DATA PROJECTOR
XJ-H1600/XJ-H1650
XJ-H1700/XJ-H1750
XJ-ST145
User's Guide
Be sure to read the precautions in the separate Setup Guide. For
details about setting up the projector, see the Setup Guide.
Be sure to keep all user documentation handy for future
reference.
*
/XJ-ST155
* USB Port Models
E
*
*
*
Advertisement
Table of Contents
Related Manuals for Casio XJ-H1700
Summary of Contents for Casio XJ-H1700
- Page 1 DATA PROJECTOR XJ-H1600/XJ-H1650 XJ-H1700/XJ-H1750 XJ-ST145 /XJ-ST155 * USB Port Models User’s Guide Be sure to read the precautions in the separate Setup Guide. For details about setting up the projector, see the Setup Guide. Be sure to keep all user documentation handy for future...
- Page 2 CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost profits due to loss of data due to malfunction or maintenance of this product, or any other reason.
-
Page 3: Table Of Contents
Contents About this manual..................5 Projector Overview ............6 Projector Features and Main Functions ..........6 Remote Controller and Projector Keys...........8 Back Terminals..................9 Operation During Projection ........10 Selecting the Input Source ..............10 To select a different input source ................10 3D Input Mode ...................... - Page 4 Configuring Advanced Projector Settings ....21 Basic Setup Menu Operations .............21 Displaying the Setup Menu..................21 Configuring Setup Menu Settings................21 Basic Setup Menu Example..................22 Direct Power On......................23 Password Protecting the Projector ............24 Inputting a Password ....................24 Using the Password Feature..................
-
Page 5: About This Manual
Appendix ................ 44 Connecting to a Video Device ..............44 Connection to a composite video output or S-video output ........44 Connection to a component video output ..............45 Connecting the HDMI Output of a Video Device or Computer to the Projector..............46 Remote Controller Signal Range ............47 Hanging the Projector from a Ceiling ...........48 Projection Distance and Screen Size ...........49... -
Page 6: Projector Overview
Projector Features and Main Functions XJ-H1600/XJ-H1650/XJ-H1700/XJ-H1750/XJ-ST145/XJ-ST155 Mercury-free Hybrid Light Source: A CASIO-original laser and LED hybrid light source delivers high luminance from 2500 to 4000 lumens. This projector does not use a mercury lamp, making it environmentally friendly. A wide selection of input sources: Analog RGB, composite video, S-video, component video (Y·Cb·Cr, Y·Pb·Pr), and HDMI input... - Page 7 Multi Projection Camera (YC-400, YC-430) Connection: A CASIO Multi Projection Camera can be connected directly to the projector’s USB-A port for fine resolution projection of documents and other images. Document camera capabilities allow projection of data without going through a computer.
-
Page 8: Remote Controller And Projector Keys
Remote Controller and Projector Keys Operations in this manual are presented based on the remote controller that comes with the projector. Major operation keys are also provided on the projector unit, so the most of the same procedures can also be performed directly on the projector. Remote Controller Keys Remote control signal emitter [INPUT] key... -
Page 9: Back Terminals
Back Terminals 9 bkbl bm bn bp bq br USB-A port (XJ-H1650/XJ-H1750/XJ-ST145/XJ-ST155 only) LAN port (XJ-H1650/XJ-H1750/XJ-ST145/XJ-ST155 only) HDMI port MONITOR OUT terminal COMPUTER IN 1 terminal COMPUTER IN 2 terminal Remote control signal receiver Power connector SERIAL port* AUDIO OUT terminal Anti-theft lock hole AUDIO IN 1 terminal AUDIO IN 2 terminal... -
Page 10: Operation During Projection
Operation During Projection Selecting the Input Source Turning on the projector initially causes the same input source that was selected the last time it was turned off to be selected. To select a different input source Press the [INPUT] key. This displays the input source selection screen. -
Page 11: 3D Input Mode
Separately available 3D glasses (YA-G30) are required in order to view a projected 3D image in Separately available special software (CASIO 3D Converter) is required to project a 3D image with the projector when a computer (analog RGB) is the input source. -
Page 12: Horizontal Flipping In The 3D Input Mode
Returning to the Normal Input Mode from the 3D Input Mode Press the [INPUT] key to display the input source selection screen. Use the [ ] and [ ] keys to move the highlighting to “To normal input mode” and then press the [ENTER] key. This enters the normal input mode and closes the input source selection screen. -
