter. transmitter firmly. The volumes of the iPod and Yamaha product are not reflected one another. Your iPod is not connected to the Reconnect the iPod to the transmitter. transmitter firmly. No sound is coming from the Yamada product when playing back music stored on a PC.
-
Page 16: Specifications
PC (Operating System) Windows 7, Windows Vista, Windows XP (as of June 2012) Mac OS X (10.6 or later) Power Consumption 0.3 W or less Allowable Current 2.1 A or less Connector Dock connector, Micro USB 48 kHz (iPod/iPhone/iPad) Sampling Frequency 32 kHz, 44.1 kHz, 48 kHz (PC) Frequency Band 2.4 GHz Refer to the manual of your Yamaha product connected Transmission Range to the transmitter. Transmission Delay Group ID (A/B): 12 msec, Group ID (C): 50 msec Dimensions (W x H x D) 40 x 38.5 x 10 mm (1-5/8” x 1-1/2” x 3/8”) Weight 10.3 g (0.36 oz) * Specifications are subject to change without notice. yitw12_om_U.indd 2012/09/07 15:13:34... - Page 17 © 2012 Yamaha Corporation Printed in Malaysia ZE03990 yitw12_om_U_cover4.indd 2012/09/03 20:47:57...
