- Page 1 Desktop Monitor MultiSync EX241UN User’s Manual MODEL: EX241UN, EX241UN-BK The regulations for this monitor applied to one of model names listed above. Please find your model name in the label on the rear side of the monitor.
-
Page 2: Table Of Contents
Index WARNING ............................English-1 CAUTION .............................English-1 Registration Information .......................English-3 Recommended use ........................English-4 Safety Precautions and Maintenance ..................English-4 Ergonomics ..........................English-5 Cleaning the LCD Panel .......................English-5 Cleaning the Cabinet ......................English-5 Quick Start ............................English-6 ControlSync ..........................English-12 Multiple monitors connection using DisplayPort ................English-14 Controls ............................English-15 Specifications ..........................English-24 Features ............................English-25 Troubleshooting ..........................English-26... -
Page 3: Warning
CAUTION: Please use the power cord provided with this display in accordance with the power cord table. If a power cord is not supplied with this equipment, please contact NEC. For all other cases, please use the power cord with the plug style that matches the power socket where the monitor is located. - Page 4 (4) The image shown in this user’s manual is indicative only. If there is inconsistency between the image and the actual product, the actual product shall govern. (5) Notwithstanding articles (3) and (4), NEC will not be responsible for any claims on loss of profit or other matters deemed to result from using this device.
-
Page 5: Registration Information
WARNING: The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government regulation could void your right to operate this equipment. -
Page 6: Recommended Use
NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use. -
Page 7: Ergonomics
CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for the display to warm up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen. -
Page 8: Quick Start
Quick Start For contents, please refer to the contents sheet. To attach the Base to the LCD stand: 1. Place monitor face down on a non-abrasive surface (Figure 1). 2. Please rotate the stand 90 degrees as shown in Figure 1. NOTE: Handle with care when pulling the stand. - Page 9 4. Connect all cables to the appropriate connectors (Figure C.1). When using the USB cable, connect the B type connector to the USB upstream port on the right back side of the monitor and the A type connector to the downstream port on the computer (Figure C.1a).
- Page 10 8. Connect one end of the power cord to the AC inlet on the back of the monitor and the other end to the power outlet. NOTE: Please refer to the CAUTION section of this manual for proper selection of AC power cord. 9.
- Page 11 Tilt and Swivel Grasp the top and bottom sides of the monitor screen with your hands and adjust the tilt and swivel as desired (Figure TS.1). Figure TS.1 NOTE: Handle with care when tilting the monitor screen. Do not insert hand into tilt cover when adjusting the monitor screen tilt. Flexible Arm Installation This LCD monitor is designed for use with a flexible arm.
- Page 12 Mount Flexible arm This LCD monitor is designed for use with a flexible arm. 1. Follow the instructions on how Remove Monitor Stand for Mounting to remove the stand. 2. Using the specified 4 screws, attach the arm to the monitor (Figure F.1). Spring washer 12 mm Flat washer...
- Page 13 Installing Optional Sensor This monitor is designed for using with a human and brightness optional sensor. Fixed by screw: Remove the screw from the monitor hole. Secure the optional sensor using the attached screw. For fixing the optional sensor within the bezel, it is recommended using screw holes as below mentioned. Fixed by double-sided tape: You can set the optional sensor at any side of the monitor.
-
Page 14: Controlsync
ControlSync ControlSync works controlling all connected sub monitors from master monitor simultaneously but also controlling a target monitor from master monitor by setting INDIVIDUAL ADJUST function (see page 22). Controlling all connected sub monitor (Synchronized control): 1. Connect the master monitor with a sub monitor via a ControlSync cable (ø 2.5) into ControlSync IN/OUT. 2. - Page 15 The following settings can be controlled by ControlSync: Synchronized control Individual adjust ECO TOOLS BRIGHTNESS* CONTRAST ECO MODE AUTO BRIGHTNESS BLACK LEVEL OFF MODE SETTING OFF MODE SENSOR SETTING OFF MODE START TIME HUMAN SENSING HUMAN SENSOR START TIME DV MODE SCREEN AUTO ADJUST AUTO CONTRAST...
-
Page 16: Multiple Monitors Connection Using Displayport
Multiple monitors connection using DisplayPort You can connect multiple monitors by using DisplayPort daisy-chain connection. For using as multiple monitors in MST (multi-stream transport) mode, setting should be DP OUT MULTISTREAM “AUTO” at each connected monitor. Please change the monitor setting which is connected to a computer last in the connected monitors. If monitors have no image, turn off the monitor who is connected to a computer then turn it on. -
Page 17: Controls
Controls OSD (On-Screen Display) control keys on the back of the monitor function are as follows: To access OSD menu, press any of the control keys. To change signal input, press the INPUT/SELECT key. NOTE: Exit OSD in order to change signal input. 1 Power LED Indicates that the power is on or off. - Page 18 ECO TOOLS BRIGHTNESS Adjusts the overall image and background screen brightness. If ECO MODE is set to 1 or 2, a bar for CARBON FOOTPRINT will appear. CONTRAST Adjusts the overall image and background screen brightness by input signal level. NOTE: When L/B is selected in COLOR control, CONTRAST is disabled.
