Thank you for purchasing a Panasonic product.
This document explains how to operate the access keypad properly.
For details about how to use the system, refer to the User's Guide
(page 16).
Please read this document before using the unit and save it for future
reference.
Operating Instructions
Home Network System
KX-HNK101FX
Model No.
Access Keypad
Advertisement
Table of Contents
Related Manuals for Panasonic KX-HNK101FX
Summary of Contents for Panasonic KX-HNK101FX
- Page 1 Home Network System Access Keypad KX-HNK101FX Model No. Thank you for purchasing a Panasonic product. This document explains how to operate the access keypad properly. For details about how to use the system, refer to the User’s Guide (page 16).
-
Page 2: Table Of Contents
Table of Contents Introduction Accessory information ....3 Important Information About this system ......4 For your safety ......4 Important safety instructions ..5 For best performance ....5 Other information .......6 Setup Part names and functions ..8 Touchpanel buttons ....8 LED indicator ......9 Setup overview ......9 Registering the keypad ....9 Confirming the usage area ..10... -
Page 3: Introduction
Introduction Accessory information Supplied accessories Accessory item/Part number Quantity AC adaptor/PNLV226CE Mounting bracket Wall mounting screws (25 mm) Wall anchors The mounting bracket is attached to the product at the time of shipment. Other information R Design and specifications are subject to change without notice. R The illustrations in these instructions may vary slightly from the actual product. -
Page 4: Important Information
These conditions can Panasonic will not be held cause fire or electric shock. Confirm responsible in the event that that smoke has stopped emitting... -
Page 5: Important Safety Instructions
The hub and other compatible do so. Hospitals or health care Panasonic devices use radio waves to facilities may be using equipment communicate with each other. that could be sensitive to external R For maximum coverage and RF energy. -
Page 6: Other Information
Important Information R If the reception for a hub location is R Do not use any cleaning products not satisfactory, move the hub to that contain alcohol, polish powder, another location for better reception. powder soap, benzine, thinner, wax, petroleum, or boiling water. Also do not spray the product with Environment insecticide, glass cleaner, or hair... - Page 7 Important Information your dealer or supplier for further information. Information on Disposal in other Countries outside the European Union This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal.
-
Page 8: Setup
Setup Part names and Touchpanel buttons functions These buttons allow you to confirm and change the system’s arm mode. During normal operation, the button that corresponds to the current arm mode is lit by default, and all other buttons are dimmed. -
Page 9: Led Indicator
Setup LED indicator Registering the keypad You can use the LED indicator to confirm the keypad’s status. This procedure is not required for Indicator Status devices that were included as part of a bundle. Normal operation, or no power Before you can use the keypad, it must Red, Keypad is not be registered to the hub. -
Page 10: Confirming The Usage Area
Setup Using the app Usage area cautions When you register the keypad by using Using the keypad in the following areas the [Home Network] app, you can may cause deformation, malfunction, or assign a name to your devices and operational failure. group them by location. -
Page 11: Installation
Setup Installation To mount the keypad flat against the wall, use the mounting bracket. Note: R Mount the keypad on the stable location where the keypad can be adequately supported when mounting. R Do not mount keypad on a soft material. It may fall down, break, or cause injury. R Do not mount the keypad on a plywood surface that is less than 25.4 mm thick. - Page 12 Setup Place the mounting bracket against the wall and determine where the mounting bracket will be installed. Mark the screw openings on the wall. R Refer to the information below. The dotted lines indicate where the edges of the keypad will be in relation to the mounting bracket. 16 mm 59 mm 19 mm...
- Page 13 Setup Installing the mounting bracket Installing the mounting bracket on wooden walls Line up the holes on the mounting bracket with the holes in the wall, then insert and tighten each screw. Note: R Use the supplied screws ( R Place the bracket with the “UP” mark facing upwards. Installing the mounting bracket on gypsum board, ALC (autoclaved lightweight cellular concrete), or concrete blocks Use the supplied anchors and screws to mount the mounting bracket to the wall.
- Page 14 Setup Insert the anchor into the hole so that it is flush with the wall surface. Line up the holes on the mounting bracket with the anchors, then insert and tighten each screw. R Use the supplied screws ( R Place the bracket with the “UP” mark facing upwards. Installing the keypad to the mounting bracket Attach the keypad to the bracket.
- Page 15 Setup Connecting the AC adaptor Note: R Use only the supplied Panasonic AC adaptor PNLV226CE. Connect the AC adaptor plug to the keypad until you hear a click (A) and connect the AC adaptor to the power outlet (B). Note about power connections AC adaptor connection R The AC adaptor must remain connected at all times.
-
Page 16: Appendix
Appendix To cancel the trigger, tap the touchpanel, enter the disarm PIN Using the keypad (default: “0000”), and then tap MOKN. Changing the arm mode Talking notification feature Tap the touchpanel to light the arm This feature allows you to get mode buttons. -
Page 17: Specifications
8 and earlier versions are not supported. R Android 4.1 or later versions are recommended. R You can also access the User’s Guide at the web page listed below. www.panasonic.net/pcc/support/tel/ homenetwork/manual/ Specifications R Standards DECT (Digital Enhanced Cordless Telecommunications) R Frequency range 1.88 GHz –... - Page 18 Notes...
- Page 19 Notes...
- Page 20 We recommend keeping a record of the following information to assist with any repair under warranty. Serial No. Date of purchase (found on the rear of the unit) Name and address of dealer Attach your purchase receipt here. © Panasonic Corporation 2016 PNQP1213YA CC0216WK1126...
