- Page 1 FLEXIDOME IP starlight 8000i NDE‑8502‑R | NDE‑8502‑RT | NDE‑8503‑R | NDE‑8503‑RT | NDE‑8504‑R | NDE‑8504‑RT | NDE‑8502‑RX | NDE‑8502‑RXT | NDE‑8503‑RX | NDE‑8503‑RXT Installation manual...
-
Page 3: Table Of Contents
Password protection in camera Troubleshooting Resolving problems Testing the network connection Customer service Maintenance 10.1 Bubble handling 10.2 Bubble cleaning 10.3 Bubble replacement 10.4 Camera reset Decommissioning 11.1 Transfer 11.2 Disposal Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... - Page 4 | Table of contents FLEXIDOME IP starlight 8000i Technical data 12.1 Dimensions 12.2 Specifications Support and training 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
-
Page 5: Safety
Electrical Code (NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1), and all applicable local codes. Bosch Security Systems accepts no liability for any damages or losses caused by incorrect or improper installation. Important safety instructions –... -
Page 6: Power Connection In Applications
NEC725 and NEC800 (CEC Rule 16-224 and CEC Section 60). Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. - Page 7 Les antennes pour ce transmetteur doivent être installé en considérant une distance de séparation de toute personnes d'au moins 20 cm et ne doivent pas être localisé ou utilisé en conflit avec tout autre antenne ou transmetteur. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
- Page 8 FLEXIDOME IP starlight 8000i Simplified EC DoC (European Union) Hereby, Bosch declares that the radio equipment type FLEXIDOME IP starlight 8000i is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.boschsecurity.com / (Product Catalog) / (Region) / (Country) / (Search for Product No.).
-
Page 9: Short Information
Bosch Security Systems accepts no liability for damage resulting directly or indirectly from faults, incompleteness or discrepancies between this manual and the product described. Copyright This manual is the intellectual property of Bosch Security Systems and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly. -
Page 10: System Overview
You can permanently disable the WLAN functionality in the device if required. Notice! This permanently disables the WLAN functionality. You must send the device to a Bosch service center to re-enable the WLAN functionality. To permanently disable the WLAN functionality, obey the following steps: Navigate to the Configuration page. - Page 11 FLEXIDOME IP starlight 8000i System overview | en Click Service. Click Licenses. Locate the Activation key field. Enter the following key: 12-01.6B.01-CF47F87B-B082146B-D79F9999- C40ED3E9-0E31AA55 Click Set. The WLAN functionality is now permanently disabled. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
-
Page 12: Preparing For Installation
This equipment should be unpacked and handled with care. If an item appears to have been damaged in shipment, notify the shipper immediately. Verify that all parts are included. If any items are missing, notify your Bosch Security Systems sales or customer service representative. - Page 13 The necessary cables are ready for use (refer to Wiring, page 14 for more information): – Network cable. – 24V AC / 12-26V DC (optional) – Audio input cables (optional). – External inputs (optional). Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
-
Page 14: Wiring
If auxiliary power (24V AC / 12-26V DC) and PoE is applied simultaneously, the camera draws its power from PoE by default, and seamlessly switches to auxiliary input if PoE power fails. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual... -
Page 15: 24V Ac / 12-26V Dc Power Input
Use the alarm output for switching external devices such as lamps or sirens. The alarm output switching capability has a maximum voltage of 30V AC or +40V DC; maximum 0.5 A continuous, 10 VA. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... -
Page 16: Grounding
Grounding provides improved surge protection (up to 1 kV, 2 kA to ground (8/20 µs pulse)). The grounding wire is not included in the box. Bosch recommends the use of a grounding wire with a ring terminal. -
Page 17: In-Box Configuration
B - Connect and configure the camera via the wired network by using the web interface , the Project Assistant app or the Configuration Manager. For more detail about the Project Assistant app, refer to Commissioning, page 34 . Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... -
Page 18: Hardware Installation
The installation of the camera follows these steps: Installing the mounting plate, page 19 . Installing the camera base, page 23 . Installing the camera module, page 29 . 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual... -
Page 19: Installing The Mounting Plate
Additionally, the camera can cover various mounting options when combined with the available accessories. See the Mounting accessories, page 31 chapter for the available accessories. Notice! The plugs and screws for surface mounting are not supplied with the camera. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... -
Page 20: Installing The Mounting Plate Without Conduit