Page 13: Image Operations During Projection
Image Operations During Projection You can perform the following operations while projecting an image. Image brightness adjustment Color mode selection Image zooming Momentary cut off of the input source image and projection of a black or blue screen, or a logo Image freeze Pointer display in the projected image Aspect ratio switching... -
Page 14: Selecting The Color Mode
Selecting the Color Mode You can select from among various different color mode settings in accordance with image contents and projection conditions. Important! The color mode cannot be selected in the following cases. When “Off” is selected for the Eco Mode setting (page 19) When the projector is in the 3D input mode. -
Page 15: Momentarily Cutting Off The Input Source Image
Momentarily Cutting Off the Input Source Image Press the [BLANK] key. This temporarily cuts off the image from the input source and projects a black screen in its place. To resume projection of the image from the input source, press the [BLANK] key (or [ESC] key). -
Page 16: Displaying A Pointer In The Projected Image
Displaying a Pointer in the Projected Image You can select from among different pointer styles, including various arrow styles, for display in the projected image. Pointers can be used during a presentation to indicate or highlight a specific part of the image. -
Page 17: Changing The Aspect Ratio Of The Projected Image
Changing the aspect ratio of the projected image Press the [ASPECT] key to cycle through the aspect ratio settings for the projected image. Available settings are as shown below. For details about the meaning of each setting, see the “Aspect Ratio”... -
Page 18: Adjusting The Volume Level
Adjusting the Volume Level You can use the remote controller keys to adjust the volume level of the audio that is output from the projector’s speaker. To adjust the volume level Press the [VOLUME] key. This causes the [Volume] screen to appear on the projected image. Press the [ ] key to increase the volume, or the [ ] key to lower the volume. -
Page 19: Eco Mode (Power Saving, Low Noise)
Eco Mode (Power Saving, Low Noise) The following three Eco Mode settings are available to specify whether priority should be given to low-power, low-noise operation or to projection brightness. On (Auto) : A brightness sensor on the top of the projector senses surrounding light, and automatically adjusts projection brightness and color accordingly. -
Page 20: Using The [Func] Key
Important! The Eco Mode setting automatically changes to “Off” whenever the projector is in the 3D input mode (“3D Input Mode”, page 11) or “On” is selected for the “Option Settings 2 Interactive Pointer” setting. The “On (Auto)” setting cannot be selected for the Eco Mode while “On” is selected for “Screen Settings Ceiling Mount”... -
Page 21: Configuring Advanced Projector Settings
Configuring Advanced Projector Settings Your projector has a setup menu that you can use to configure advanced settings. Basic Setup Menu Operations Displaying the Setup Menu Pressing the [MENU] key displays the menu shown below in the center of the projection screen. Main menu Pressing the [MENU] key displays the main menu. -
Page 22: Basic Setup Menu Example
Basic Setup Menu Example The procedure below shows how to configure the following three settings: Image Adjustment 1 Contrast Image Adjustment 1 Color Mode Input Settings Signal Name Indicator Note The setup menu items that you can change depend on whether or not an image signal is being input to the projector, and on the currently selected input source. -
Page 23: Direct Power On
To configure the “Image Adjustment 1 Color Mode” setting Use the [ ] key to select “Color Mode”. Press the [ENTER] key. This displays the color mode menu. Use the [ ] and [ ] keys to select the color mode you want, and then press the [ENTER] key. -
Page 24: Password Protecting The Projector
1. Personal identification (original or copy of your driver’s license, employee I.D., etc.) 2. Projector unit Note that your CASIO distributor will not be able to clear the password of your projector unless you bring both of the items listed above. - Page 25 Keep a written record of your password! You will not be able to use the projector if you forget its password. We strongly suggest that you keep a written or other type of record of the password so you can look it up when necessary. To change the password Press the [MENU] key to display the setup menu.
