- Page 1 User manual RTD317 AUX IN It is important to read this instruction book prior to using your new product for the first time.
-
Page 2: Fcc Information
FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Important Information
Important Information For your safety The AC power plug is polarized (one blade is wider than the other) and only fits into AC power outlets one way. If the plug won’t go into outlet completely, turn the plug over and try to insert it the other way. - Page 4 Important Information Important battery information new and old batteries. Do not use rechargeable batteries. observe the polarities indicated inside the battery compartment. Replace only with the type of batteries specified. Do not dispose of them in a fire or recharge them. a long period of time, remove the batteries.
-
Page 5: Important Safety Instructions
Important Safety Instructions Please read and save for future reference Some of the following information may not apply to your particular product; however, as with electronic product, should be observed during handling and use. • Read these instructions. • Keep these instructions. •... -
Page 6: Table Of Contents
Table of Contents Connections and Setup Connecting to your TV (VIDEO)....2 Connecting to your TV (via HDMI input) Connecting AUDIO from external sources such a TV (Aux-in) Connecting the speakers. -
Page 7: Connections And Setup
Connections and Setup Accessories provided Remote control and Left and right 2 AAA batteries front speakers One external AM loop antenna Things to consider before you connect • Ensure that the mains supply in your house complies with that indicated identification sticker located on the back of your unit. -
Page 8: Connecting To Your Tv (Video)
Connections and Setup Connecting the antennas FM 75 Ω Whit e GN D The AM and FM antennas connect to the AM and FM terminals on the system’s back panel. They must be hooked up in order to receive clear reception. AM Loop Antenna 1. -
Page 9: En Connecting To Your Tv (Via Hdmi Input)
Connecting to your TV (via HDMI input) HDMI stands for High Definition Multimedia Interface. HDMI transfers digital audio and uncompressed digital video on a single cable. Press the HDMI button on the remote control to change output signals as follows: 480p, 720p, 1080i and 1080p. -
Page 10: Connecting The Speakers
Connecting the speakers Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the terminal and insert the wire. Release the tab to lock wire in the terminal. Purple/Grey or Black Striped Subwoofer... -
Page 11: Positioning Speakers
Connections and Setup Positioning speakers Courtesy Dolby Laboratories 1. Left, Right (Front Speakers) Front speakers carry primarily music and sound effects. 2. Center In surround mode, the center speaker carries most of the dialog as well as music and effects. It should be set between the left and right speakers. -
Page 12: Better Surround Placement
Better surround placement Location If possible, place surround speakers to either side of the listening area, not behind it. Height If space permits, install surround speakers 2-3 feet above viewers. This helps to minimize localization effects. Aiming Aim surround speakers straight across the room, not down at viewers, to help create a more open, spacious surround sound field. -
Page 13: Overview Of Controls
Overview of Controls Front panel controls Opens and closes the disc tray. AUX IN AUX IN jacks - Connects USB connects audio devices for devices. playing music and photos. Remote control functions in DVD/CD mode ON•OFF – Switches the unit on and off (p.9). DVD –... -
Page 14: Mode
HDMI RCR 192 AD2 STOP – Stops playback. Press and hold to open the disc tray (p. 9, 10). PAUSE – Freezes frame, accesses frame advance or slow motion function (p.10). AUDIO – Accesses the audio function (p.12). ANGLE – Accesses the camera angle function for DVD disc (p.13). -
Page 15: On Screen Menus
Overview of Controls Using remote control to navigate through the on-screen menus and OK on the remote control to navigate through the on-screen displays (the DVD player’s menu, the Info Display that appears during playback, or a disc’s menu). on the remote to move through on-screen menus in the direction of the arrow button (e.g., to move right, press >). -
Page 16: Basic Playback Operations
Basic playback operations Playback Switch the unit and the TV set on. 1. After loading a disc, playback starts automatically, or the disc menu appears. If the disc menu appears, select the Play option to begin playback. 2. Press STOP to stop playback. Accelerated play While the disc is playing, press REVERSE or FORWARD one or more times to vary the... -
Page 17: The Info Menu
Playing Discs - Basic Functions Notes: • When you press STOP, the unit stores the point where playback was interrupted. If you press PLAY again, playback resumes from this point. To stop playback completely or to start again from the beginning, press STOP twice. -
Page 18: Title/Chapter (Dvd)/Track
Title/chapter (DVD)/track (audio CD ) To directly access a title, chapter (DVD) or a track (audio CD), press INFO, press OK. Select the Title(TT), Track(TRK) or Chapter(CH) icon and enter a number directly with the numeric buttons. Press OK again to confirm. Note: Many discs only have one title. -
Page 19: Camera Angle (Dvd)