Put the cable through the center hole of the mounting plate. Attach the mounting plate to the surface with 4 screws. Tighten the screws between 4 and 7 Nm (3 and 5.2 lbfft). 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual... -
Page 21: Installing The Mounting Plate With Conduit
If the conduit or cable diameter is smaller than M20, use the rubber adapter with the conduit plate adapter with the larger hole. The rubber must be perforated to put the conduit or cable through. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... - Page 22 11. Install 4 plugs in the holes. 12. Attach the mounting plate to the surface with 4 screws. Tighten the screws between 4 and 7 Nm (3 and 5.2 lbfft). 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
-
Page 23: Installing The Camera Base
If the installation of the mounting plate was done with the conduit, remove the door on the camera base as shown in the image. Keep the screw and lid. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... - Page 24 1 Network cable inlet. 2 Secondary cable inlet for additional cabling. It is waterproof if not in use. 3 Protective breathing vents. Do not remove or break the sealing from these holes. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 25 Hold the camera base and attach the screw with the grounding cable. 0.07 inch Warning! Trained electricians only! Work at electric appliances must only be carried out by qualified technicians. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
-
Page 26: Installation Steps
Grab the camera base with both hands and push the grommet into the network cable inlet with both thumbs on the opposite sides of the network cable. Make sure that the grommet is pushed in to its full length. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual... - Page 27 Push the camera base against the mounting plate and turn the camera base in the clockwise direction until you hear/feel a click. Make sure that the camera base is secured. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
- Page 28 After removing the desiccant tablet from the bag, installation must be completed in less than 10 minutes. Attach the desiccant tablet with the adhesive side facing the camera base. Make sure not to cover the vents with the desiccant. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
-
Page 29: Installing The Camera Module
4 Nm (1.8 and 3 lbfft). Make sure that the arrow on the camera module points in the same direction as the red arrow on the camera base. Remove the protective cover from the bubble. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... -
Page 30: Led Status
Make sure that all necessary wiring is done, and that energy is being supplied. Notice! Use full size SD cards for maximum reliability, and to eliminate the risk of bad connections in a microSD to full size SD adapter. Bosch recommends the use of industrial SD cards with health monitoring. LED status A status LED can be seen in the camera bubble on the opposite side of the camera lens. -
Page 31: Mounting Accessories
NDA-8000-WP On-camera weather protector for FLEXIDOME IP 8000i. NDA-8000-PIPW Pendant interface plate including weather protector, outdoor. NDA-8000-PIP Pendant interface plate for FLEXIDOME IP 8000i, indoor. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... - Page 32 NDA-U-PSMB Surface mount box (SMB) for wall mount or pipe mount. NDA-U-PMAL Universal pole mount adapter, white; large. NDA-U-PAx Surveillance cabinet NDA-U-WMT Universal wall mount for dome cameras, white. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 33 FLEXIDOME IP starlight 8000i Hardware installation | en NDA-U-PMT Universal pipe mount for dome cameras, 31 cm, white. NDA-U-RMT Universal roof mount for dome cameras, white. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
-
Page 34: Commissioning
WLAN mode of the camera are designed as installation aid for first set-up or adjustments at a later moment in time. Notice! Remote commissioning can be done down to temperatures of -40º C / 104º F. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual... -
Page 35: Connection Via The Web Browser
Connection via the web browser This device can be accessed via a web browser to configure, control, receive live images, and replay stored video. For best experience, use Microsoft Internet Explorer browser with the Bosch MPEG-ActiveX plugin. This enables these functions: –... - Page 36 Fill in the fields User name and Password. Click OK. If the password is correct, the desired page appears. Note: New releases of software may require you to set a new and stronger password. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
-
Page 37: Troubleshooting
Camera parts are out of place Please contact your supplier or or broken due to transportation. system integrator, or go directly to Bosch Security Systems customer service. PTRZ does not work Camera has lost calibration Reset the PTR in the user correctly. - Page 38 Closing seals are damaged. Please contact your supplier or system integrator, or go directly to Bosch Security Systems customer service. Rubber grommet not placed Re-install rubber grommet. correctly. Cable diameter or shape is not Re-install camera with proper as specified.