-
Page 26: Entering The Password When Turning On The Projector
To turn password protection on and off Display the Power On Password setting screen by performing steps 1 through 5 of the procedure under “To change the password” on page 25. At this time, make sure that “Power On Password” is selected on the Power On Password setting screen. -
Page 27: Restoring Projector Settings To Their Initial Factory Defaults
Restoring Projector Settings to Their Initial Factory Defaults You can use the procedures in this section to restore all of the settings on a particular main menu or all of the settings on the setup menu to their initial factory defaults. To restore all settings on a particular main menu to their initial factory defaults Press the [MENU] key to display the setup menu. - Page 28 To restore all settings on the setup menu to their initial factory defaults Press the [MENU] key to display the setup menu. Use the [ ] key to select “Restore All Defaults” and then press the [ENTER] key. After confirming that “Restore All Defaults” sub-menu is selected, press the [ENTER] key.
-
Page 29: Setup Menu Contents
Setup Menu Contents This section contains tables that provide detailed explanations of all of the items included on the setup menu. The following describes the type of information that appears in each of the columns of the tables. Setting Name: This column shows the names of the settings as they appear on the sub-menu. Input: This column shows the input source for which each setting is supported. - Page 30 Setting Name Input Setting Unit Description Color Mode R C V H D U Source You can select from among various different color mode settings in Specific accordance with image contents and projection conditions. Standard: Use this setting when you want to highlight the colors of your presentation.
-
Page 31: Image Adjustment 2 Main Menu
Image Adjustment 2 Main Menu Setting Name Input Setting Unit Description Vertical R C V Signal Use this sub-menu to adjust the vertical position of the input source Position Specific image within the projection area. Horizontal R C V Signal Use this sub-menu to adjust the horizontal position of the input Position Specific... -
Page 32: Screen Settings Main Menu
Screen Settings Main Menu Setting Name Input Setting Unit Description Keystone R C V H D U N Single Use this sub-menu to correct vertical keystoning of the projected Correction image. Aspect Ratio R C V H D Source Use this sub-menu to select an aspect ratio setting for the projected image. - Page 33 Setting Name Input Setting Unit Description Startup Screen R C V H D U N Single Use this sub-menu to specify whether or not a startup screen should be projected whenever the projector is turned on. Logo: Select this option to project the projector’s built-in logo screen at startup.
-
Page 34: Input Settings Main Menu
Input Settings Main Menu Setting Name Input Setting Unit Description COMPUTER 1 N Single Use this sub-menu to specify manually the type of signal being input Terminal/ from the projector’s COMPUTER IN 1/COMPUTER IN 2 terminal. COMPUTER 2 Auto*: Terminal Automatically detects the signal being input from the COMPUTER IN 1/COMPUTER IN 2 terminal and configures the appropriate input protocol. -
Page 35: Option Settings 1 Main Menu
Option Settings 1 Main Menu Setting Name Input Setting Unit Description Auto Keystone R C V H D U N Single Use this sub-menu to turn auto keystone correction on or off. Correction On*: Select this option to turn on auto keystone correction. Off: Select this option to turn off auto keystone correction. -
Page 36: Option Settings 2 Main Menu
Setting Name Input Setting Unit Description Language R C V H D U N Single Use this sub-menu to specify the language to use for messages, setup menus, etc. English / French / German / Italian / Spanish / Swedish / Portuguese / Turkish / Russian / Chinese (Simplified) / Chinese (Traditional) / Korean / Japanese Note... - Page 37 Setting Name Input Setting Unit Description High Altitude R C V H D U N Single Use this sub-menu to turn the high-altitude fan speed setting on or off in accordance with the altitude of the area where you are using the projector.
