- Page 1 RADONTEC ALPHAEX 150 / 200 / 250 Manual February 2021...
- Page 2 RadonTec GmbH Hauptstraße 5 89426 Wittislingen - Germany Tel: (+49) 9076 - 919 98 35 E-Mail: info@radontec.de Website: radontec.de Shop: radonshop.com Version: 01...
-
Page 3: Table Of Contents
Operation with speed controller ......26 Operation with transformer ........26 Commissioning ............27 Maintenance............... 28 Troubleshooting ............30 Transport and Storage ..........32 Disassembly and disposal ........... 33 Circuit diagrams ............34 Two-year warranty ............. 36 Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 4 Support and Contact ..........37 16.1 Troubleshooting/FAQ ..........37 16.2 Contact Us .............. 37 Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 5: Introdcution
Introdcution The RADONTEC ALPHAEX was developed for the underfloor extraction of radon gas. With a drainage underneath the foundation, radon-containing soil air is extracted over a wide area and conducted outside by negative pressure. With a so- called radon well in or near the house, the radon-containing soil air is extracted selectively and thus kept away from the walls of the house that are in contact with the soil. - Page 6 Application example 1: Point radon extraction with discharge at floor level. Manual – RadonTec AlphaEx 150/ 200/ 250...
- Page 7 Application example 2: Point radon extraction under the floor slab with discharge above the roof. Manual – RadonTec AlphaEx 150/ 200/ 250...
- Page 8 Application example 3: Extraction of radon soil air via an external radon well. Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 9: Technical Data
Protection class IP X4 Installation location Roof Mounting position vertical Material Powder-coated steel Fluid temperature at I -25 °C to 50 °C Sound pressure level 48 dB(A) (distance 3 m, free field conditions) Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 10: Scope Of Delivery
The RADONTEC ALPHAEX radon aspirator is available in different versions, each of which differs in the pipe diameter and the resulting performance and air volumes. EX 150 EX 200 EX 250 Nominal width 150 mm 200 mm 250 mm Nominal power... - Page 11 Depending on the size and temperature conditions, the cooling time can be up to 30 minutes. Do not switch on the unit until this time has elapsed. Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 12: Dimensions
Dimensions Depending on the nominal width, the variants of the RADONTEC ALPHAEX have different dimensions. Dimensions, mm Weight, EX 150 EX 200 EX 250 10,1 Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 13: Bestimmungsgemäße Verwendung
Bestimmungsgemäße Verwendung Intended use The RADONTEC ALPHAEX fans are suitable for the following applications: ● RADONTEC ALPHAEX fans are suitable for both private and public/commercial use. ● These fans are used for the extraction/venting of soil air containing radon under buildings. -
Page 14: 6.2 Non-Permitted Use
ISO 13857. We offer the matching protective grille for this as an option. (Must be purchased separately). 6.2 Non-permitted use RadonTec is not liable for damage caused by improper use. Do not use the unit under any circumstances: ● to convey air that is saturated with water vapour or contains grease ●... -
Page 15: Ambient Conditions
The electrical connection may only be carried out by qualified electricians. These have electrical engineering training and knowledge of the dangers and effects that can result from an electric shock. The installation personnel must be height- and foot-safe. Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 16 Only operate the unit when it is completely assembled. A sufficient supply air flow must be ensured. Modifications and conversions to the unit are not permitted and release the manufacturer from any warranty and liability. Manual – RadonTec AlphaEx 150/ 200/ 250...