-
Page 39: Testing The Network Connection
Customer service If a fault cannot be resolved, please contact your supplier or system integrator, or go directly to Bosch Security Systems customer service. The version numbers of the internal firmware can be viewed on a service page. Please note this information before contacting customer service. -
Page 40: Maintenance
Bubble may become yellow overtime due to exposure to UV radiation like direct or indirect sunlight. In case the bubble gets damaged or yellow, it can be replaced by a clear bubble (NDA-8000- CBL) or a tinted bubble (NDA-8000-TBL). 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual... -
Page 41: Camera Reset
Press tightly and hold the reset button on top of the SD card slot for 15 seconds. The LED light by the reset button flashes in red. Release the reset button. Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... - Page 42 Remove the connection PCB from the camera module. Disconnect the network or power cable from the camera module. 10. Re-install the connection PCB in the camera base. 11. Re-attach the camera module onto the camera base. 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
-
Page 43: Decommissioning
FLEXIDOME IP starlight 8000i Decommissioning | en Decommissioning 11.1 Transfer The device should only be passed on together with this Installation manual. 11.2 Disposal Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual... - Page 44 Surface mount Color White (RAL9003) Motorized PTR range Pan: 0º to +361º; Tilt: -3º to +86º (NDE-8502-R), -3º to +90º (NDE-8502-RT); Roll: -95º to +95º Dome bubble Polycarbonate, clear with UV blocking anti-scratch coating Housing Aluminum with dehumidifying membranes and waterproof...
- Page 45 Tilt: -3º to +81º (NDE-8502-RX), -3º to +89º (NDE-8502-RXT); Roll: -95º to +95º Dome bubble Polycarbonate, clear with UV blocking anti-scratch coating Housing Aluminum with dehumidifying membranes and waterproof connection area NDE-8503-RX / NDE-8503-RXT Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
- Page 46 Audio signal line in 10 kOhm typical; 1 Vrms max Audio signal line out 1 Vrms; 1.5 kOhm typical Alarm input 2 supervised inputs, dry contact or voltage operated (5 - 40 VDC); 2.2K end-of-line resistor 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 47 Positioning Coordinates / Mounting height Camera view wizard Motorized pan, tilt, roll, zoom, autofocus Wireless commissioning IEEE 802.11b/g/n NDE-8502-R / NDE-8502-RT Video streaming Video compression H.265; H.264; M- JPEG Sensor modes 25 fps, HDR, 1920 x 1080 (2 MP) 30 fps, HDR, 1920 x 1080 (2 MP) 50 fps, 1920 x 1080 (2 MP)
- Page 48 20 fps, HDR, 3840 x 2160 (8 MP) 25 fps, 3840 x 2160 (8 MP) 30 fps, 3840 x 2160 (8 MP) Streaming Multiple configurable streams in H.264, H.265 and M-JPEG, configurable frame rate and bandwidth. Regions of Interest (ROI) 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 49 1280 x 1024, HD 720p 1280 x 720, SD 432p 768 x 432, SD 480p (4:3) 720 x 480, VGA (4:3) 640 x 480 NDE-8503-RX / NDE-8503-RXT Video streaming Video compression H.265; H.264; M- JPEG Sensor modes 25 fps, HDR X, 2688 x 1520 (4.1 MP); 30 fps, HDR X, 2688 x 1520 (4.1 MP); 50 fps, 2688 x 1520 (4.1 MP); Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
- Page 50 Data security Crypto Coprocessor (TPM) RSA 2048 bit, AES/CBC 256 bit X.509 certificates Encryption Full end-to-end encryption with supported VMS Network: TLS1.0/1.2, AES128, AES256 Local storage: XTS-AES 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 51 FLEXIDOME IP starlight 8000i Technical data | en Data security Video authentication checksum, MD5, SHA-1, SHA-256 Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
- Page 52 – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 53 FLEXIDOME IP starlight 8000i Support and training | Bosch Security Systems B.V. 2021-02 | V02 | F.01U.385.211 Installation manual...
- Page 54 | Support and training FLEXIDOME IP starlight 8000i 2021-02 | V02 | F.01U.385.211 Bosch Security Systems B.V. Installation manual...
- Page 56 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2021 202104061459...
