Before operating this product, please read these instructions carefully and save this document
for future use.
Operating Instructions
Model No.
Contents
Read Me First .............................................. 2
1. Getting Started ........................................ 3
Precautions................................................ 3
Name of each part & function.................... 6
2. Operation................................................. 7
Battery Installation ..................................... 7
Paper Installation....................................... 7
AC cable Set Up ........................................ 8
Charging Battery........................................ 9
3. Appendix................................................ 10
Troubleshooting ....................................... 10
How to care ............................................. 11
How to attach the Option parts ................ 11
Specifications........................................... 12
Warranty Policy........................................ 13
Compliance Notice .................................. 13
PRINTER
JT-H300PR-U1
Advertisement
Table of Contents
Related Manuals for Panasonic JT-H300PR-U1
Summary of Contents for Panasonic JT-H300PR-U1
-
Page 1: Table Of Contents
Operating Instructions PRINTER JT-H300PR-U1 Model No. Contents Read Me First ..........2 1. Getting Started ........3 Precautions..........3 Name of each part & function....6 2. Operation..........7 Battery Installation ........7 Paper Installation........7 AC cable Set Up ........8 Charging Battery........ -
Page 2: Read Me First
Read Me First Introduction Thank you for purchasing the series Panasonic Printer. JT-H300PR This manual describes the instructions for the printer. Please read this manual carefully before using this product. What’s in the Box? Printer (Battery is not included.) Safety Precautions Options 1. -
Page 3: Getting Started
1. Getting Started Precautions [Printer: JT-H300PR-U1] 1. Avoid Radio Frequency Interference Do not place the printer near a television or radio receiver. 2. Avoid Stacking Do not place heavy objects on the printer. 3. Keep Small Objects Away Do not insert paper clips or other small objects into the printer. - Page 4 Precautions [Battery Pack: JT-H100DP-50] 〔For Sales rep or service bench〕 1. Avoid Heat Do not throw the battery pack into a fire or expose it to excessive heat. Failure to observe this may cause fire or explosion. 2. Keep Articles Away Do not place the battery pack together with articles such as necklaces or hairpins when carrying or storing.
- Page 5 Precautions [AC Adaptor: JT-H300AD-P1] 1. Do Not Disassemble Do not attempt to disassemble the charger. Failure to observe this may cause electric shock or fire. 2. Keep Dry Failure to observe this may cause heat or fire. 3. Do Not Use With Any Other Device The AC Adaptor is designed for the specified JT-H300PR printer.
-
Page 6: Name Of Each Part & Function
Name of each part & function Paper Out Status LED Paper Cover Lever Power Switch Status Feed Receiving IrDA I/F Receiving LED Feed (Press button to feed paper) Paper Cover DC IN 9.5 V Jack USB Port Indicate Status Normal status. 1. -
Page 7: Operation
. Operation Paper Installation Slide the Paper Cover Lever Open the Paper Cover Install Paper (Paper must be tightly rolled and be confirmed that dust/sand is not on.) Close the Paper Cover (Make sure that the Cover is closed completely.) 3) Paper... -
Page 8: Ac Cable Set Up
AC cable Set Up Please attach the core to the AC cable, before using the AC adaptor. The core is included in the AC adaptor (JT-H300AD-P1). AC Adaptor How to connect USB cable 1) Pull the Connector Cover. 2) Connect the plug of USB cable (JT-H300CC-P1), to the USB connector of the printer. <Note>... -
Page 9: Charging Battery
Charging Battery [By AC Adaptor] 1) Pull the Connector Cover. 2) Connect the plug of AC adaptor, to the DC jack of the printer. <Note> Don’t open the battery cover. -
Page 10: Appendix
3. Appendix Troubleshooting Symptom Possible Cause Solution No Power in 1. Has the battery fully inserted? 1. Charge the battery pack. Printer 2. Is the Power Switch on? 2. Move the Power Switch on. 1. Is the power turned on? 1. -
Page 11: How To Care
How to care <How to clean up the thermal head and the rubber roller. > Push the paper cover lever to open the paper cover. Wipe off any dust/dirt using the cotton swab with a small amount of alcohol (ethanol). (Do not use thinner, benzene series or kerosene series.) Close the cover after alcohol volatilizes. -
Page 12: Specifications
[ Printer:JT-H300PR-U1 ] Items Description Specifications Mechanical Printing Line Thermal Printing Speed Max. 106 mm/Sec (Panasonic Test Standard) Head Printing Width 48 mm (384 dots/ line) Character font 12 x 24 dots (standard) Printing Font Type Alpha-numeric, Barcode, 2D code Function ８... -
Page 13: Warranty Policy
Warranty Policy The warranty period and what is covered are according to the application, contract or distributor. Please ask our sales rep. <NOTE> The out of term warranty is as follows: - Any secondary damages as for the loose of Printing paper, data or business chances. - Any damages by user including dropping, water contact or any other wrong use, other than the purpose designed for. - Page 14 For USA Federal Communications Commission Notices This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 15 For CANADA Industry Canada Statement This device complies with Industry Canada ICES-003 and RSS210 rules. Operation is subject to the following two conditions: 1. This device may not cause interference and 2. This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 16 Panasonic Solutions Company Unit of Panasonic Corporation of North America One Panasonic Way Secaucus, NJ 07094 The operation instructions can be downloaded from following URL. http://www.panasonic.net/pss/ht/jt-h300pr.html Specifications and manuals are subject to change without notice. Panasonic System Networks Co., Ltd.
