Chapter 4: Connecting The Wireless-G Internet Video Camera For Setup; Overview; Connection To A Wired Network For Setup; Connection To A Wireless Ad-Hoc Network For Setup - Cisco Linksys WVC54G User Manual

Wireless-G Internet Video Camera
Chapter 4: Connecting the Wireless-G Internet Video Camera
for Setup

Overview

Before you set up the Camera, connect it to a wired or wireless network. Proceed to the appropriate section for
your setup.
If you need to move the Camera from a wired network to a wireless network, or vice versa, go to this section,
"Moving the Camera to a Different Network."

Connection to a Wired Network for Setup

1. Attach the antenna.
2. Connect the Ethernet network cable to your router, switch, or computer.
3. Connect the other end of the cable to the Ethernet port on the Camera. See Figure 4-1.
4. Connect the power adapter to the Power port on the Camera.
5. Plug the power adapter into an electrical outlet.
The Camera's Ready LED flashes while the Camera is initializing. The Camera is ready for use when the Ready
and Ethernet LEDs are solidly lit.
Proceed to "Chapter 5: Setting up and Mounting the Wireless-G Internet Video Camera."

Connection to a Wireless Ad-Hoc Network for Setup

1. Make sure your computer has the following wireless settings:
• SSID - linksys
• Network Mode - Ad-Hoc
• Channel - 6
• WEP - Disabled
2. Attach the antenna.

Chapter 4: Connecting the Wireless-G Internet Video Camera for Setup

Overview

Figure 4-1: Connect the Ethernet Network Cable

NOTE: You MUST connect the Camera to a PC,
router, or switch using the Ethernet network
cable BEFORE powering on the Camera.
Otherwise, the Camera will not function.

Figure 4-2: Connect the Power Adapter

8