- Page 19 HUMAN SENSING (Option sensor only) The sensor detects the movement of a person by using the HUMAN SENSING function. The HUMAN SENSING has three settings: OFF: No human sensing. 1 (LIGHT): After it is detected that there is no person after a period of time, the monitor shifts to low brightness mode automatically to reduce the power consumption.
- Page 20 FINE (Analog input only) Improves focus, clarity and image stability by increasing or decreasing this setting. If the “Auto Adjust” function and the “H.SIZE” function do not give you a satisfactory picture setting, a fine tuning can be performed by using the “FINE” function. For this a Moiré...
- Page 21 Color Color Control System: Color presets are available for adjusting color settings. 1, 2, 3, 4, 5: Increases or decreases Red, Green or Blue color depending upon which is selected. The change in color will appear on screen and the direction (increase or decrease) will be shown by the bars. sRGB (color preset mode [4]) dramatically improves the color fidelity in the desktop environment by a single standard RGB color space.
- Page 22 LED BRIGHTNESS You can adjust the blue LED brightness. DDC/CI This function allows the DDC/CI function ON or OFF. USB POWER Selects a power relation of USB. AUTO: Power is supplied to USB downstream port depending on related power condition. ON: Power is always supplied to USB downstream port even when in power save mode or power OFF.
- Page 23 CUSTOMIZE SETTING Store the current settings for easy recovery. To store current settings: Press the “INPUT/SELECT” key. After a warning message appears, press the “ECO/ RESET” key, current settings are stored. To restore settings: Hold “CENTER/EXIT” for 3 seconds or more while the OSD menu is off. MULTI DISPLAY Allows one image to be expanded and displayed over multiple screens (up to 25) through a distribution amplifier.
- Page 24 TILE COMP Works in tandem with TILE MATRIX to compensate for the width of the tile bezels in order to accurately display the image. TILE COMP with 4 monitors (black area shows monitor frames): Monitor 1 Monitor 2 Monitor 1 Monitor 2 Monitor 3 Monitor 4...
- Page 25 ECO Information CARBON SAVINGS: Displays the estimated carbon savings information in kg. CARBON USAGE: Displays the estimated carbon usages information in kg. This is the arithmetic estimation, not actual measurement value. COST SAVINGS: Displays the electricity cost savings in balance. CARBON CONVERT SETTING: Adjusts the carbon footprint factor in the carbon saving calculation.
-
Page 26: Specifications
@ 60 Hz to 75 Hz 1400 x 1050* @ 60 Hz to 75 Hz 1440 x 900* @ 60 Hz 1920 x 1080 @ 60 Hz........... NEC DISPLAY SOLUTIONS cites recommended. Active Display Area Landscape: Horiz.: 527.04 mm/20.7 inches Vert.: 296.46 mm/11.7 inches... -
Page 27: Features
Note: The manufacturing and operating carbon footprints are calculated by a unique algorithm developed exclusively by NEC for its monitors and are accurate at the time of printing. NEC reserves the right to publish updated carbon footprint values. ControlSync: Follow the steps of “DATA COPY” and copy the settings from the master monitor to the sub monitors by connecting the ControlSync cable. -
Page 28: Troubleshooting
NOTE: As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use. - Page 29 Display image is not sized properly • Use the OSD Image Adjust controls to increase or decrease the Coarse adjustment. • Check to make sure that a supported mode has been selected on the display card or system being used. (Please consult display card or system manual to change graphics mode.) •...
-
Page 30: Using The Zoom Function
Using the Zoom Function Allows you to use the entire screen area, significantly expanding the size. Allows the picture displayed in the center to expand. SETUP 1. Select FULL or ASPECT in EXPANSION to activate the Zoom function (see page 18). EXPANSION OFF 2. -
Page 31: Multi Display Setting
Multi Display setting You can display a image by using multiple monitors with any input signals. [Example of V MONITOR 5, H MONITOR 5 (See page 21)] 1. Press the CENTER/EXIT key to display OSD menu. 2. Move the LEFT/RIGHT key left or right to select MULTI DISPLAY. 3. - Page 32 Using ControlSync function with multi screen configuration To control sub monitor from master monitor, control buttons of the master monitor is used. Please install master monitor at accessible place. Mounting multi screen configuration When monitors are used in a multi screen configuration for a longer time, slight expansion of the displays may happen due to temperature changes.
-
Page 33: Human Sensing Function (Option Sensor Only)
Human sensing function (Option sensor only) Human sensing function reduces power consumption by detecting the movement of a person. The HUMAN SENSING has following two settings: MODE HUMAN SENSING SETTING No person in front of the monitor LIGHT BRIGHTNESS 0% DEEP Power saving mode Image of human sensing operation... -
Page 34: Using The Auto Brightness Function (Option Sensor Only)
Using the Auto Brightness function (Option sensor only) The brightness of the LCD screen can be set to increase or decrease depending on the amount of ambient lighting within the room. If the room is bright, the monitor becomes correspondingly bright. If the room is dim, then the monitor will dim accordingly. The purpose of this function is to make the viewing experience more comfortable to the eye in a variety of lighting conditions. -
Page 35: Manufacturer's Recycling And Energy Information
Dedicated recycling sites ensure that environmentally harmful components are properly handled and securely disposed. To ensure the best recycling of our products, NEC DISPLAY SOLUTIONS offers a variety of recycling procedures and gives advice on how to handle the product in an environmentally sensitive way, once it has reached the end of its life.