The Info Menu Camera angle (DVD) Some discs offer different camera angles for specific scenes. 1. To change the camera angle, press the ANGLE button on the remote or press the INFO button twice and select the Camera angle icon with the left/right buttons. 2. -
Page 20: Creating A Program List For Play Mode Bookmark/Sleep/Introscan(Cd)
Creating a program List for program play mode (mp3 CDs) To use program play mode with an mp3 disc, you must first create a program list. You can program up to 16 songs. 1. To create a program list, press the INFO button twice. -
Page 21: Mp3/Wma Files And Jpeg Files
Mp3/WMA Files and jpeg Files Playing mp3/WMA files or displaying jpeg files Mp3/WMA is an audio file format which compresses recorded music. The main advantage of the mp3/WMA format is that CD-quality music tracks can be stored on a personal computer in user friendly compressed files. -
Page 22: Radio
Radio The unit has a built-in tuner that allows for FM radio function. The AM loop antenna allows for AM radio function. Manual tuning 1. Connect the FM antenna and the AM loop antenna at the back of the unit. Rotate the AM loop for better reception. -
Page 23: Usb Device
USB Device An overview This unit supports MSC devices. You can connect your own USB storage devices, then you can start playback. Connecting/Disconnecting USB device to the Unit Insert the USB drive's connector into the main unit’s USB jack of the unit. To disconnect, unplug the drive. -
Page 24: Cd Ripping
CD Ripping An overview CD ripping allows you to rip tracks on CD to USB device. This unit supports Mass Storage Class (MSC) devices. Connect the USB device first before ripping. Ripping CD to USB device 1. During CD playback, press REC on the remote to activate the Ripping Menu. -
Page 25: The Setup Menu
The Setup Menu There are four options in the main setup menu: General Setup, Display Setup, Speaker Setup and Language Setup. Press SETUP to bring up the main menu. Select one of the menu icons across the top of the screen using the left/right arrow buttons. The menu’s options are displayed on the left side of the screen. -
Page 26: Rating
Rating Explanations • The disc publisher is responsible for coding scenes according to the rating limits. Below is an explanation of Ratings. • To change the rating limit, highlight the RATING option and press the right arrow button. Select the rating limit using the up/ down arrow buttons and press OK. -
Page 27: Subtitles
Subtitles Select the subtitle language using up/down arrow buttons and press OK. To change the language of the subtitles during playback, press INFO twice for DVD and use the left/right arrow buttons to highlight the Subtitle icon. Press the up/down arrow buttons or the SUBTITLE button on the remote to select a subtitle language. -
Page 28: Test Tone
Test Tone This function is used to test the speaker setting and change the speaker level. A short noise comes successively from each speaker. Notes: • Night mode function is available only on DVD discs recorded in Dolby Digital. • The receiver speaker distance default settings are as follows: Front (FR/FL Dist.) Center (Cen Dist.) -
Page 29: Additional Information
Additional Information Troubleshooting The unit does not switch on. • Make sure it is plugged in. • Press the ON•OFF button on the remote control or the ON/STANDBY button on the front of the unit. The device switches off spontaneously. •... -
Page 30: Precautions
Precautions • If your unit has been stored in a cool place for any length of time, during a journey for example, wait for about 2 hours before using it. • The openings located on the top and bottom are for ventilation and must not be obstructed. -
Page 31: Compatible Formats
Additional Information Compatible Formats In order to ensure playback, discs must conform with DVD or CD standards. This unit may not play some recordings or files due to differences in recording formats, software used and disc types. DVD-Video Digital video discs - 12 cm, single or double sided, single or dual layer. -
Page 32: Sound Enhancement Systems
• Do not record copyright-protected mp3 files. “Securized” files are encrypted and code protected to prevent illegal copying. jpeg files CD-R and CD-RW with jpeg files. Certain jpeg files, including progressive jpeg files, cannot be read by this unit. IMPORTANT! The above recommendations do not guarantee that the unit will play mp3 recordings, or as an assurance of sound... -
Page 33: Technical Specifications
Additional Information Technical Specifications: Amplifier Section: RMS Output Power: Dolby Digital Mode with 10% Total Harmonic Distortion Rear Channels: 40Watts channel (1KHz, 4Ohm) Front and Center Channel: 40 Watts per channel (1KHz, 4Ohm) Subwoofer Channel: 50Watts (100Hz, 3Ohm) Total RMS Output Power, Dolby Digital mode: 250Watts FTC Output Power: Dolby Digital Mode with 10% Total Harmonic Distortion... -
Page 34: Limited Warranty
For more information on other products and services, please visit our web site at www.1800customersupport.com/RCA Important: Also keep your "Bill of Sale" as proof of purchase. - Page 36 AVC Multimedia Inc. Unit 6, 170 Esna Park Drive, Markham, Ontario L3R 1E3 © 2008 AVC Multimedia Inc. Trademark(s)® Registered Marque (s)® de commerce enregistrée (s) Marca(s) Registrada(s) Printed in China RTD317 IB V1.0 (EN)