-
Page 38: Wired Lan Settings Main Menu (Usb Port Models Only)
Wired LAN Settings Main Menu (USB Port Models Only) Setting Name Input Setting Unit Description Remote on R C V H D U N Single Specifies whether the projector can be turned on via wired LAN while the projector is in standby (projector off with power being supplied). -
Page 39: Operational Info Main Menu
Operational Info Main Menu Setting Name Input Setting Unit Description Input Signal R C V H D U N Source This sub-menu item shows the currently selected input signal Specific (RGB, Component, Video, S-video, HDMI (PC), or HDMI (DTV)). “- - - -” is indicated here when there is no input signal. Signal Name R C V H D U Source... -
Page 40: Cleaning The Projector
Cleaning the Projector Periodically clean the projector exterior, lens, intake vents, and intake-exhaust vents on a regular basis. Important! Before cleaning the projector, be sure to unplug it from the power outlet and make sure it is cooled down completely. Cleaning the Projector Exterior Wipe the exterior of the projector with a soft cloth that has been moistened in a weak solution of water and a mild neutral detergent. -
Page 41: Error Indicators And Warning Messages
STANDBY indicator is lit amber (without flashing), and then turn power back on again. If the error occurs again when you turn power back on, contact your retailer or nearest authorized CASIO Service Center. POWER : Amber flashing Power has turned off automatically due to a fan problem. - Page 42 If the error occurs again when you turn power back on, contact your Message : A system problem has retailer or nearest authorized CASIO Service Center. occurred. Normal Press the [ESC] key to clear the warning message.
- Page 43 2 Check to make sure that the light source unit cover is closed. (1-second interval) 3 Plug the power cord back in and turn the projector back on again. Message : – If the error occurs again when you turn power back on, contact your retailer or nearest authorized CASIO Service Center.
-
Page 44: Appendix
Appendix Connecting to a Video Device The projector is able to project images from the composite video output, S-video output, or component video output of a connected video device. Important! Always turn off the projector and the video device before connecting them. Connection to a composite video output or S-video output Projector Video device... -
Page 45: Connection To A Component Video Output
Connection to a component video output Projector Video device Component video cable (commercially available) COMPUTER IN 1 terminal AUDIO IN 1 terminal To component video output terminals To AUDIO output terminals COMPUTER IN 2 terminal White AUDIO IN 2 terminal Stereo mini plug Pin plug type audio cable (commercially available) -
Page 46: Connecting The Hdmi Output Of A Video Device Or Computer To The Projector
Connecting the HDMI Output of a Video Device or Computer to the Projector The projector supports projection and output of HDMI video and audio output from a computer or video device. Important! Turn off the projector and the computer or video device before connecting them. Projector Computer or video device HDMI port... -
Page 47: Remote Controller Signal Range
Remote Controller Signal Range When performing an operation on the remote controller, point it at the remote control signal receiver on the back or front of the projector. The following illustration shows the range of the remote controller signal. ± 30 degrees max. 5 meters (16.4 feet) max. -
Page 48: Hanging The Projector From A Ceiling
Hanging the Projector from a Ceiling The projector can be hung from a ceiling. When doing so, the projector should be turned upside down, and secured to the ceiling. You also need to install a safety wire to ensure that the projector cannot fall accidentally. -
Page 49: Projection Distance And Screen Size
Projection Distance and Screen Size The following table shows the relationship between the distance and projected image size. XJ-H1600/XJ-H1650/XJ-H1700/XJ-H1750 XJ-ST145/XJ-ST155 Projection Size Approximate Projection Distance Projection Size Approximate Projection Minimum Maximum Screen Diagonal Screen Diagonal Distance (cm / inch) Distance... -
Page 50: Aspect Ratio Setting And Projection Image
Aspect Ratio Setting and Projection Image The following shows how images are projected in accordance with the type of the input signal and the aspect ratio setting of the projector. Input source: RGB or HDMI (PC) Input Signal Normal Full SVGA (800 ×... - Page 51 Input source: Video, S-video, component or HDMI (DTV) Input Signal Normal 16:9 4:3 Aspect Image Squeezed Image Letter Box Image...
