QW15W714
USER
MANUAL
EN
User Manual
Washing Machine

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna QW15W714

Summary of Contents for Husqvarna QW15W714

  • Page 1 QW15W714 User Manual Washing Machine USER MANUAL...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS................33 DEAR CUSTOMER Thank you for choosing this Husqvarna-Electrolux product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    This appliance is intended to be used in household • and similar applications such as: staff kitchen areas in shops, offices and other – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments;...
  • Page 5 ENGLISH future they must be reattached to lock be replaced, this must be carried out the drum to prevent an internal by our Authorised Service Centre. damage. • Connect the mains plug to the mains • Always take care when moving the socket only at the end of the appliance as it is heavy.
  • Page 6 • Do not wash fabrics which are heavily hinge and seals, other seals, door soiled with oil, grease or other greasy locking assembly, plastic peripherals substances. It can damage rubber such as detergent dispensers. Please parts of the washing machine.

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 Appliance overview 11 12 Worktop Drain hose Detergent dispenser Inlet hose connection Control panel Mains cable Door handle Transit bolts Rating plate Hose support Quick Reminder sticker Feet for levelling the appliance The rating plate reports the model name (A), product number (B),electrical ratings (C) and serial number (D).

  • Page 8: Installation

    Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐ ture Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 8 bar (0.8 MPa)
  • Page 9 ENGLISH 2. Loosen or tighten the feet to adjust the WARNING! level. All feet must rest firmly on the floor. It is possible to see water flowing from the WARNING! drain hose. This is Do not put cardboard, wood because the washing or equivalent materials machine has been below the appliance feet to...
  • Page 10 The drain hose should stay at a height of no less than 60 cm and not more than 100 cm. You can extend the drain hose to maximum 400 cm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Accessories

    6. ACCESSORIES 6.1 Fixing plate kit If you install the appliance on a plinth that is not an accessory supplied by HUSQVARNA, secure the appliance in the fixing plates. Read carefully the instructions supplied with the accessory. 6.2 Stacking kit...

  • Page 12: Control Panel

    WARNING! Do not put the tumble dryer under the washing machine. Verify the compatible stacking kit by checking the depth of your appliances. 7. CONTROL PANEL 7.1 Special features This appliance is designed with a self cleaning draining system, allowing light...

  • Page 13: Programme Chart

    ENGLISH 7.3 Display A. The time area: • Programme time. • The alarm codes. Refer to the chapter “Troubleshooting” for their description. • The level of the FlexiTime B. The Delay Start indicator. C. The Child Lock indicator. D. The Door Lock indicator: •...
  • Page 14 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Denim 800 rpm 3 kg Special programme for Denim clothing 30 °C (1200 - 800 with delicate washing phase to mini‐...
  • Page 15 ENGLISH Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 60min EasyWash 1400 rpm 5 kg Cotton and fast-coloured synthetic items. 30°C (1400- 800 Complete washing programme that, in only 60°C - 30°C rpm) 60 minutes, washes the daily soiled laun‐...

  • Page 16: Options

    Programme ■ ■ ■ Rapid 30min ■ ■ ■ ■ ■ 60min EasyWash Suitable detergents for washing programmes Universal Liquid Uni‐ Liquid for Delicates Programme Special versal coloureds woollens powder Eco 40-60 ▲ ▲ ▲ Cottons ▲ ▲ ▲...
  • Page 17 ENGLISH • Set this option for very delicate This option increases the fabrics. programme duration. • The rinses phase uses more water for some washing programmes. The corresponding indicator illuminates. Rinse Hold 9.6 Night • Set this option to prevent the laundry creases.

  • Page 18: Settings

    (max. half load recommended). to wash quickly items with almost no soil. The Time Manager is available only with the programmes in the table. ■ ■ ■ ■ ■ ■ ■ ■ ■...

  • Page 19: Before First Use

    ENGLISH 11. BEFORE FIRST USE 1. Connect the mains plug to the mains During installation or before socket. first use you may observe 2. Open the water tap. some water in the appliance. 3. Put a small quantity of detergent in This is residual water left in the compartment for washing phase.
  • Page 20 12.2 Filling the detergent and additives Compartment for washing phase. If you use liquid detergent, put it immediately before you start the programme. Compartment for liquid additives (fabric conditioner, starch). Maximum level for quantity of liquid additives. Flap for powder or liquid deter‐...
  • Page 21 ENGLISH • The indicator flashes. • The display shows the level of the Time Manager, the programme duration and the indicators of the phases of the programme. 2. If necessary, change the temperature and the spin speed or add available options.
  • Page 22 • The door locks, the display shows 3. Press again. the indicator The programme continues. • When the countdown is 12.9 Cancelling a running completed, the programme starts automatically. programme You can cancel or change 1. Turn the programme knob to position...

  • Page 23: Hints And Tips

    ENGLISH 2. Wait for some minutes and then open 1. Press . The appliance drains the the appliance door. water and spins. 3. Close the appliance door. 2. When the programme is completed, 4. Set the programme again. the door lock indicator flashes for a few minutes.
  • Page 24 13.3 Detergent type and a. interrupt the programme and open the door (refer to "Daily quantity Use" chapter); b. manually redistribute the load so The choice of detergent and use of that the items are spaced evenly correct quantities not only affects your around the tub;...

  • Page 25: Care And Cleaning

    ENGLISH 13.4 Ecological hints • Set the maximum possible spin speed for the selected washing To save water, energy and to help programme before drying your protect the environment, we recommend laundry in a tumble dryer. This will that you follow these tips: save energy during drying! •...
  • Page 26 14.6 Cleaning the drum with double lip trap', 'Cleaning the drum' and 'Cleaning the inlet hose and the Regularly examine the drum to prevent valve filter' paragraphs. If necessary, unwanted deposits. please contact the Authorised Service Centre. Rust deposits in the drum may occur due to rusting foreign body in the washing or 14.3 External cleaning...
  • Page 27 ENGLISH Check and remove objects (if there are any) that could be trapped in the fold. Make sure that no laundry remains between the seal and the door. Use a moist cloth to wipe off any dirt or water residue left behind in the door seal after completion of program cycle.

  • Page 28: Consumption Values

    45° 20° 14.10 Frost precautions 5. When the drain pump is empty, install the inlet hose again. If the appliance is installed in an area WARNING! where the temperature can be less than Make sure that the 0° C, remove the remaining water from temperature is higher than the inlet hose and the drain pump.
  • Page 29 ENGLISH 15.2 Legend Laundry load. h:mm Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of spinning phase. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture. Values and programme duration may differ depending on different conditions (e.g.

  • Page 30: Troubleshooting

    Programme Litres h:mm °C Cottons 1.60 3:00 1400 60°C Cottons 0.40 2:45 1400 20°C Synthetics 0.65 2:00 1200 40°C Delicates 0.30 1:20 1200 30°C Wool 0.30 1:05 1200 30°C 1) Reference indicator of the spin speed. 2) Suitable for washing heavily soiled textiles.
  • Page 31 ENGLISH • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. The appliance does For this information, contact your local water authority. not fill with water prop‐ •...
  • Page 32 Problem Possible solution • Make sure that the mains plug is connected to the mains socket. • Make sure that the appliance door is closed. • Make sure that there is no damaged fuse in the fuse box. The programme does •...

  • Page 33: Environmental Concerns

    ENGLISH Problem Possible solution • Increase the detergent quantity or use a different detergent. • Use special products to remove the stubborn stains before The washing results you wash the laundry. are not satisfactory. • Make sure that you set the correct temperature. •...
  • Page 36 www.husqvarna-electrolux.se/shop...