- Page 17 If the unit is installed close to the floor, it is recommended that the fan be installed at a minimum height of 2 metres. This can reduce wilful damage, tampering or the risk of injury to children or animals. Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 18: Assembly And Electrical Connection
● Use suitable insulation, soundproofing and installation material between the unit and the roof base. ● The fan can be mounted on a roof box to prevent snow and water from entering a ventilation pipe. Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 19: Fan Installation
3. Sufficiently dimensioned fastening material must be provided by the customer (screws with Ø 10 mm, min. strength class 8.8). Screw the unit tightly to the roof, roof base or pipework. Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 20 Put on protective gloves. Leakage due to insufficient sealing. 1. Screw the unit tightly with all screws. 2. Attach suitable insulation, sound insulation and installation material. Installation on the roof or roof plinth Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 21: Electrical Connection
The fan must be connected to the power supply via insulated, electrical power lines (cables, wires) through the miniature circuit breaker built into the stationary power supply network, which interrupts the circuit in the event of a short circuit or overload. Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 22 2. The fan is connected to the mains via the terminal strip fixed inside the external or integrated terminal box of the fan according to the connection diagram and terminal markings. 3. sticker with the terminal designations is located inside the terminal strip. Manual – RadonTec AlphaEx 150/ 200/ 250...
- Page 23 S1 button is pressed. 6. In case of motor overheating, the contact is disconnected, the winding of the motor starter is switched off and the motor is stopped. Manual – RadonTec AlphaEx 150/ 200/ 250...
- Page 24 The circuit breaker QF, the magnetic starter KM1, the control buttons S1 and S2 are not included in the scope of delivery. Manual – RadonTec AlphaEx 150/ 200/ 250...
- Page 25 Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 26: Operation With Speed Controller
Operation with transformer The speed of RADONTEC ALPHAEX units can be adjusted with a 5-stage transformer suitable for the unit type. (Must be purchased separately) Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 27: Commissioning
5. Carry out a function test. Check the smooth running of the impeller and ensure it if necessary. It is also important that the air can flow freely. 6. Switch off the unit. Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 28: Maintenance
Disconnect the fan from the mains before carrying out maintenance work! To ensure access to fan parts, partially disassemble the fan. Wipe the impeller blades with a neutral cleaning solution and a damp cloth. Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 29 Technical maintenance includes regular cleaning of the fan surfaces from dust and dirt. Use a soft brush or compressed air to remove dust. Carefully clean the impeller blades every 6 months. Do not immerse the fan in water. Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 30: Troubleshooting
Check the repair switch if necessary. Thermal overload Impeller blocked. Repair only protection of the permitted by a specialist: Check motor switches off impeller and clean if necessary. the fan. Impeller does not Motor too hot. rotate. Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 31 If the fault persists or occurs repeatedly, disconnect the fan from the mains at all poles. Have the cause of the fault determined and eliminated by a trained electrician. Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 32: Transport And Storage
• at a temperature of +5 °C to +40 °C • relative humidity of 80 % (at +20 °C) Before installation, check the proper function of the motor bearing. Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 33: Disassembly And Disposal
5. Remove the fan. Packaging materials and old units must be disposed of in an environmentally friendly manner at the end of their useful life in accordance with the regulations in force in your country. Manual – RadonTec AlphaEx 150/ 200/ 250... -
Page 34: Circuit Diagrams
At the end of its service life, the appliance must be disposed of in accordance with the regulations in force in your country. Circuit diagrams RADONTEC ALPHAEX 150 / 200 / 250 Manual – RadonTec AlphaEx 150/ 200/ 250... - Page 35 RADONTEC ALPHAEX with 5 stage transformer RADONTEC ALPHAEX with Speed Controller Manual – RadonTec AlphaEx 150/ 200/ 250...
-
Page 36: Two-Year Warranty
Two-year warranty The warranty applies to the RADONTEC ALPHAEX purchased from RadonTec GmbH or authorised dealers. This covers defects in material or workmanship under normal use for a period of one year after receipt of the product. Contamination due to dirt or improper use is not covered by the warranty. - Page 37 Should you have any further questions or require further help and technical support, please do not hesitate to contact us. RadonTec GmbH Hauptstraße 5 89426 Wittislingen - Germany Tel: (+49) 9076 - 919 98 35 E-Mail: info@radontec.de Website: radontec.de Shop: radonshop.com Manual – RadonTec AlphaEx 150/ 200/ 250...
