Panasonic F-P06DXZ Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Includes Warranty
Thank you very much for purchasing
・
Please read the Operation Instruction and Warranty terms carefully in order to use
the Air Purifier correctly.
In particular please also read the "Safety Precautions" section (page 4 and 5)
before use. Keep the instructions in a safe place for future reference.
・
Correct information shall be written on warranty card including date of purchase and
name of distributor. Warranty Card shall be provided upon purchase.
Operating Instruction
F-P06DXZ
Model No.
This product is for indoor use only.
     
Air Purifier.
Use wisely to save power
Air Purifier

Advertisement

Table of Contents
loading

Related Manuals for Panasonic F-P06DXZ

Summary of Contents for Panasonic F-P06DXZ

  • Page 1 Operating Instruction Air Purifier F-P06DXZ Model No. This product is for indoor use only. Includes Warranty         Thank you very much for purchasing Air Purifier. ・ Please read the Operation Instruction and Warranty terms carefully in order to use the Air Purifier correctly.
  • Page 2 Super alleru-buster Air Purifier Fight against allergens and viruses. Mega-active ions released Restraining activity ifDP allergens ＊ 1 viruses Composite air filter floating fungi and molds and fight odors. Restraining activity Super alleru-buster Unit Super alleru-buster Unit Super alleru-buster Unit allergens ＊...
  • Page 3 Contents Page Safety precautions ‥‥‥‥‥‥‥ Automatic AIC  ‥‥‥‥‥‥‥‥ Part identification Operation ‥‥‥‥‥‥‥ Installation location Air Intelligent Control Before use ‥‥‥‥‥‥‥‥‥‥‥ AIC is a combination of AIC learning ‥‥ Put down the date of first use on the label function and patrolling function, Sensor sensitivity level adjustment ‥‥‥‥‥‥...

  • Page 4: Safety Precautions

    Safety precautions Always observe these precautions These safety precautions are provided for your protection. Please read and follow them carefully to avoid unnecessary injury and damage to the product itself or other properties. ■ The following symbols differentiate the levels of danger and injury that may result if the product is not used specifically as instructed.
  • Page 5 WARNING Do not insert pins Do not disassemble Do not let the or other metallic appliance or modify this objects into the air get wet. appliance. inlets or air outlets. Do not Disassembling or Short-circuits or If metallic objects touch get wet ! modifying the appliance electric shock may...

  • Page 6: Part Identification

    Part identification (  page 13) Operation panel Timer indicators Child lock indicator (  page 10) Operation indicators (  page 13) Filter check indicator (     pages 15 and 19) Power Off / On button (  pages 8 and 9) Operation mode selection button Child lock button Timer button (  page 10) (  page 13)
  • Page 7 (Removing the filter units:    page 17) Filter units (2 units) (internal) ＜ ＞ Filter unit disassembly diagram Composite air filter Filter frame (  page 2) (white) Deodorizing filter (  page 2) Filter frame Filter frame (gray) Important: Do not use this unit when a filter unit and / ●...
  • Page 8 Installation location Before use Power Off / On button Installation basics Panel indicators Do not block the areas around the air outlets. Odor sensor In order to ensure the efficient circulation of air in the room, place the unit so that the air outlets are at least 30cm away from walls and furniture.
  • Page 9 Label Put down the date of first use of the Composite composite air filter and deodorizing filter Date installed: air filter on the label (lower left side of the label) on the rear of the unit. Replacement filter Deodorizing Part No. F Y506WZ Date installed: filter...

  • Page 10: Using The Air Purifier

    Using the air purifier Press the Power Off / On button. (  page 9)   Press the Operation mode Selection button to select an operation mode. Power Off / On button Each press of the button changes the ● operation mode and operation indicators Operation indicators in the order shown below.
  • Page 11 To predict and remove pollutants: AIC Auto Mode Automatic operation combines the AIC Learning Function and AIC Patrolling Function to predict the pollution of the room. Operation indicators Panel indicators Panel indicators Operation indicators Super alleru- buster indicator (blue) (orange) AIC indicator Fan speed (orange)
  • Page 12 Using the air purifier To efficiently remove allergens: Allergen Mode automatic operation The unit will first operate in Super mode for approximately 30 minutes to remove dust, the source of allergens. It will then repeat a 24 -hour cycle of shutting down for 15 minutes and then operating for 16 minutes, maintaining the cleanliness of the air in the room.
  • Page 13 Useful settings Using the timer Timer indicators Press the Timer button while the unit is running. The timer setting will change with each press ● of the button. Timer indicators (red) Using the child lock Use this function to prevent children from changing the unit's settings. Child lock indicator Press and hold for 3 seconds to turn the Lock on.
  • Page 14 Useful settings Turning off or dimming the air quality monitor and panel indicators You can turn off or dim the air quality monitor and panel indicators when they are too bright when going to bed. Panel indicators Press and hold the timer and operation mode selection buttons at the same time for 3 seconds while the unit is running.

  • Page 15: Care And Maintenance

    Care and maintenance Be sure to unplug the power supply before maintenance. Care and maintenance frequency Filter check indicator (Top of the main unit) (red) Once ・ Main unit Cleaning Page 16 ・ Pre - filter month ・ Filter unit (front) Page 17 Once Cleaning...
  • Page 16 Care and maintenance Main unit / once per month Wipe away soil with a damp, tightly wrung-out cloth. Do not use water to wash the main unit. ● If you use a cleansing agent, be sure to use ● a diluted, neutral kitchen cleanser. Do not use any of the solvents shown in the ●...
  • Page 17 Filter unit (front) / Once in per 3 years Front (Composite air filter side) Use a vacuum cleaner to clean dirt away from the front (composite air filter side). Remove the filter units (2) from the bottom of the main unit. (  See below.) Use a vacuum cleaner to clean dirt away from the front (composite air filter side).
  • Page 18 Care and maintenance Filter replacement period ※ Composite air filter Replacement not necessary Filter unit (2units) Approx. once per 3 years Deodorizing filter The replacement period for the filters may be ● shorter than normal depending on the location and method of use (for instance, in a household where smoking is common).
  • Page 19 Composite air filter: When the filter check indicator comes on (once per 5 years) Composite air filter Soak the filters in washing detergent ● Be sure to remove dissolved in cold water or warm water. (2units) the filter from the filter (   page 15) frame.

  • Page 20: Troubleshooting

    Troubleshooting Check the following before asking for service. Symptom Check / Remedy Page Have the pre-filter or filter cover been removed? ● Are they installed securely? 16.17  Securely install the pre-filter and / or filter cover. → The air purifier Has the power plug been removed from the wall socket? ●...

  • Page 21: Replacement Filters

    Normal situations that do not cause harm or hazards. Sometimes the air purifier may operate in ways that appear to be a problem but are actually normal. You can continue using the air purifier at such times without problem. Symptom Operation is Normal Page Is AIC Auto Mode in progress...
  • Page 22 MEMO...
  • Page 24 Model No. 〜 Power supply Fan speed settings ※ Power consumption (W) Air volume (m /min.) Floor area capacity   Power cord length × × Size (H Weight ※   P06XZ8950ZC K0505W0...