-
Page 52: Supported Signals
Supported Signals Important! Even if a signal is listed in the table below, it does not guarantee that you will be able to display its images correctly. RGB Signal Horizontal Frequency Vertical Frequency Signal Name Resolution (kHz) (Hz) VESA 640 × 480/60 640 ×... - Page 53 Component Signal Horizontal Frequency Vertical Frequency Signal Name (kHz) (Hz) HDTV 1080p/50 56.3 1080p/60 67.5 720p/50 37.5 720p/60 45.0 1080i/50 28.1 1080i/60 33.7 SDTV 576p/50 31.3 576i/50 16.6 480p/60 31.5 480i/60 15.7 Video Signal, S-video Signal Horizontal Frequency Vertical Frequency Signal Name (kHz) (Hz)
- Page 54 HDMI Signal Horizontal Frequency Vertical Frequency Signal Name (kHz) (Hz) 640 × 480/60 31.5 800 × 600/60 37.9 1024 × 768/60 48.4 1280 × 768/60 47.8 1280 × 800/60 49.7 1280 × 960/60 1280 × 1024/60 1400 × 1050/60 65.3 SDTV (480p) 31.5 SDTV (576p)
-
Page 55: Using Wired Lan To Control The Projector (Xj-H1650, Xj-H1750, Xj-St145, Xj-St155)
Information about the types of external devices that can be connected to the LAN port and control the projector, as well as the control commands supported for each external device will be published on the CASIO website below as such information becomes available. http://www.casio.com/support/... - Page 56 Look up the projector’s IP address. Perform the following steps to look up the projector’s current IP address. 1. Press the [MENU] key to display the setup menu. 2. Use the [ ] and [ ] keys to select “Wired LAN settings” and then press the [ENTER] key. 3.
- Page 57 To control the projector using the Wireless Presentation System control panel Depending on the type of LAN connection you are using, perform either of the following operations to display the top page of the projector’s System Admin page. : “To establish a wired LAN connection between the projector and a Wired LAN Connection computer”...
- Page 58 Group Item Description Image Input Specifies the input source. The following are the available input source options. 3D Off 3D On Computer 1/2 (Auto) Computer 1/2 (RGB) Computer 1/2 (RGB) Video Computer 1/2 (Component) S-video Video S-video HDMI Puts the projector into the 3D input mode or normal input mode. On: 3D input mode Off: Normal input mode Note that this setting cannot be change while the currently selected...
- Page 59 After all of the settings are the way you want, click “Logout”. Note The “Status”, “Setup”, “Change Password”, and “Restore Factory Defaults” items along the left side of the screen are mainly for accessing information and configuring settings related to projector wireless LAN connection.
-
Page 60: Projector Rs-232C Control
Projector RS-232C Control You can use a commercially available serial cable (cross) to connect the projector to a computer and control the projector from the computer. Connecting the Projector to a Computer Connect the projector to the computer as shown in the illustration below. Projector Computer Serial port (RS-232C) - Page 61 See the “Command List” for details about command names and settings. All commands use ASCII characters and decimal format integers. The projector will return a question mark (?) when it is sent a command it cannot recognize. Also, any command that attempts to set a value that is outside the applicable allowable range will be ignored.
- Page 62 Command Function Setting Range Name Color Mode: Selects the color mode. 1: Graphics, 2: Theater, 3: Standard, 4: Blackboard, 5: Game Aspect Ratio: Specifies the aspect ratio. 0: Normal* , 1: 16:9, 2: Normal* , 4: Full Get Light Time: Gets the light time from the projector. 0- Unit: Hours *1 Input source: RGB or HDMI (PC) *2 Input source: Video, S-video, component or HDMI (DTV)
-
Page 63: Specifications
Chinese (Simplified), Chinese (Traditional), Korean, Japanese * XJ-H1650/XJ-H1750/XJ-ST145/XJ-ST155 only CASIO COMPUTER CO., LTD. makes no guarantees concerning the operation or suitability of any USB device that you connect to the projector’s USB port. Specifications are subject to change without notice. - Page 64 MA1108-D...
